OWNERS MANUAL
Lectric XP™ 3.0
Lectric XP™ Step-Thru 3.0
V 1.0 | 2022
www.lectricebikes.com
602.715.0907
To prevent PROPERTY DAMAGE, SERIOUS INJURY, or DEATH,
you should read, understand, and follow the warnings and
instructions in this manual. Keep for future reference.
L E CT R I C E B I K E S.C O M | 602.715.0907
1
Advertisement
Table of Contents
Related Manuals for Lectric eBikes XP 3.0
Summary of Contents for Lectric eBikes XP 3.0
- Page 1 OWNERS MANUAL Lectric XP™ 3.0 Lectric XP™ Step-Thru 3.0 V 1.0 | 2022 www.lectricebikes.com 602.715.0907 To prevent PROPERTY DAMAGE, SERIOUS INJURY, or DEATH, you should read, understand, and follow the warnings and instructions in this manual. Keep for future reference. L E CT R I C E B I K E S.C O M | 602.715.0907...
- Page 2 For replacement parts and accessories, you should always use Lectric eBikes approved parts, as they have been specially designed for your bicycle and manufactured to meet Lectric eBikes’ demanding standards. This manual should be considered a permanent part of your bicycle and should remain with the bicycle when it is sold.
-
Page 3: Table Of Contents
TABLE OF CONTENTS Important Safety Information Getting Started Features Cockpit System Preparing to Ride Your First Ride Battery Pack Storing Your Lectric eBike Transporting Your Lectric eBike Disposal of Your Lectric eBike Troubleshooting Maintenance Legal L E CT R I C E B I K E S.C O M | 602.715.0907... -
Page 4: Important Safety Information
IMPORTANT SAFETY INFORMATION Read and Understand Owner’s Manual Before Riding Read this entire Owner’s Manual before you take the first ride on your new eBike and keep it for reference. This Owner’s Manual contains important safety, performance, and service information. The latest version of your manual is available at lectricebikes.com/manual Like any sport, bicycling involves risk of injury and damage. - Page 5 Intended Use The intended use of your Lectric eBike is to be ridden by one adult rider (age 18 and up) at an appropriate time and place for general transportation and/or recreational use. Any other use is prohibited and may result in SERIOUS INJURY or DEATH. Your bicycle is NOT INTENDED for off-road or mountain bicycle use, or for any kind of jumping.
- Page 6 • Take responsibility for your own SAFETY. If you have any questions or do not understand any aspect of using or maintaining your bicycle, contact Lectric eBikes at contact@lectricebikes.com or call (602) 715-0907. L E CT R I C E B I K E S.C O M | 602.715.0907...
- Page 7 Helmets • Always wear a helmet. Wearing a helmet properly may reduce the risk of a severe head injury. When riding, always wear a helmet that meets or exceeds the standards of the Consumer Product Safety Commission (CPSC). Check the manual that comes with your helmet.
- Page 8 Pre-Ride Safety Checklist Lectric eBikes recommends going through each item on the pre-ride safety checklist before and after each ride. Spending time to make sure all of the bike’s components are in good working order before a ride is a crucial step along the way to a safe and fun ride.
- Page 9 Pull the brake levers to ensure the brakes are working properly and adjust if necessary. Visually inspect the bike for damage or anything out of the ordinary. Turn on the lights, especially if riding at night. Make sure all hardware is tightened to the recommended torque specifications found on p.
- Page 10 Riding at Night • Riding at night comes with more risks than riding during the day due to decreased visibility; riders are encouraged to exercise increased caution in nighttime conditions. • Turn lights ON for safety. For increased visibility, ensure that the front headlight and rear taillight are turned ON and adjusted such that other people on the road can see them clearly.
- Page 11 On-Product Warning Labels There are warning labels on your Lectric eBike for your protection. If a label is missing or is not legible, contact Lectric eBikes for a replacement. Stem label Class 2 label...
- Page 12 On-Product Warning Tags There are warning tags on your Lectric eBike for your protection. If a tag is missing or is not legible, contact Lectric eBikes for a replacement.
-
Page 14: Getting Started
2 Battery Manufacturer Keys Manuals If anything is missing or is damaged, contact Lectric eBikes immediately for assistance. For a video about how to unfold your bicycle, visit our YouTube page: Lectric eBikes, youtube.com/LectriceBikes L E CT R I C E B I K E S.C O M | 602.715.0907... - Page 15 Serial Number Your serial number is located on the head tube of the bicycle as shown below. Please write it down inside the front cover of this manual. You may be asked for your bicycle’s serial number as part of a warranty request.
- Page 16 Stem Continued To fold: 1. Pull up on the silver button labeled “open” to unlock the latch. 2. Pull the latch away from the stem while still holding the “open” button. 3. Fold the stem by lowering it to the side. Frame To unfold: 1.
- Page 17 Pedals To unfold: 1. Pull each pedal out until you hear an audible click as they lock into position. To fold: 2. Grasp pedal and push lightly toward bicycle. 3. Continue pushing while raising pedal into its folded position. 4. The pedal will click into the folded position.
- Page 18 Adjust Seat Height WARNING! • Always tighten fasteners to the correct torque to prevent serious injury or death. Bolts that are too tight can stretch and deform. Bolts that are too loose can move and fatigue. Either condition can lead to a sudden failure of the bolt and result in a crash.
- Page 19 To adjust seat height: • Loosen the seatpost clamp. The open and closed positions of the seatpost clamp are shown below (open position on left, closed position on right); • Raise or lower the seat post in the seat tube; •...
- Page 20 Front and back adjustment: Loosen nuts on both sides of the seat. Make sure the clamp mechanism is clamping on the straight part of the seat rails and is not touching the curved part of the rails. Ensure that you are using the recommended torque on the clamping fastener(s).
- Page 21 Tightening Torque Spec Bottom Bracket 30 Nm Brake Caliper Mounting Bolts 8 Nm Brake Lever Clamp Bolts 6 Nm Crank Bolts 50 Nm Disc Rotor Mounting Bolts 4 Nm Fender Mounting Bolts 4 Nm Headlight Mounting Screw 4 Nm Headset Compression Bolt 4 Nm Kickstand Mounting Bolts 7 Nm...
-
Page 22: Features
Lectric eBike PAS system (e.g. chainring, chainring receptacle, pedals) must only be replaced with identical components or components that have been specifically approved by Lectric eBikes. This should help protect the motor from overloading. • Always remove the battery pack from your Lectric eBike before beginning work (e.g. - Page 23 safety and that of other road users, thus running the risk of high personal liability costs and possibly even criminal prosecution in the event of accidents that can be attributed to manipulation of the bicycle. • Under extreme conditions, such as continuously high loads at low speed when riding up hills or carrying loads, parts of the motor can reach high temperatures.
- Page 24 Mechanical Disc Brakes Your Lectric XP is equipped with mechanical disc brakes. WARNING! To prevent serious injury or death: • ALWAYS apply right brake lever (rear wheel) before and during use of the front brake. • ALWAYS apply even pressure to both brake levers when slowing down or stopping.
- Page 25 Suspension Fork The suspension fork will affect the handling of the bicycle, primarily when going over bumps and stopping. In some situations, it may be advantageous to lock the suspension so it is fully rigid. Check to ensure your suspension fork is properly adjusted for the terrain and your weight.
-
Page 26: Cockpit System
COCKPIT SYSTEM Cockpit Instruments BRAKE LEVERS GEAR SHIFTER DISPLAY CONTROL PAD HALF-TWIST THROTTLE DISPLAY Display Controls PLUS BUTTON POWER BUTTON MINUS BUTTON Overview When does the Pedal Assist activate? Pedal Assist (PAS) functions only when you are pedaling. If you do not pedal, the PAS will not activate. - Page 27 When the bicycle has not been used for 10 consecutive minutes, the display will automatically shut down. The PAS and throttle features will no longer work when the display is OFF. WARNING! To prevent serious injury or death: • Do not allow yourself to be distracted by the display. If you do not concentrate on the traffic around you, you risk being involved in a crash.
- Page 28 Range Estimates The range the bicycle can go on a single battery charge can vary significantly between riders, terrain, wind conditions, user input, and additional cargo weight. The following table shows estimates of potential ranges riders may expect in different conditions. All tests were performed with: •...
- Page 29 Display Functions Walk Mode, Cruise Control, and Pedal assist (PAS) Level Indicator Odometer, Trip A, Voltage, Current, Trip Timer (TM) readouts Battery level indicator bar Maximum and Average Speed Speedometer in MPH or KM/H Light On/Off Indicator Mile and kilometer indicators L E CT R I C E B I K E S.C O M | 602.715.0907...
- Page 30 Battery Level Indicator Bar The “Energy Bar” near the top of the display is your battery indicator and shows the estimated charge level remaining in your battery pack. As the battery charge depletes, the remaining marks will display the approximate remaining charge in the battery pack. The battery display will flash when there is no charge remaining.
- Page 31 Changing setting not listed in the following table may cause your bike to stop working properly. If you need the default setting values of setting not listed, contact Lectric eBikes. DO NOT ride your bicycle until the default settings have been restored.
- Page 32 Setting Function Default Explanation Brightness Backlight display brightness. The darkest level is 1 and the brightest level is 3. Distance 0: KM; 1: MILE. Units Sleep LCD Display sleep timer. The default setting will turn the display OFF after it has not been used for 10 minutes.
- Page 33 Setting Function Default Explanation When set to higher numbers, Strength the motor will come on stronger. Lower numbers will be more gentle. Odometer Hold the plus (+) button for 5 Reset seconds to reset odometer. Walk Mode 0: Walk Mode disabled Toggle 1: Walk Mode enabled Changing Top Speed...
- Page 34 WARNING! ALWAYS check your local laws and regulations to determine if it is lawful to ride Class 3 eBikes on public roads before increasing your bicycle’s top speed. Laws vary by territory, state, trail, path, and road so you will need to check the applicable regulations in each new location you ride.
- Page 35 Passenger Mode Passenger Mode is designed to add an additional level of protection when a passenger is on the bike. Passenger Mode will limit the top speed of your Lectric XP to 10mph. You and your passenger will need to continue to practice caution on the Lectric XP. To engage Lectric “Passenger Mode”: 1.
-
Page 36: Preparing To Ride
Cruise Control Cruise control on your Lectric XP works similarly to cruise control on a car. The bike will try to maintain a speed based on the position of the throttle when cruise control was activated. For example, if the throttle is twisted all the way from its resting position (to a position that would normally maintain 20 mph) and the minus button is held, cruise control will be activated and set at 20 mph. - Page 37 Foot pegs are designed as a footrest only, for use by a passenger while they are sitting on the rear passenger seat. A passenger must always keep both feet on the foot pegs when the bike is in motion. If the passenger cannot always keep contact with the foot pegs, they should ride in an appropriate child seat or should not ride as a passenger on the Lectric XP or XP Step-Thru 3.0.
- Page 38 recommended, which all help ensure hands and feet are kept clear of the moving wheel. • Follow the stated weight limits for the bike and accessories; do not overload Lectric XP or XP Step-Thru 3.0. • Increased weight from a passenger will increase the time it takes to slow the bike when braking.
- Page 39 Thule Yepp Maxi Easyfit child carrier accessory, visit the manufacturer’s website online at www.thule.com and contact Lectric eBikes. WARNING! Children too large or heavy for the Thule Yepp Maxi Easyfit child carrier must have legs long enough to always maintain contact with the foot pegs anytime the bike is in motion.
-
Page 40: Your First Ride
YOUR FIRST RIDE The acceleration of your Lectric eBike may be faster than anticipated, and may feel unusual at first. Before your first ride, you should use the lowest level of pedal assist (PAS 1) and become familiar with the operation of your Lectric eBike by practicing starting, stopping, cornering, and navigating obstacles in a safe environment away from other bicycles, pedestrians, and/or vehicles. -
Page 41: Battery Pack
WARNING! Only use original Lectric eBike batteries for your eBike. Using other batteries can lead to injuries and pose a fire hazard. Lectric eBikes accepts no liability or warranty claims if other batteries are used. To prevent serious injury or death: •... - Page 42 Short circuit damage which occurs in this instance voids any and all warranty claims against Lectric eBikes. L E CT R I C E B I K E S.C O M | 602.715.0907...
- Page 43 • Only charge the battery using original Lectric eBikes chargers. When using chargers that are not made by Lectric eBikes, the risk of fire cannot be excluded. • Use the battery only in conjunction with your Lectric eBike. This is the only way in which you can protect the battery against dangerous overload.
- Page 44 Other types of batteries may burst, causing personal injury and damage. • Only charge Lectric eBikes approved lithium ion battery packs. The battery pack voltage must match the battery pack charging voltage of the charger. Otherwise, there is risk of fire and explosion.
- Page 45 • Do not expose the charger to rain or wet conditions. If water enters a charger, there is a risk of electric shock. • Only use the original Lectric eBikes battery charger supplied with your eBike or one approved for your eBike by the manufacturer and purchased from a trusted source.
- Page 46 Contact Lectric eBikes if you have any questions or to purchase a compatible replacement battery or charger. L E CT R I C E B I K E S.C O M | 602.715.0907...
- Page 47 Battery Charging Information • Check the charger, charger cables, and battery for damage before beginning each charge. • Always charge in a safe area that is cool*, dry, indoors, away from direct sunlight, dirt, or debris, in a clear area away from potential to trip on the charging cords, or for damage to occur to the bike, battery, or charging equipment while parked and/or charging.
- Page 48 • Do not charge or use battery pack if it is damaged. Contact Lectric eBikes to order a replacement. Your bike comes with a 48V lithium- ion battery. The bike’s battery...
- Page 49 *Images are point of view from bottom of bike* To install: 1. Fully insert battery pack into the bicycle frame with the key removed. The locking pin will be retracted. Locking Pin retracted 2. Key position shown: UNLOCKED. Insert the key into the battery through the hole in the bottom of the frame.
- Page 50 When unlocking and removing your battery pack from the frame, take care that it does not slide out while the bicycle is folded. If your battery impacts the ground and is damaged, discontinue use and contact Lectric eBikes immediately. Storing Charging Battery Pack Before and During Storage...
- Page 51 You may replace it yourself by purchasing a replacement battery pack from Lectric eBikes. Storage Conditions If possible, store the battery pack in a dry, well-ventilated place.
- Page 52 Troubleshooting If you have any questions at all regarding the basic troubleshooting below, reach out to Lectric eBikes customer support by email at contact@lectricebikes.com, or call (602) 715-0907. Issue Most Common Solutions Charging indicator lights 1. Check that the cord is connected to the charger.
-
Page 53: Storing Your Lectric Ebike
STORING YOUR LECTRIC EBIKE Please observe storage temperatures for your Lectric eBike. Protect the Drive Unit, Cockpit System, and Battery Pack against extreme temperatures (e.g. from intense sunlight without adequate ventilation). Extreme temperatures can cause the components (especially the battery) to be damaged. TRANSPORTING YOUR LECTRIC EBIKE WARNING! To prevent serious injury or death:... -
Page 54: Troubleshooting
TROUBLESHOOTING If you have any questions at all regarding the basic troubleshooting below, reach out to Lectric eBikes customer support by email at contact@lectricebikes.com, or call (602) 715-0907. Issue Most Common Solutions Bicycle will not turn ON. 1. Charge the battery until the light on the charger turns from red to green. -
Page 55: Maintenance
Error Codes The components of your Lectric eBike are continuously monitored automatically. If a fault is detected, the corresponding error code will appear on the display. Error Code Meaning Most Common Solution Check PAS quick plug E003 PAS Sensor Fault E006 Battery Undervoltage Fully charge battery... - Page 56 Tampering can void your warranty and render your bicycle noncompliant with the applicable laws and regulations. Lectric eBikes is not responsible for any direct, incidental, or consequential damages. This includes, without limitation, damages for personal injury, property damage or economic losses due to tampering.
- Page 57 Tune-Ups 100 Mile Tune-Up After 100 miles, or 5 full battery charge cycles, have the following services performed at a bicycle shop: • Brake cables may need to be adjusted and tensioned properly. • Shifting cables will stretch during the wear-in period. The derailleur may need to be adjusted.
-
Page 58: Legal
LEGAL Warranty LECTRIC EBIKES WARRANTS TO THE ORIGINAL REGISTERED PURCHASER THAT LECTRIC eBIKES SHALL BE FREE FROM ALL DEFECTS IN MATERIAL AND WORKMANSHIP FOR A PERIOD OF ONE YEAR FROM THE DATE OF PURCHASE. DISCLAIMER OF CONSEQUENTIAL AND INCIDENTAL DAMAGES: THE... - Page 59 Lectric eBikes will replace any parts deemed to have been damaged during shipping. Shipping damage must be reported to Lectric eBikes within 14 days of shipment arrival. This applies to all products, including bikes and accessories.
- Page 60 Lectric eBikes reserves the right to change its warranty at any time and without notice. Any action, lawsuit or other proceeding, under this warranty or otherwise related to the bike must be commenced within ninety (90) days after expiration of the one-year warranty period.
- Page 61 Under no circumstances is Lectric eBikes responsible for any damage resulting from damaged, defective, or improperly secured parts. This includes, but is not limited to, damage to personal property, personal injury, or death. This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions: 1.
- Page 62 This equipment should be installed and operated with a minimum distance of 5 mm between the device and the user or bystanders. This device must not be co-located or operating in conjunction with any other antenna or transmitter. L E CT R I C E B I K E S.C O M | 602.715.0907...
- Page 63 L E CT R I C E B I K E S.C O M | 602.715.0907...
- Page 64 The latest version of your manual is available at lectricebikes.com/manual...
Need help?
Do you have a question about the XP 3.0 and is the answer not in the manual?
Questions and answers
How do you turn on the standard headlight and brake light for night riding?
To turn on the standard headlight and brake light on the Lectric XP 3.0 for night riding, first, make sure the bike is powered on by pressing the power button. Once the display is on, hold the "+" button on the handlebar control until the light symbol appears on the display. This indicates that the lights are on. The headlight will provide a forward beam, and the brake light will activate when braking.
This answer is automatically generated
@Jan Hangen Do the keys need to be engaged for the battery to work
Battery fully charged, key in on position, bike will not start, LED display doesn't light up.
If a Lectric XP 3.0 bike won't start, the LED display doesn't light up, and the battery is fully charged with the key in the on position, possible issues could include:
1. A damaged or disconnected display or plug.
2. The battery output is below 42 volts despite appearing fully charged.
3. The controller plate may not be properly installed or connected.
4. The electrical components may be damaged or affected by water (not waterproof).
5. The bike may have entered auto shut-off mode after 10 minutes of inactivity.
Check the display and plug for damage, verify battery voltage with a multimeter, and ensure all components are properly connected.
This answer is automatically generated
throttle does not work when I turn it
Possible reasons the throttle is not working on the Lectric eBikes XP 3.0 include:
1. The display is OFF — PAS and throttle features will not function.
2. The battery is low or not charged — PAS and throttle will not work.
3. Cruise Control is not properly activated — it requires holding the minus (-) button while twisting the throttle.
4. Loose or damaged connections — check the discharge plate, controller connections, and look for carbon deposits or poor solder joints.
5. The controller or display unit may be faulty and need replacement.
Check all connections, clean any carbon deposits, and repair or replace damaged components as needed.
This answer is automatically generated
My XP3.0 has an issue with clamping tight enough to hold the seat post in place. The clamp has ID. mark "R40" on it. Currently the bike cannot be riden
If the seat post clamp on a Lectric eBikes XP 3.0 is not holding tight enough, ensure the seatpost is inserted past the minimum insertion point, and tighten the seatpost collar and clamp to 18 Nm or until it leaves an impression on your hand.
This answer is automatically generated
The key will only turn clockwise so I have not been able to turn the bike on. Any suggestions on how to get the key to turn?
The key on a Lectric eBikes XP 3.0 is designed to turn clockwise to move between positions such as OFF and ON. If the key only turns clockwise and does not turn back, this may be normal operation depending on the position. To remove the battery, follow these steps in reverse:
1. Turn the key to the OFF position (one click counterclockwise from ON).
2. Push and hold the frame latch.
3. Pull the battery out of the frame.
4. Remove the key from the battery.
If the key physically cannot turn counterclockwise or feels stuck, inspect for dirt or damage in the key slot or locking pin area. If damaged, the lock mechanism may need service or replacement.
This answer is automatically generated
I have charged the battery and tried to get my bike to run but when I push the power button the display lights up and goes back out within two seconds. Am I doing something wrong?
If the display on your Lectric eBikes XP 3.0 lights up and then goes out after pressing the power button, follow these steps:
1. Check the battery charge level and fully charge the battery, as low voltage may cause the display to turn off.
2. Inspect the display quick plug connection to ensure it is secure.
3. If possible, test the display by swapping it with a working display from another XP 3.0 bike. If the display works on the other bike, the issue may be with the display unit.
4. If the display does not work on either bike, continue troubleshooting other components such as the controller or battery.
Always remove the battery before performing inspections or maintenance.
This answer is automatically generated
how do I check/replace Hall Sensor board on a lectric XP mid drive 3.0. and where is it located.
To check or replace the Hall Sensor board on a Lectric XP 3.0:
1. Location: The Hall Sensor board is located inside the motor hub.
2. Checking the Sensor:
- Use a voltage meter to test the Hall sensors.
- Connect the bike to power.
- Identify the Hall sensor wires (typically red for power, black for ground, and three signal wires—often blue, green, yellow).
- With the motor slowly rotated by hand, check for voltage changes (usually 0V to 5V) on each signal wire relative to ground.
3. Replacing the Board:
- Open the motor hub carefully.
- Desolder the old Hall sensor board from the internal wiring.
- Solder in the new Hall sensor board, ensuring clean and secure connections.
- Reassemble the hub and test the motor function.
Note: If unsure about soldering or diagnostics, it may be more effective to replace the motor or use a diagnostic tool.
This answer is automatically generated
How do I turn the bike on?
To turn on the Lectric XP 3.0 bike:
1. Insert the key and turn it to the "on" position to secure the battery and enable power.
2. Go to the handlebars and press and hold the power button to activate the display and enter riding mode.
This answer is automatically generated
I cannot fold the bike, the OPEN does not move
To fix a stuck folding mechanism on a Lectric eBike XP 3.0:
1. Check if the latch is fully pushed down and locked. Pull on it to confirm it's secure.
2. To unlock and fold the bike:
- Slide the switch labeled “open” to the right.
- While holding the switch in the “open” position, pull the latch.
- Fold the bike once the latch is released.
Ensure no cables or parts are blocking the hinge, and check for any damage or misalignment.
This answer is automatically generated
I cannot fold the bike
To fold the Lectric eBikes XP 3.0:
1. Slide the switch labeled “open” to the right.
2. While holding the switch in the “open” position, pull the latch.
3. Fold the bike frame.
4. For the pedals, grasp each pedal, push lightly toward the bicycle, then raise it into its folded position until it clicks.
Optionally, use the provided Velcro strap to loop through the wheels and secure them together when folded.
This answer is automatically generated
