- Page 1 NETWORK VIDEO RECORDER Quick Guide QRN-420S/QRN-820S/QRN-1620S...
-
Page 2: Package Contents
English Features Package Contents The product records video and audio from cameras to a hard disk, and enables playback from the hard disk. The actual parts may differ from the images. It also provides remote monitoring environment for video and audio over the network using a remote computer. Accessories and quantities may vary by sales region. -
Page 3: Hdd Installation
HDD Installation QRN-1620S After unscrewing, push back and remove the cover. Connect the SATA/power cables of the HDD to the If you are adding a new or previously used HDD to this product in addition to the HDD(s) originally installed, format the new HDD connectors on the mainboard. - Page 4 Install Wizard Setup Recorder ID/PW Setup Sets the administrator's password. Select the language Select your preferred language. ※ Click < > to view the basic guide for setting a password. Refer to the password setup rules. Camera ID/PW Setup 4-1. Set a camera password in factory reset. The initial password for the camera must be entered. Network Settings 4-2.
-
Page 5: Record Setup
Record Setup Resolution Setup To set the recommended resolution, click <Apply> followed by the <Next> button. You can set resolution, IPS, and quality of recordings by channel, and by recording type of standard / event. You can check frame rates and data transfer amount of Full Frame and Key Frame recordings for each channel, and set the transfer limit for recordings. - Page 6 Set up and run the layout Browse The layout set on the live screen can also be used for time search and can be searched and played according to the channel order and channel combination set by the user. For more information on how to set each step, refer to the “User Manual.” Live channel layout Setup a The default value is <All channels>.
-
Page 7: Live Launcher
Using the basic guide Using product information You can check the product information/manual/firmware information/FAQ/HDD compatibility list on the homepage or mobile web of your smartphone. View shortcut menu By right-clicking the live screen, you can use various functions provided by the recorder. If you hover over the icon, the definition of terms for each function is briefly displayed. -
Page 8: Connecting The Cable
Using P2P Service Connecting to a network using a router This function is available only for products that support P2P. To find products that support P2P, see If you want to add 1-3 PCs and recorders in an environment using xDSL/Cable modem, you can use the router with "Supported Products by Function"... -
Page 9: System Requirements
Checking the recorder connection from the PC Accessing using DDNS address in the dynamic IP environment In the dynamic IP environment such as xDSL/Cable modem, the router's WAN IP can be changed, so we provide Enter the IP set in the recorder menu in the local PC address bar to go to the web viewer screen of the recorder. DDNS (Dynamic Domain Name Server) service so that you can always access the recorder with only the DDNS address even in the dynamic IP environment. - Page 10 • Connect using DDNS address Go to <DDNS> in the recorder <Network> setup menu. Connect to <ddns.hanwha-security.com> and check if the connection status of the registered Select <ddns.hanwha-security.com>. product is set to <ON>. Enter the <Manufacturer ID>. Enter the <Product ID> created on the Wisenet DDNS website in <Manufacturer ID>.
- Page 11 MEMO...
- Page 12 MEMO...
- Page 13 Hanwha Techwin cares for the environment at all product manufacturing stages, and is taking measures to provide customers with more environmentally friendly products. The Eco mark represents Hanwha Techwin's devotion to creating environmentally friendly products, and indicates that the product satisfies the EU RoHS Directive.
- Page 14 Head Office 6, Pangyo-ro 319 beon-gil, Bundang-gu, Seongnam-si, Gyeonggi-do, 463-400 Rep. of KOREA Tel : +82.70.7147.8753 Fax : +82.31.8018.3740 www.hanwha-security.com Hanwha Techwin America 500 Frank W. Burr Blvd. Suite 43 Teaneck, NJ 07666 Toll Free +1.877.213.1222 Direct +1.201.325.6920 Fax +1.201.373.0124 www.hanwhasecurity.com...
