Adjust Seat Height
WARNING!
• Always tighten fasteners to
the correct torque to prevent
serious injury or death. Bolts
that are too tight can stretch
and deform. Bolts that are
too loose can move and
fatigue. Either condition can
lead to a sudden failure of the
bolt and result in a crash. See
Tightening Torque (p. 21).
• ALWAYS insert seat post past
the minimum insertion point
marked on the seat post. A
seat post that is positioned
too high can damage the bike
and can cause you to lose
control and crash.
Correct seat adjustment is an important factor in getting the most
performance and comfort from your bicycle. If the seat position is
not comfortable for you, you may want to go to your local bicycle
shop for assistance.
To achieve correct seat height:
• Sit on the seat;
• Place one heel on a pedal;
• Rotate the crank until the pedal with your heel on it is in the down
position and the crank arm is parallel to the seat tube.
If your leg is not completely straight, your seat height needs to be
adjusted. If your hips must rock for your heel to reach the pedal,
the seat is too high. If your leg is bent at the knee with your heel on
the pedal, the seat is too low.
L E CT R I C E B I K E S.C O M | 602.715.0907
18
Hide quick links:
Advertisement
Table of Contents
Need help?
Do you have a question about the XP 3.0 and is the answer not in the manual?
Questions and answers
How do you turn on the standard headlight and brake light for night riding?
To turn on the standard headlight and brake light on the Lectric XP 3.0 for night riding, first, make sure the bike is powered on by pressing the power button. Once the display is on, hold the "+" button on the handlebar control until the light symbol appears on the display. This indicates that the lights are on. The headlight will provide a forward beam, and the brake light will activate when braking.
This answer is automatically generated
@Jan Hangen Do the keys need to be engaged for the battery to work
how to charge battery
To charge the Lectric eBikes XP 3.0 battery:
1. Plug the charger cable into the battery pack's charging port.
2. Plug the charger power cable into a wall socket using the supplied AC power cord.
3. Ensure the battery is within the permitted charging temperature range.
4. Do not leave the battery unattended while charging.
5. Do not charge the battery for more than 12 hours.
6. When the charger light turns green, disconnect the charger from the battery and then from the wall socket.
7. If the battery was charged while in the bike frame, insert the rubber plug into the charging port to prevent dirt or water from entering.
This answer is automatically generated
Having trouble reconnecting the stem clamp
To reconnect the stem clamp on a Lectric eBikes XP 3.0:
1. Pull the handlebar stem to its upright position.
2. Push the latch in firmly until it locks in position.
3. Pull on the latch to confirm it is locked and the handlebars cannot fold.
This answer is automatically generated
I need a exploded view of the rear breaking system
How to turn on head light
To turn on the headlight on a Lectric eBikes XP 3.0, hold the plus (+) button on the display control pad for about 3 seconds until the light icon appears on the display.
This answer is automatically generated
I cannot find the voice associated the video?
How I turn on the voice with the video.
size of rear axle on XP 3.0
The rear axle on the Lectric XP 3.0 uses a 17-millimeter nut, as indicated by the need for a 17mm socket to loosen it.
This answer is automatically generated
ALINE THE FRONT WEAL WITH HANDLE BAR?
To align the front wheel with the handlebars on a Lectric eBikes XP 3.0, follow these steps:
1. Gather the necessary tools: a 5mm Allen socket, a 5mm Allen wrench, and a torque wrench.
2. Locate the two pinch bolts at the bottom of the stem.
3. Use the 5mm Allen wrench to evenly loosen both pinch bolts until the stem is loose enough to adjust.
4. Grip the handlebars and make small adjustments left and right until the display is lined up with the front tire and headlight.
5. Use the front fork to ensure proper alignment between the stem and handlebars.
6. Once aligned, use the 5mm Allen wrench to tighten the pinch bolts.
7. Torque the bolts down to 20 Nm using the torque wrench and 5mm Allen socket.
After completing these steps, the handlebars should be properly aligned, and the eBike is ready to ride.
This answer is automatically generated
How to line up front wheel to handle bar?
To align the front wheel with the handlebars on a Lectric eBikes XP 3.0:
1. Use a 5mm Allen wrench to evenly loosen the two pinch bolts located at the bottom of the stem until the stem is loose enough to adjust.
2. Grip the handlebars and make small left or right adjustments until the display is lined up with the front tire and headlight.
3. Use the front fork to ensure the stem and handlebars are properly spaced apart.
4. Once aligned, tighten the pinch bolts using the 5mm Allen wrench.
5. Torque the bolts down to 20Nm using a torque wrench with a 5mm Allen socket.
Now, the handlebars should be properly aligned and ready for riding.
This answer is automatically generated
