- Page 1 NETWORK VIDEO RECORDER Quick Guide XRN-6410DB4/XRN-6410B4/XRN-3210B4...
-
Page 2: Package Contents
English Features Package Contents The product records video and audio from network cameras to a hard disk, and enables playback from the hard disk. It also provides remote monitoring environment for video and audio over the network using a remote computer. •... -
Page 3: Installing The Hdd
Installing the HDD Installing the Rack Use the front cover lock key to unlock the cover. Press the orange button on the hard disk bracket to Rack Installation Requirements and Reference Dimensions Grab the front cover with both hands and pull it to the left and pull forward to separate the main body the left to remove it. - Page 4 Recommended rack dimensions Precautions when Using Sliding Shelves Rack back When removing a shelf, fix the rack to the ground so Avoid leaning on the installed product or place an that it does not get toppled. object on it while its shelf is pulled out. Back mounting flange Recorder Front mounting flange...
-
Page 5: Select The Language
Install Wizard Setup How to Install Rack As shown below, proceed through each step of the <Install Wizard>. Install Wizard can only be accessed at factory Mount the fixed or sliding shelf onto the 19-inch rack. reset. If you do not want to proceed, click <Exit>. See the manual provided by the manufacturer for installing the fixed shelf. - Page 6 Recorder ID/PW Setup Date/Time Setup Sets the administrator's password. Set the date, time, time zone, and DST and then click <Next>. Camera Register ※ Click < > to view the basic guide for setting a password. Refer to the password setup rules. Camera ID/PW Setup Registers the searched network cameras.
-
Page 7: Record Setup
Explore Screen Configuration Record Setup The recorder screen consists of the following. You can set resolution, IPS, and quality of recordings by channel, and by recording type of standard / event. You can check frame rates and data transfer amount of Full Frame and Key Frame recordings for each channel, and set the transfer limit for recordings. - Page 8 Set up and Run the Layout 2-1 Search The layout set on the live screen can also be used for time search and can be searched and played according to the channel order and channel combination set by the user. For more information on how to set each step, refer to the ‘User Manual’.
- Page 9 Using Product Information Export recorded video You can check the product information/manual/firmware information/FAQ/HDD compatibility list on the homepage or mobile web of your smartphone. http://hanwha-security.com http://hanwha-security.com a Click < > at the bottom of the screen. b Select a layout. c Select a channel.
- Page 10 Using P2P Service From now on, when you run the WiseNet mobile application saved to your smartphone, you can easily monitor with your smartphone as you are automatically connected to the recorder. This function is available only for products that support P2P. To find products that support P2P, see ‘Products supporting each feature (Page 4)’...
-
Page 11: Connecting The Cable
Connecting to a Network Using a Router Checking the recorder connection from the PC Enter the IP set in the recorder menu in the local PC address bar to go to the web viewer screen of the recorder. If you want to add 1-3 PCs and recorders in an environment using xDSL/Cable modem, you can use the router with only one Internet line. - Page 12 Accessing using DDNS address in the dynamic IP environment Connect using DDNS address In the dynamic IP environment such as xDSL/Cable modem, the router's WAN IP can be changed, so we provide Select DDNS site on the recorder setup menu Connect to ddns.hanwha-security.com and DDNS (Dynamic Domain Name Server) service so that you can always access the recorder with only the DDNS and enter the product ID.
- Page 13 Hanwha Techwin cares for the environment at all product manufacturing stages, and is taking measures to provide customers with more environmentally friendly products. The Eco mark represents Hanwha Techwin's devotion to creating environmentally friendly products, and indicates that the product satisfies the EU RoHS Directive.
