- Page 1 Operator's Manual Supplement Lift Tools™ Expo Installer First Edition Third Printing Part No. 1286259GT...
- Page 2 Genie boom product other than the designated models. Copyright © 2018 by Terex Corporation First Edition: Third Printing, July 2019 Genie is registered trademarks of Terex South Dakota, Inc. in the U.S.A. and many other countries. These machines comply with ANSI/SAIA A92.20 CAN/CSA B.354.6...
- Page 3 First Edition • Third Printing Operator's Manual Supplement Introduction Genie Self-propelled Boom Genie Self-propelled Booms may be used to lift under the following guidelines: Products and Lift Tools Expo The owner/employer/user/operator of the Installer (LTEI) Guidance boom is responsible for providing fall protection for boom operator.
- Page 4 A person trained in the operation of the Genie Terex USA and its parent and affiliated companies boom shall remain on the ground near the against any and all liabilities, claims, suits, losses,...
- Page 5 First Edition • Third Printing Operator's Manual Supplement Introduction The LTEI can only be used on Genie Booms equipped with the following 6 ft/1.83 m or 8 ft/ 2.44 m platforms: Standard entry platforms manufactured from January, 2003 Danger Failure to obey the instructions and safety rules in this manual will result in death or serious injury.
- Page 6 Operator's Manual Supplement First Edition • Third Printing Introduction LTEI Safety The LTEI shall not be used with machines equipped with the following: Read, understand and obey all warnings and Panel cradle option instructions provided with the LTEI. Traveling Fall Arrest Anchor System Do not exceed the rated platform capacity.
-
Page 7: Symbol And Hazard Pictorials Definitions
First Edition • Third Printing Operator's Manual Supplement Introduction Symbol and Hazard Pictorials Pre-operation Inspection Definitions Be sure that the operator’s, safety manual, responsibilities manual and any necessary LTEI system weighs supplements are complete, legible and in the 84 lbs/38.1 kg storage container located in the platform. -
Page 8: Annual Inspection
Operator's Manual Supplement First Edition • Third Printing Introduction Annual Inspection Inspect for missing or loose components. Check all fasteners for proper torque. Refer to the installation instructions section of this document for the torque specifications. Inspect all components for damage or wear. Check for cracks, bends and corrosion. -
Page 9: Observe And Obey
First Edition • Third Printing Operator's Manual Supplement Operating Instructions Operating Instructions Do not cause a horizontal force due to a sign that is caught, snagged or otherwise prevents normal motion.Maximum wind speed: 0 mph/0 m/sec. Before elevating a sign, the area shall be marked to warn of work being performed by personnel. -
Page 10: Tip-Over Hazards
Operator's Manual Supplement First Edition • Third Printing Operating Instructions Suspended Load Hazards Be sure that the operator keeps the load vertical under the lifting point.Do not adjust the Work Area Safety length of the suspension element during movement or lifting operations. General Safety ... - Page 11 First Edition • Third Printing Operator's Manual Supplement Operating Instructions Identify the proper lifting points of the load, taking Only lift a load vertically; do not pull a load into consideration the center of gravity and load horizontally as it could cause excessive swinging of stability.
-
Page 12: Installation Instructions
Operator's Manual Supplement First Edition • Third Printing Installation Instructions Installation Instructions Before Starting Installation Contents of Kit 1285719 Read, understand and obey the safety rules For use with 6 ft / 1.83 m platforms with and operating instructions in the appropriate word decals. - Page 13 First Edition • Third Printing Operator's Manual Supplement Installation Instructions Contents of Kit 1286618 Contents of Kit 1288801 For use with 6 ft / 1.83 m platforms with For use with 8 ft / 2.44 m platforms with symbol decals. word decals.
- Page 14 Operator's Manual Supplement First Edition • Third Printing Installation Instructions Contents of Kit 1288803 For use with 8 ft / 2.44 m platforms with symbol decals. Part Description Genie Part Qty. Number (1) Spacer 1256481 (2) Screw, 3/8-16 x 2.5 ** 1256856 (3) Flange nut, 3/8-16** 1274322...
- Page 15 First Edition • Third Printing Operator's Manual Supplement Installation Instructions Lift Tools™ Expo Installer Part No. 1286259GT First Edition • Third Printing Operator's Manual Supplement ™ Part No. 1286259GT Lift Tools Expo Installer...
