Lectric eBikes XPedition 1.0 Owner's Manual

Hide thumbs

Advertisement

Table of Contents

OWNERS MANUAL
Lectric XPedition 1.0
V 1.0 | 2023
www.lectricebikes.com
602.715.0907
To prevent PROPERTY DAMAGE, SERIOUS INJURY, or DEATH,
you should read, understand, and follow the warnings and
instructions in this manual. Keep for future reference.
L E CT R I C E B I K E S.C O M | 602.715.0907
1

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the XPedition 1.0 and is the answer not in the manual?

Questions and answers

Related Manuals for Lectric eBikes XPedition 1.0

Summary of Contents for Lectric eBikes XPedition 1.0

  • Page 1 OWNERS MANUAL Lectric XPedition 1.0 V 1.0 | 2023 www.lectricebikes.com 602.715.0907 To prevent PROPERTY DAMAGE, SERIOUS INJURY, or DEATH, you should read, understand, and follow the warnings and instructions in this manual. Keep for future reference. L E CT R I C E B I K E S.C O M | 602.715.0907...

  • Page 2: Table Of Contents

    For replacement parts and accessories, you should always use Storing Your Lectric eBike Lectric eBikes approved parts, as they have been specially Transporting Your Lectric eBike designed for your bicycle and manufactured to meet Lectric eBikes’ Disposal of Your Lectric eBike demanding standards. Troubleshooting This manual should be considered a permanent part of your bicycle and should remain with the bicycle when it is sold.

  • Page 3: Important Safety Information

    IMPORTANT SAFETY INFORMATION Intended Use The intended use of your Lectric eBike is to be ridden by one adult Read and Understand Owner’s Manual Before Riding rider (age 18 and up) at an appropriate time and place for general transportation and/or recreational use. Any other use is prohibited Read this entire Owner’s Manual before you take the first ride on your and may result in SERIOUS INJURY or DEATH.
  • Page 4 However, there may be local your bicycle, contact Lectric eBikes at contact@lectricebikes.com differences such as where you can ride, minimum rider age, or or call (602) 715-0907.
  • Page 5 • Look ahead and brake sooner. You may be moving faster on your eBike, and it may be heavier compared to a bicycle, which means you may need to react and brake sooner when riding. Other road users may not expect you to be traveling at higher speeds. Riding faster may increase your risk of a crash.
  • Page 6 Check that the seat post is inserted past the minimum insertion point. The minimum insertion point is labeled Lectric eBikes recommends going through each item on the pre-ride on the seat post. safety checklist before and after each ride. Spending time to make Check that the seat post collar and clamp are closed sure all of the bike’s components are in good working order before a...
  • Page 7 There are warning labels on your Lectric eBike for your protection. the consequences of failure to maintain or inspect your bicycle and If a label is missing or is not legible, contact Lectric eBikes of failure to follow safe cycling practices.
  • Page 8 On-Product Warning Tags There are warning tags on your Lectric eBike for your protection. If a tag is missing or is not legible, contact Lectric eBikes for a replacement. WARNING HELMET WARNING TAG WARNING: ALWAYS WEAR A HELMET WHILE RIDING A BIKE. FAILURE WARNING TO DO SO COULD RESULT IN SERIOUS INJURY AND/OR DEATH.

  • Page 9: Getting Started

    2 Battery Keys per battery If anything is missing or is damaged, contact Lectric eBikes immediately for assistance. For a video about how to setup your bicycle, visit our YouTube page: Lectric eBikes, youtube.com/LectriceBikes L E CT R I C E B I K E S.C O M | 602.715.0907...
  • Page 10 How to Unfold the Stem How to Remove and Insert Pedals To unfold and secure in riding position: Removing Pedals 1. Begin with handlebars in the folded down position. 2. Simply unfold the stem upward and press the latch inward until there is an audible click.
  • Page 11 Folding and Unfolding the Stem How to Unlock the Stem Lever 1. Push the stem safety button up, toward the LCD display. How to Fold the Stem 2. Keep the safety button pushed, as you pull the stem lever away To fold the stem down: from the stem.
  • Page 12 Handlebar Adjustments Adjust Seat Height To adjust your handlebars: WARNING! 1. Once your stem lever is unlocked, you may adjust the orientation of • Always tighten fasteners to the correct torque to prevent serious the handlebars and adjust the angle of the stem. injury or death.
  • Page 13 To adjust seat height: Adjust Seat Position • Loosen the seat post clamp. The open and closed positions of the WARNING! seat post clamp are shown below (open position on left, closed position on right); Always tighten fasteners to the correct torque to prevent serious •...
  • Page 14 Charge Battery Before First Use Tightening Torque Locate charging port on the side of the battery pack. Use this port to Part Tool Spec charge when battery pack is installed or not installed. Bottom Bracket ISIS spline tool (171-00517) 40 Nm Brake Caliper Mounting Bolts 5mm allen 10 Nm...

  • Page 15: Features

    To shift down: components or components that have been specifically approved Push the upper lever marked with the minus (-) away from you by Lectric eBikes. This should help protect the motor from overloading. (forward). • Always remove the battery pack from your Lectric eBike before beginning work (e.g.
  • Page 16 Hydraulic Disc Brakes Throttle Your Lectric XPedition is equipped with hydraulic disc brakes. The right handlebar features a half-twist throttle. WARNING! To operate: Check that the Pedal Assist (PAS) level is set above 0, then twist the To prevent serious injury or death: throttle back slowly to achieve your desired speed and acceleration.

  • Page 17: Cockpit System

    COCKPIT SYSTEM Overview Cockpit Instruments When does the Pedal Assist activate? Pedal Assist (PAS) functions only when you are pedaling. If you do not pedal, the PAS will not activate. The motor output always BRAKE LEVERS depends on your pedaling and the PAS level you have set. PAS automatically switches off at the maximum speed set for your Lectric eBike (up to 28 mph).
  • Page 18 Display Functions WARNING! To prevent serious injury or death: • Do not allow yourself to be distracted by the display. If you do not concentrate on the traffic around you, you risk being involved in a crash. If you want to change any settings other than the PAS level, always stop before changing the settings or display.
  • Page 19 Battery Level Indicator Bar Range Estimates The “Energy Bar” near the top of the display is your battery indicator The range the bicycle can go on a single battery charge can vary and shows the estimated charge level remaining in your battery pack. significantly between riders, terrain, wind conditions, user input, and additional cargo weight.
  • Page 20 If you need the more crank rotations for the motor to turn default value of a setting not listed, contact Lectric eBikes. DO NOT ON. Lower numbers will take fewer crank ride your bicycle until the default settings have been restored.
  • Page 21 Setting Function Default Explanation WARNING! Odometer ALWAYS check your local laws and regulations to determine if it is Hold the plus (+) button for 5 seconds to Reset reset odometer. lawful to ride Class 3 eBikes on public roads before increasing your bicycle’s top speed.

  • Page 22: Preparing To Ride

    • Do not exceed the load limit of the rear cargo rack or optional Pull either brake lever to disengage Walk Mode OR press and hold the console attachment. The Lectric XPedition 1.0 rear cargo rack minus (-) button on the display control pad.
  • Page 23 Lectric XPedition 1.0. on the Lectric XPedition 1.0. Do not stand on or otherwise misuse • Increased weight from a passenger will increase the time it foot platform, or damage to the product, serious injury, and/or takes to slow the bike when braking.

  • Page 24: Your First Ride

    If they cannot always on the Lectric XPedition 1.0 unless seated in a properly fitted and maintain contact with the foot pegs when the bike is in motion, they approved child safety seat.

  • Page 25: Battery Pack

    • Do not engage Walk Mode when riding or sitting on your Lectric batteries can lead to injuries and pose a fire hazard. Lectric eBikes accepts no liability or warranty claims if other batteries are used. eBike. Holding the minus (-) button will engage the motor up to a walking speed.
  • Page 26 • Only charge the battery using original Lectric eBikes chargers. Lectric eBikes immediately. When using chargers that are not made by Lectric eBikes, the risk of fire cannot be excluded. • Do not puncture or crush the battery pack. Do not impact the battery pack or modify it in any way.
  • Page 27 Locate the charge port on the side of the battery. You can charge the • Only use the original Lectric eBikes battery charger supplied with battery from this port while the battery is in or out of the bicycle.
  • Page 28 Contact Charger Manufacturer Lectric eBikes if you have any questions or to purchase a compatible • Charger made by: Wuxi Dpower Electric Co., Ltd. replacement battery or charger.
  • Page 29 • Do not charge or use battery pack if it is damaged. Contact of your Lectric eBike battery is within the permitted charging Lectric eBikes to order a replacement. temperature range. Your bike comes with a 48V lithium-ion battery. The bike’s battery...
  • Page 30 Corroded terminals have higher resistance, which in turn can lead to an increased risk of fire. If you notice your battery terminals are corroded, discontinue use and contact Lectric eBikes. Removing Rear Battery NOTE: If using dual batteries, remove the rear battery before removing the front battery.
  • Page 31 You may replace it yourself by purchasing a replacement battery pack from Lectric eBikes. L E CT R I C E B I K E S.C O M | 602.715.0907...
  • Page 32 If you have any questions at all regarding the basic troubleshooting If possible, store the battery pack in a dry, well-ventilated place. below, reach out to Lectric eBikes customer support by email at Protect it from moisture and water. contact@lectricebikes.com, or call (602) 715-0907.

  • Page 33: Storing Your Lectric Ebike

    If you have any questions at all regarding the basic troubleshooting Protect the Drive Unit, Cockpit System, and Battery Pack against below, reach out to Lectric eBikes customer support by email at extreme temperatures (e.g. from intense sunlight without adequate contact@lectricebikes.com, or call (602) 715-0907.

  • Page 34: Maintenance

    MAINTENANCE Error Codes You should have your bicycle maintained at regular service intervals The components of your Lectric eBike are continuously monitored at your local bicycle shop. automatically. If a fault is detected, the corresponding error code will appear on the display. WARNING! Error Code Meaning...
  • Page 35 Lectric eBikes is not responsible • All hardware should be adjusted to the specified values, found in for any direct, incidental, or consequential damages. This includes, “Tightening Torque”...

  • Page 36: Legal

    LEGAL hot, or cold conditions may void the warranty. Lectric eBikes will replace any parts deemed to have been damaged Warranty during shipping. Shipping damage must be reported to Lectric eBikes LECTRIC EBIKES WARRANTS TO THE ORIGINAL REGISTERED within 14 days of shipment arrival. This applies to all products, PURCHASER THAT LECTRIC eBIKES SHALL BE FREE FROM ALL including bikes and accessories.
  • Page 37 Lectric eBikes reserves the right to change its warranty at any time Under no circumstances is Lectric eBikes responsible for any and without notice. damage resulting from damaged, defective, or improperly secured parts. This includes, but is not limited to, damage to personal Any action, lawsuit or other proceeding, under this warranty or property, personal injury, or death.
  • Page 38 This equipment should be installed and operated with a minimum distance of 5 mm between the device and the user or bystanders. This device must not be co-located or operating in conjunction with any other antenna or transmitter. L E CT R I C E B I K E S.C O M | 602.715.0907 L E CT R I C E B I K E S.C O M | 602.715.0907...
  • Page 39 The latest version of your manual is available at lectricebikes.com/manual...
