A
C H A P T E R
Disk Drive Insertion
This appendix describes how to properly insert a disk drive into a controller or
expansion tray.
Drives are inserted with the power on, unless specifically instructed not to by Sun
technical support.
The correct way to insert a disk drive into the tray is as follows:
1. Lift the drive handle up to open it.
2. Push the disk drive into the chassis by slowly pushing against the drive housing
until the drive handle engages with the chassis.
3. When the handle starts to move itself downwards, push the disk drive handle
down. This will crank the disk drive the rest of the way into the chassis.
FIGURE A-1
shows a drive being inserted into the chassis the correct way.
35
