Page 1 Sun Fire™ 6800/4810/4800/3800 Systems Service Manual Sun Microsystems, Inc. 901 San Antonio Road Palo Alto, CA 94303 U.S.A. 650-960-1300 Part No. 805-7363-11 April 2001, Revision Send comments about this document to: docfeedback@sun.com...
Page 2 Sun, Sun Microsystems, the Sun logo, AnswerBook2, docs.sun.com, Sun Fire, and Solaris are trademarks, registered trademarks, or service marks of Sun Microsystems, Inc. in the U.S. and other countries. All SPARC trademarks are used under license and are trademarks or registered trademarks of SPARC International, Inc.
Page 3: Table Of Contents
Contents Preface xix Safety and Tools Requirements 1-1 Safety Precautions 1-1 Symbols 1-2 System Precautions 1-3 Filler Boards and Filler Panels 1-4 Tools Required 1-4 Powering Off and On 2-1 Powering Off the System 2-1 Powering On the System 2-6 CPU/Memory Boards and Components 3-1 Handling Boards and Assemblies 3-1 Filler Panels and Filler Boards 3-3...
Page 4 Resetting the System Controller Board 6-9 6.2.4 Replacing a System Controller Board 6-9 Repeater Board 7-1 Handling Boards and Assemblies 7-1 Filler Boards 7-2 Repeater Board 7-2 7.3.1 Replacing Repeater Boards 7-7 Sun Fire 6800/4810/4800/3800 Systems Service Manual • April 2001...
Page 5 Power Supply Slot Locations 8-3 8.1.2 Power Supply LEDs 8-7 8.1.3 Replacing a Sun Fire 6800/4810 System Power Supply 8-7 8.1.4 Replacing a Sun Fire 4800 System Power Supply 8-9 8.1.5 Replacing a Sun Fire 3800 System Power Supply 8-10 AC Input Box 8-12 8.2.1...
Page 6 Removing the LED Board 10-40 10.5.2 Installing the LED Board 10-42 10.6 Replacing ID Source Boards 10-43 10.6.1 Removing the ID Source Board From the Sun Fire 6800 System 10-43 10.6.2 Installing the ID Source Board in the Sun Fire 6800 System 10-44 10.6.3...
Page 7 FrameManager LEDs 12-2 12.3 Replacing the FrameManager 12-2 A. Functional Description A-1 System Overview A-1 System Packaging A-2 A.2.1 Sun Fire 6800 System A-2 A.2.2 Sun Fire 4810 System A-4 A.2.3 Sun Fire 4800 System A-5 A.2.4 Sun Fire 3800 System A-6 Software A-8 A.3.1...
Page 8 Sun Fire 3800 System Replacement Parts C-9 C.2.5 CPU/Memory Board Replacement Parts C-11 C.2.6 I/O Assembly Replacement Parts C-12 C.2.7 Repeater Board Replacement Part C-14 C.2.8 System Controller Board C-15 C.2.9 Power Supply Replacement Parts C-16 viii Sun Fire 6800/4810/4800/3800 Systems Service Manual • April 2001...
Page 9 C.2.10 Filler Boards and Filler Panels Replacement Parts C-18 C.2.11 Cables Replacement Parts C-19 Glossary Glossary-1 Index Index-1 Contents...
Page 10 Sun Fire 6800/4810/4800/3800 Systems Service Manual • April 2001...
Page 11 CPU/Memory Board Slot Assignments—Sun Fire 3800 System—Front View 3-7 FIGURE 3-5 Unlocking the Ejector Levers 3-8 FIGURE 3-6 Removing or Replacing a CPU/Memory Board—Sun Fire 6800 System 3-9 FIGURE 3-7 Removing and Replacing a CPU/Memory Board—Sun Fire 3800 System 3-10 FIGURE 3-8...
Page 12 Removing and Replacing a Repeater Board—Sun Fire 6800 System 7-9 FIGURE 7-6 Power Supply Locations—Sun Fire 6800 System—Front View 8-3 FIGURE 8-1 Power Supplies in Power Grid 0 and Power Grid 1—Sun Fire 6800 System 8-4 FIGURE 8-2 Power Supply Locations—Sun Fire 4800 System—Front View 8-5 FIGURE 8-3...
Page 13 Cabinet Fan Tray Top Plate 9-11 FIGURE 9-9 Removing the Door—Sun Fire 6800 System 10-2 FIGURE 10-1 Removing All Components From the Front of the Sun Fire 6800 System 10-3 FIGURE 10-2 Removing the Bus Bar Access Panels 10-3 FIGURE 10-3 Loosening the Bus Bar Captive Screws—Sun Fire 6800 System 10-4...
Page 14 FIGURE 10-5 Removing the Screws Securing the System Centerplane—Sun Fire 6800 System 10-5 FIGURE 10-6 Moving the System Centerplane Forward Off the Guide Pins—Sun Fire 6800 System 10-6 FIGURE 10-7 Removing the System Centerplane—Sun Fire 6800 System 10-6 FIGURE 10-8...
Page 15 Disconnecting the LED Cable From the Centerplane—Sun Fire 3800 System 10-41 FIGURE 10-36 Remove IB9 I/O Assembly—Sun Fire 6800 System 10-43 FIGURE 10-37 Removing the ID Source Board From the Centerplane—Sun Fire 6800 System 10-44 FIGURE 10-38 Removing IB8 I/O Assembly—Sun Fire 4810 System 10-45 FIGURE 10-39 Removing the ID Source Board From the Centerplane—Sun Fire 4810 System 10-46...
Page 16 System Controller Board—Sun Fire 3800 System C-15 FIGURE C-13 Sun Fire 6800/4810 Systems Power Supply C-16 FIGURE C-14 Sun Fire 3800 System Power Supply C-17 FIGURE C-15 Sun Fire 4800 System Power Supply C-17 FIGURE C-16 Sun Fire 6800/4810/4800/3800 Systems Service Manual • April 2001...
Page 17: Filler Boards
Tables Typographic Conventions xx TABLE P-1 Safety Precautions 1-1 TABLE 1-1 Symbols 1-2 TABLE 1-2 Overheating Precautions Using Filler Boards 1-4 TABLE 1-3 CPU/Memory Board LED Functions 3-3 TABLE 3-1 CPU/Memory Board Slot Locations 3-5 TABLE 3-2 Description of the PCI I/O Assembly 4-3 TABLE 4-1 Location of the I/O Assemblies 4-3 TABLE 4-2...
Page 18 TABLE A-4 I/O Assemblies A-14 TABLE A-5 Number of Fan Trays, CPU Fan Trays, and Blower Assemblies A-17 TABLE A-6 Overheating Precautions Using Filler Panels and Filler Boards B-8 TABLE B-1 xviii Sun Fire 6800/4810/4800/3800 Systems Service Manual • April 2001...
Page 19: Preface
Preface This book describes how to remove and install field-replaceable units (FRUs) that are part of the system. For example, how to remove and install boards, cards, assemblies, and modules are covered in this book. This book also presents a functional description of the systems.
Page 20: Typographic Conventions
These are called class options. You must be superuser to do this. AaBbCc123 Command-line variable; To delete a file, type rm filename. replace with a real name or value Sun Fire 6800/4810/4800/3800 Systems Service Manual • April 2001...
Page 21: Related Documentation
Sun Fire 6800/4810/4800/3800 Systems Overview Manual 805-7362 Software Sun Fire 6800/4810/4800/3800 Systems Platform Administration Manual 805-7373 Sun Fire 6800/4810/4800/3800 Systems Controller Command Reference Manual 805-7372 Accessing Sun Documentation Online The docs.sun.com web site enables you to access Sun technical documentation on the Web.
Page 22: Sun Welcomes Your Comments
For system compliance class and conformity information, refer to the system installation guide that came with your system. xxii Sun Fire 6800/4810/4800/3800 Systems Service Manual • April 2001...
Page 23 United States Export Control Laws Notice Product covered by and information contained in this service manual are controlled by U.S. Export Control laws and may be subject to the export or import laws in other countries. Nuclear, missile, chemical biological weapons, or nuclear maritime end uses or end users, whether direct or indirect, are strictly prohibited.
Page 24 Sun Fire 6800/4810/4800/3800 Systems Service Manual • April 2001...
Page 25: Safety And Tools Requirements
C H A P T E R Safety and Tools Requirements This chapter describes the safety and system precautions you must take when servicing the system. It also lists the tools and equipment you will need. Safety Precautions For your protection, observe the following safety precautions when setting up your equipment: Follow all cautions, warnings, and instructions marked on the equipment.
Page 26: Symbols
Component is activated when the green activated LED on the ACTIVATED system component is lit. OK TO You can safely remove board or component from the system when REMOVE the OK to remove LED (amber) is lit. Sun Fire 6800/4810/4800/3800 Systems Service Manual • April 2001...
Page 27: System Precautions
Use only properly grounded power outlets as described in the installation guides. Caution – DO NOT make mechanical or electrical modifications to the system or the cabinet. Sun Microsystems™ is not responsible for regulatory compliance of modified cabinets. Caution – The chassis AC power cord(s) must remain connected to ensure a proper ground.
Page 28: Filler Boards And Filler Panels
For the procedures in this document, you will need these tools: Screwdriver, Phillips #2 Screwdriver, Phillips #2 with six-inch shank Needlenose pliers ESD mat ESD grounding wrist strap or foot strap Sun Fire 6800/4810/4800/3800 Systems Service Manual • April 2001...
Page 29: Powering Off And On
1. If your Sun Fire 4810/4800/3800 system is not in a Sun Fire cabinet, skip this step. For Sun Fire 6800 system or Sun Fire 4810/4800/3800 systems mounted in a Sun Fire cabinet, turn the keyswitch on the FrameManager to the off position...
Page 30: Figure 2-2 Ac Input Boxes-Sun Fire 6800 System-Rear View
The Sun Fire 3800 system does not have an AC input box. AC input box AC input box AC Input Boxes—Sun Fire 6800 System—Rear View FIGURE 2-2 AC input box AC Input Box—Sun Fire 4810 System—Front View FIGURE 2-3 Sun Fire 6800/4810/4800/3800 Systems Service Manual • April 2001...
Page 31: Figure 2-4 Ac Input Box-Sun Fire 4800 System-Rear View
AC input box AC Input Box—Sun Fire 4800 System—Rear View FIGURE 2-4 Chapter 2 Powering Off and On...
Page 32: Figure 2-5 Sun Fire 3800 System Power Supplies-Rear View
( FIGURE 2-5 Power switch Power supply Sun Fire 3800 System Power Supplies—Rear View FIGURE 2-5 4. Turn off the redundant transfer switches (RTS) ( FIGURE 2-6 FIGURE 2-7 Sun Fire 6800/4810/4800/3800 Systems Service Manual • April 2001...
Page 33 System rear System front Redundant Transfer Switches (RTS)—Sun Fire 6800 System FIGURE 2-6 System rear Redundant Transfer Switches (RTS)—Sun Fire 4810 System FIGURE 2-7 Chapter 2 Powering Off and On...
Page 34: Powering On The System
Powering On the System 1. If your Sun Fire 4810/4800/3800 system is not in a Sun Fire cabinet, skip to Step 3. For the Sun Fire 6800 system or Sun Fire cabinet, turn on the RTS modules on page 8-18 and on page 8-18).
Page 35: Cpu/Memory Boards And Components
C H A P T E R CPU/Memory Boards and Components To protect both yourself and the equipment, make sure you follow the precautions in Chapter 1. This chapter contains the following sections: Section 3.1 “Handling Boards and Assemblies” on page 3-1 Section 3.2 “Filler Panels and Filler Boards”...
Page 36 Note – The CPU/Memory board can be inserted into a powered-on system. The board will not be recognized by the system until the domain has been re-initialized and rebooted. Refer to the Sun Fire 6800/4810/4800/3800 Systems Platform Administration Manual for complete procedures for initializing a domain.
Page 37: Filler Panels And Filler Boards
Filler Panels and Filler Boards See Section 1.4 “Filler Boards and Filler Panels” on page 1-4 for procedures you must follow when removing CPU/Memory boards from a system in order to prevent the system from overheating. 3.2.1 CPU/Memory Boards All systems support the following: Up to four CPU processors with each CPU processor supporting two DIMM (dual inline memory module) banks of four DIMMs per bank Up to eight Ecache modules (two per CPU processor)
Page 38: Figure 3-1 Cpu/Memory Board With The Cover Installed
CPU processor 0 land area CPU processor 3 land area CPU processor 2 land area Ejector lever Activated LED (green) Fault LED (amber) LED (amber) (for future use) Ejector lever DIMMs Sun Fire 6800/4810/4800/3800 Systems Service Manual • April 2001...
Page 39 SB0, SB2 Front , and illustrate the slot numbers for the FIGURE 3-2 FIGURE 3-3 FIGURE 3-4 FIGURE 3-5 CPU/Memory boards for all systems. CPU/Memory Board Slot Assignments—Sun Fire 6800 System—Front View FIGURE 3-2 Chapter 3 CPU/Memory Boards and Components...
Page 40: Figure 3-3 Cpu/Memory Board Slot Assignments-Sun Fire 4810 System-Front View
CPU/Memory Board Slot Assignments—Sun Fire 4810 System—Front View FIGURE 3-3 CPU/Memory Board Slot Assignments—Sun Fire 4800 System—Rear View FIGURE 3-4 Sun Fire 6800/4810/4800/3800 Systems Service Manual • April 2001...
Page 41: Replacing Cpu/Memory Boards
CPU/Memory Board Slot Assignments—Sun Fire 3800 System—Front View FIGURE 3-5 3.2.2 Replacing CPU/Memory Boards Note – Before you begin this procedure, make sure that all fan trays are installed in the system and are operating normally. The fan trays cool the CPU/Memory boards. For more information on fan tray cooling, see Chapter 9.
Page 42: Figure 3-6 Unlocking The Ejector Levers
1. Prepare the system to remove the CPU/Memory board. Refer to the Sun Fire 6800/4810/4800/3800 Systems Platform Administration Manual for complete procedures for powering off the board. 2. Be sure that you have a filler board, filler panel, or replacement board ready.
Page 43: Figure
This action unseats the board from the connector. 7. Remove the CPU/Memory board. For the Sun Fire 6800/4810/4800 systems, remove the board from the card cage by holding the handle and grasping the bottom rail with your other hand. Slide...
Page 44: Figure 3-8 Removing And Replacing A Cpu/Memory Board-Sun Fire 3800 System
Note – The CPU/Memory board can be inserted into a powered-on system. The board will not be recognized by the system until the domain has been re-initialized and rebooted. Refer to the Sun Fire 6800/4810/4800/3800 Systems Platform Administration Manual for complete procedures for initializing a domain.
Page 45: Replacing Dimms
TABLE 3-2 FIGURE 3-7 For the Sun Fire 6800/4810/4800 systems, the top of the board is noted by the thin rail. The bottom of the board has a thicker rail. The board LEDs should be at the bottom of the handle when the board is inserted properly into the card cage for the Sun Fire 6800/4810/4800 systems.
Page 46: Figure 3-9 Dimm Slot Numbers
Install the larger capacity DIMMs into banks before installing the smaller capacity DIMMs into banks. The minimum number of DIMMs you can install per CPU processor is four DIMMs or one bank. 3-12 Sun Fire 6800/4810/4800/3800 Systems Service Manual • April 2001...
Page 47: Figure 3-10 Removing A Dimm
If the number of CPU processors on each CPU/Memory board are the same, place DIMM banks on CPU/Memory boards that have fewer populated DIMM banks before placing DIMMs on CPU/Memory boards that already have more populated DIMM banks. If some CPU/Memory boards have more CPU processors than others, place DIMMs in DIMM banks on the board with the most CPU processors.
Page 48: Installing Dimms
5. Align the short-side key on the DIMM and the long-side key on the DIMM with the short side and long side of the DIMM connector. Note – If you are installing four DIMMs, insert the DIMMs into the same bank. 3-14 Sun Fire 6800/4810/4800/3800 Systems Service Manual • April 2001...
Page 49: Figure 3-11 Installing A Dimm
6. Place your thumbs on the top edge of the DIMM, and push the DIMM firmly into its connector ( FIGURE 3-11 Long side key Short side key Installing a DIMM FIGURE 3-11 7. Press down firmly on the entire edge of the DIMM. When installed correctly, the ejector levers will be in the upright position.
Page 50 3-16 Sun Fire 6800/4810/4800/3800 Systems Service Manual • April 2001...
Page 51: Pci I/O Assemblies And Components
PCI I/O Assemblies and Components The PCI I/O assembly is supported in the Sun Fire 6800/4810/4800 systems. The Sun Fire 3800 system supports only the CompactPCI I/O assembly. See Section 5.3 “CompactPCI I/O Assembly” on page 5-3. This chapter provides an overview of the PCI I/O assembly, including how to remove and install the PCI I/O assembly.
Page 52: Filler Boards And Filler Panels
Note – The PCI I/O assembly can be inserted into a powered-on system. The assembly will not be recognized by the system until the domain has been re- initialized and rebooted. Refer to the Sun Fire 6800/4810/4800/3800 Systems Platform Administration Manual for complete procedures for initializing a domain.
Page 53: Pci I/O Assemblies
PCI board is 965 Mbytes/second. 4.3.1 PCI I/O Assembly Location Requirements Location of the I/O Assemblies TABLE 4-2 System Slot Numbers Location Sun Fire 6800 IB6, IB7, IB8, IB9 Rear Sun Fire 4810 IB6, IB8 Front Sun Fire 4800 IB6, IB8...
Page 54: Figure 4-1 I/O Assemblies For The Sun Fire 6800 System-Rear View
I/O Assemblies for the Sun Fire 6800 System—Rear View FIGURE 4-1 When you install PCI I/O assemblies into the Sun Fire 6800 system, you can install them in either the top or bottom I/O locations. Populate the PCI I/O assemblies from right to left. That is, populate I/O locations IB6 and IB8 before you populate the left I/O locations, IB7 and IB9.
Page 55: Figure 4-2 I/O Assemblies For The Sun Fire 4810 System-Front View
4.3.1.2 Locations Requirements for the Sun Fire 4810 System illustrates the I/O assembly locations in the Sun Fire 4810 system. FIGURE 4-2 I/O Assemblies for the Sun Fire 4810 System—Front View FIGURE 4-2 Chapter 4 PCI I/O Assemblies and Components...
Page 56: Figure 4-3 I/O Assemblies For The Sun Fire 4800 System-Rear View
Locations Requirements for the Sun Fire 4800 System illustrates the I/O assembly locations in the Sun Fire 4800 system. FIGURE 4-3 I/O Assemblies for the Sun Fire 4800 System—Rear View FIGURE 4-3 Sun Fire 6800/4810/4800/3800 Systems Service Manual • April 2001...
Page 57: I/O Assembly Leds
Removing a PCI I/O Assembly 1. Prepare the system for removal of the PCI I/O assembly. Refer to the Sun Fire 6800/4810/4800/3800 Systems Platform Administration Manual for complete procedures for powering off the assembly. 2. Attach a wrist strap or foot strap. Connect the ESD strap to the system.
Page 58: Figure 4-4 Pci I/O Assembly
This action releases the board from the connectors. 6. Slide the I/O assembly out of the I/O assembly opening ( FIGURE 4-5 Removing or Inserting an I/O Assembly—Sun Fire 4810 System FIGURE 4-5 Sun Fire 6800/4810/4800/3800 Systems Service Manual • April 2001...
Page 59: Replacing Pci Cards
Note – The PCI I/O assembly can be inserted into a powered-on system. The assembly will not be recognized by the system until the domain has been re- initialized and rebooted. Refer to the Sun Fire 6800/4810/4800/3800 Systems Platform Administration Manual for complete procedures for initializing a domain.
Page 60: Figure 4-6 Removing A Pci Card From The I/O Assembly
Removing a PCI Card From the I/O Assembly FIGURE 4-6 5. If you are not going to replace the PCI card, insert a filler board into the empty PCI slot. 4-10 Sun Fire 6800/4810/4800/3800 Systems Service Manual • April 2001...
Page 61: Installing A Pci Card
4.3.4.2 Installing a PCI Card Caution – Short PCI boards longer than 6.6 inches (167 mm) must be installed in a long PCI card slot. 1. Attach a wrist strap or foot strap. Connect the ESD strap to the system. 2.
Page 62 4-12 Sun Fire 6800/4810/4800/3800 Systems Service Manual • April 2001...
Page 63: Compactpci I/O Assemblies And Components
C H A P T E R CompactPCI I/O Assemblies and Components Only the Sun Fire 3800 system supports the CompactPCI I/O assembly. This chapter provides an overview of the CompactPCI I/O assembly, including how to remove and replace the CompactPCI I/O assembly in the Sun Fire 3800 system. To protect both yourself and the equipment, make sure you follow the precautions in Chapter 1.”...
Page 64 Note – The CompactPCI I/O assembly or CompactPCI card can be inserted into a powered-on system. The assembly will not be recognized by the system until the domain has been re-initialized and rebooted. Refer to the Sun Fire 6800/4810/4800/ 3800 Systems Platform Administration Manual for complete procedures for initializing a domain.
Page 65: Filler Boards, Filler Panels, And Compactpci Filler Cards
Filler Boards, Filler Panels, and CompactPCI Filler Cards In order to prevent the system from overheating, see Section 1.4 “Filler Boards and Filler Panels” on page 1-4 for procedures you must follow when removing the I/O assembly from a system. Caution –...
Page 66: Compactpci I/O Assembly Location Requirements
I/O Assemblies for the Sun Fire 3800 System—Front View FIGURE 5-1 The Sun Fire 3800 system supports only the CompactPCI I/O assembly. Populate the left I/O location, IB6, first and the right I/O location, IB8, last. Sun Fire 6800/4810/4800/3800 Systems Service Manual • April 2001...
Page 67: I/O Assembly Status Leds
Removing a CompactPCI I/O Assembly 1. Power off the assembly. Refer to the Sun Fire 6800/4810/4800/3800 Systems Platform Administration Manual for complete procedures for powering off the assembly. 2. Attach a wrist strap or foot strap. Connect the ESD strap to the system. Place a grounded ESD mat close to the system.
Page 68: Figure 5-2 Removing Or Inserting A Compactpci I/O Assembly-Sun Fire 3800 System
Caution – DO NOT FORCE any I/O assembly into an opening; this can cause damage to the assembly and system. The assembly should insert and seat smoothly. If it binds, remove the assembly and inspect the card cage slot for any obvious obstructions. Sun Fire 6800/4810/4800/3800 Systems Service Manual • April 2001...
Page 69: Replacing Compactpci Cards
7. Tighten the four captive Phillips screws. 8. Power on the assembly. Refer to the Sun Fire 6800/4810/4800/3800 Systems Platform Administration Manual for complete system procedures for powering on the assembly. Note – The assembly will not be recognized by the system until the domain has been re-initialized and rebooted.
Page 70: Figure 5-3 Removing A Compactpci Card
Caution – Do not hold, pull, or push the CompactPCI card by the lever lock. The lever lock is not designed to be used as a handle. Hold the card by the front panel or edges only. Sun Fire 6800/4810/4800/3800 Systems Service Manual • April 2001...
Page 71 7. Tighten the two captive screws, one at each end of the card. 8. Power on the card. Refer to the Sun Fire 6800/4810/4800/3800 Systems Platform Administration Manual for complete procedures for powering on the card. Note – The CompactPCI card will not be recognized by the system until the domain has been re-initialized and rebooted.
Page 72 5-10 Sun Fire 6800/4810/4800/3800 Systems Service Manual • April 2001...
Page 73: System Controller Board
C H A P T E R System Controller Board This chapter describes how to remove and replace the system controller board. To protect both yourself and the equipment, make sure you follow the precautions in Chapter 1 “Safety and Tools Requirements.” This chapter contains the following sections: Section 6.1 “Handling Boards and Assemblies”...
Page 74: System Controller Board
Controller board Centralized time-of-day (TOD) chip Centralized reset logic Status and control of power supplies The System Controller board consists of the following subsystems: Console Bus Clocks Reset logic Centerplane connector signals Sun Fire 6800/4810/4800/3800 Systems Service Manual • April 2001...
Page 75 LED (amber) Fault LED (amber) Reset switch Captive Activated Ejector lever screw LED (green) System Controller Board for Sun Fire 6800/4810/4800 Systems FIGURE 6-1 System Controller Board for the Sun Fire 3800 System FIGURE 6-2 Chapter 6 System Controller Board...
Page 76: System Controller Board Slot Locations
For all systems, the System Controller board in the lower slot, SSC0, is the master System Controller board. The System Controller board in the top slot, SSC1, is the redundant System Controller board. Sun Fire 6800/4810/4800/3800 Systems Service Manual • April 2001...
Page 77: Figure 6-3 System Controller Board Slot Assignments For The Sun Fire 6800 System-Front View
SSC1 SSC0 System Controller Board Slot Assignments for the Sun Fire 6800 System— FIGURE 6-3 Front View Chapter 6 System Controller Board...
Page 78: Figure 6-4 System Controller Board Slot Assignments For The Sun Fire 4810 System-Front View
SSC1 SSC0 System Controller Board Slot Assignments for the Sun Fire 4810 System— FIGURE 6-4 Front View Sun Fire 6800/4810/4800/3800 Systems Service Manual • April 2001...
Page 79: Figure 6-5 System Controller Board Slot Assignments For The Sun Fire 4800 System-Rear View
SSC1 SSC0 System Controller Board Slot Assignments for the Sun Fire 4800 System— FIGURE 6-5 Rear View Chapter 6 System Controller Board...
Page 80: System Controller Board Leds
LED Name and Location Activated LED Board is activated Board is deactivated. (green) Internal fault Fault LED (amber) No internal fault OK to remove LED Assembly can be removed Assembly cannot be (amber) removed Sun Fire 6800/4810/4800/3800 Systems Service Manual • April 2001...
Page 81: Resetting The System Controller Board
6.2.3 Resetting the System Controller Board If the System Controller board hangs and will not respond: Press the Reset switch ( ) by using a pen tip to reset the System FIGURE 6-7 Controller board so that it reboots. Pressing the reset switch reloads the system controller software. Pressing the reset switch does not have any adverse effect on domains.
Page 82 1. Power off the system. Refer to the Sun Fire 6800/4810/4800/3800 Systems Platform Administration Manual for complete system procedures for powering off. 2. Attach a wrist strap or foot strap. Connect the ESD strap to the system. Place a grounded ESD mat close to the system.
Page 83: Figure 6-9 Removing And Replacing A System Controller Board-Sun Fire 6800 System
6. Slide the board out ( FIGURE 6-9 FIGURE 6-10 illustrates how to install or remove the board for a Sun Fire 6800 system. FIGURE 6-9 illustrates how to install or remove the board for a Sun Fire 3800 system.
Page 84: Figure 6-10 Removing And Replacing A System Controller Board-Sun Fire 3800 System
3. Turn both board ejectors outward before you insert the board into the card cage. 4. Line up the board with the slots. For the Sun Fire 6800/4810/4800 systems, slide the board into the card cage slot FIGURE 6-9 For the Sun Fire 3800 system, put one hand on the center of the board and the other hand on the front panel.
Page 85: Figure 6-11 Tightening The Captive Screws And Locking The Ejector Levers
Tightening the Captive Screws and Locking the Ejector Levers FIGURE 6-11 7. Connect the serial or network cable to the board. 8. Power on the system. Refer to the Sun Fire 6800/4810/4800/3800 Systems Platform Administration Manual for complete system procedures for powering on. Chapter 6 System Controller Board...
Page 86 6-14 Sun Fire 6800/4810/4800/3800 Systems Service Manual • April 2001...
Page 87: Repeater Board
C H A P T E R Repeater Board To protect both yourself and the equipment, make sure you follow the precautions in Chapter 1 “Safety and Tools Requirements.” This chapter explains the following topics: Section 7.1 “Handling Boards and Assemblies” on page 7-1 Section 7.2 “Filler Boards”...
Page 88: Filler Boards
Sun Fire 4810 and Sun Fire 4800 systems, Repeater boards work as single boards. However, in the Sun Fire 6800 system, the Repeater boards work in pairs. In the Sun Fire 3800 system, the equivalent of two Repeater boards is integrated into the active centerplane.
Page 89 Repeater Board Slot Assignments for the Sun Fire 6800 System—Rear View FIGURE 7-1 In the Sun Fire 6800 system, Repeater boards work in pairs: RP0 with RP1, and RP2 with RP3. Populate Repeater board pairs on the Sun Fire 6800 system from right to left, beginning with RP0 and RP1.
Page 90: Figure 7-2 Repeater Board Slot Assignments For The Sun Fire 4810 System-Front View
Repeater Board Slot Assignments for the Sun Fire 4810 System—Front View FIGURE 7-2 Repeater Board Slot Assignments for the Sun Fire 4800 System—Rear View FIGURE 7-3 Sun Fire 6800/4810/4800/3800 Systems Service Manual • April 2001...
Page 91 In the Sun Fire 4810 and Sun Fire 4800 systems, there are two Repeater boards: RP0 and RP2. Populate the Repeater boards from left to right. There are three LEDs on the Repeater board. notes the LED functions. TABLE 7-2 Repeater Board LED Functions TABLE 7-2 LED Name and Location...
Page 92: Figure 7-4 Repeater Board Leds
Activated LED (green) Fault LED (amber) OK to remove LED (amber) (for future use) Repeater Board LEDs FIGURE 7-4 Sun Fire 6800/4810/4800/3800 Systems Service Manual • April 2001...
Page 93: Replacing Repeater Boards
Removing a Repeater Board 1. Halt the domain and power off the board. Refer to the Sun Fire 6800/4810/4800/3800 Systems Platform Administration Manual for complete procedures for powering off the board. 2. Attach a wrist strap or foot strap. Connect the ESD strap to the system. Place a grounded ESD mat close to the system.
Page 94: Figure 7-5 Unlocking The Ejector Levers
Unlocking the Ejector Levers FIGURE 7-5 Sun Fire 6800/4810/4800/3800 Systems Service Manual • April 2001...
Page 95: Figure 7-6 Removing And Replacing A Repeater Board-Sun Fire 6800 System
( FIGURE 7-6 Removing and Replacing a Repeater Board—Sun Fire 6800 System FIGURE 7-6 6. Place the board on an ESD mat that is on a work surface.
Page 96 When properly installed, the ejectors will lock automatically. 5. Power on the board. Refer to the Sun Fire 6800/4810/4800/3800 Systems Platform Administration Manual for complete procedures for powering on the board. 6. Initialize the domain. Refer to the Sun Fire 6800/4810/4800/3800 Systems Platform Administration Manual for complete procedures for initializing a domain.
Page 97: Power
Section 8.3.2 “Replacing the RTU Assembly” on page 8-19 Power Supplies These systems offer redundant power supplies. The Sun Fire 6800 and Sun Fire 4810 systems use the same interchangeable power supplies. The Sun Fire 4800 system and the Sun Fire 3800 system each have specialized power supplies that cannot be interchanged with each other or with any other Sun Fire systems.
Page 98 Sun Fire 4810 Sun Fire 6800 There are four alternating current (AC) power cords for the Sun Fire 6800 system. There are three AC power cords for the Sun Fire 4810 and the Sun Fire 4800 systems. Each power supply in the Sun Fire 3800 system has its own power cord. The software monitors the status of the AC power source.
Page 99: Power Supply Slot Locations
Power Supply Locations—Sun Fire 6800 System—Front View FIGURE 8-1 The Sun Fire 6800 system has two power grids, grid 0 and grid 1. For the Sun Fire 6800 system, power supplies PS0, PS1, and PS2 are assigned to power grid 0 and power supplies PS3, PS4, and PS5 are assigned to power grid 1.
Page 100: Figure 8-2 Power Supplies In Power Grid 0 And Power Grid 1-Sun Fire 6800 System
FIGURE 8-2 grid 1. Power supplies in power grid 1 Power supplies in power grid 0 Power Supplies in Power Grid 0 and Power Grid 1—Sun Fire 6800 System FIGURE 8-2 Sun Fire 6800/4810/4800/3800 Systems Service Manual • April 2001...
Page 101: Figure 8-3 Power Supply Locations-Sun Fire 4800 System-Front View
In the Sun Fire 4800 and Sun Fire 4810 systems, install the right and left power supplies before installing the middle power supply. Install the power supplies in this order: PS0, PS2, and PS1. Power Supply Locations—Sun Fire 4800 System—Front View FIGURE 8-3 Power Supply Locations—Sun Fire 4810 System—Front View FIGURE 8-4...
Page 102: Figure 8-5 Power Supply Locations-Sun Fire 3800 System-Front View
In the Sun Fire 3800 system, install the middle power supply first. Then install the left power supply. And finally, install the right power supply. Install the power supplies in this order: PS1, PS2, and PS0. Power Supply Locations—Sun Fire 3800 System—Front View FIGURE 8-5 Sun Fire 6800/4810/4800/3800 Systems Service Manual • April 2001...
Page 103: Power Supply Leds
8.1.3 Replacing a Sun Fire 6800/4810 System Power Supply 8.1.3.1 Removing a Sun Fire 6800 or Sun Fire 4810 System Power Supply 1. Power off the appropriate power supply. Refer to the Sun Fire 6800/4810/4800/3800 Systems Platform Administration Manual for complete procedures for powering off the power supply.
Page 104: Figure 8-6 Removing Or Replacing A Power Supply-Sun Fire 6800 System
6. Install a power supply filler panel to cover the empty slot. Tighten the captive screws. 8.1.3.2 Installing a Sun Fire 6800 or Sun Fire 4810 System Power Supply 1. Remove the power supply filler panel. 2. Slide the power supply into the slot ( FIGURE 8-6 3.
Page 105: Replacing A Sun Fire 4800 System Power Supply
Removing a Sun Fire 4800 System Power Supply 1. Power off the appropriate power supply. Refer to the Sun Fire 6800/4810/4800/3800 Systems Platform Administration Manual for complete procedures for powering off the system. 2. Have a power supply filler panel available.
Page 106: Replacing A Sun Fire 3800 System Power Supply
Removing a Sun Fire 3800 System Power Supply 1. Power off the appropriate power supply. Refer to the Sun Fire 6800/4810/4800/3800 Systems Platform Administration Manual for complete procedures for powering off the desired power supply. 2. Have a power supply filler panel available.
Page 107: Figure 8-8 Removing Or Replacing A Power Supply-Sun Fire 3800 System
Caution – Do not remove the power supply completely from the system while only holding the handle of the power supply. 6. Holding the power supply with both hands, slide the power supply completely out of the system. Captive screws Removing or Replacing a Power Supply—Sun Fire 3800 System FIGURE 8-8 7.
Page 108: Ac Input Box
For the location of the AC input box(es), see on page 8-13, FIGURE 8-10 on page 8-13, and on page 8-14. FIGURE 8-11 FIGURE 8-12 AC Input Box—Sun Fire 6800 System FIGURE 8-9 8-12 Sun Fire 6800/4810/4800/3800 Systems Service Manual • April 2001...
Page 109: Figure 8-10 Ac Input Box-Sun Fire 4800 System
AC input AC Input Box—Sun Fire 4800 System FIGURE 8-10 AC input box AC Input Box—Sun Fire 4810 System FIGURE 8-11 Chapter 8 Power 8-13...
Page 110: Replacing The Ac Input Box
8.2.1.1 Removing the AC Input Box 1. Power off the system. Refer to the Sun Fire 6800/4810/4800/3800 Systems Platform Administration Manual for complete procedures for powering off the system. 2. Loosen the power cord lock. 3. Disconnect the power cord.
Page 111 Captive screws Two Captive Screws on the AC Input Box—Sun Fire 6800 System FIGURE 8-13 5. Slide the AC input box out of the chassis ( FIGURE 8-14 Additional AC input box Removing the AC Input Box—Sun Fire 6800 System FIGURE 8-14 8.2.1.2...
Page 112: Redundant Transfer Unit (Rtu) And Redundant Transfer Switch (Rts)
Redundant Transfer Unit (RTU) and Redundant Transfer Switch (RTS) The Sun Fire 6800 system has two RTUs. Each RTU contains two RTS modules. The primary configuration is the left RTS module with the right RTS module as secondary for redundancy. The RTUs function as power sequencers.
Page 113 describes the LED functions. TABLE 8-4 LED Functions TABLE 8-4 LED Position] Color Status Meaning Left Green The source is present and is within specifications. The source either is not present or is below specifications. Flashing The source is above specifications. Middle Green The module relay is energized and the module is...
Page 114: Figure 8-16 Rts Modules-Sun Fire 4810 System-Rear View
RTS1 RTS0 RTS Modules—Sun Fire 4810 System—Rear View FIGURE 8-16 RTS2 RTS0 RTS1 RTS3 Rear view Front view RTS Modules—Sun Fire 6800 System FIGURE 8-17 8-18 Sun Fire 6800/4810/4800/3800 Systems Service Manual • April 2001...
Page 115: Replacing The Rts Modules
Replacing the RTS Modules 1. Power off the system. Refer to the Sun Fire 6800/4810/4800/3800 Systems Platform Administration Manual for complete procedures for powering off the system. 2. Power off the wall circuit breaker connected to the RTS module that is to be replaced.
Page 116 6. Remove the four screws holding the RTU to the cabinet ( FIGURE 8-18 7. Firmly pull out the RTU. 8. Install the replacement RTU Assembly by reversing Step 1 through Step 6. The assembly is self-aligning. 8-20 Sun Fire 6800/4810/4800/3800 Systems Service Manual • April 2001...
Page 117: Fan Trays
All systems have multiple fan trays that provide redundant cooling if one fan tray fails. The Sun Fire 6800 system has four fan trays that collectively cool the system. The Sun Fire 4810 and Sun Fire 4800 systems have three fan trays that also collectively cool the system.
Page 118: Fan Tray Slot Numbering
Front Rear Sun Fire 3800 system Rear (redundant) Rear Rear Rear , and illustrate the locations of the fan FIGURE 9-1 FIGURE 9-2 FIGURE 9-3 FIGURE 9-4 trays in each system. Sun Fire 6800/4810/4800/3800 Systems Service Manual • April 2001...
Page 119: Figure 9-1 Front And Rear Fan Trays-Sun Fire 6800 System
Front and Rear Fan Trays—Sun Fire 6800 System FIGURE 9-1 Fan Trays—Sun Fire 4810 System FIGURE 9-2 Chapter 9 Fan Trays...
Page 120: Figure 9-3 Fan Trays-Sun Fire 4800 System
Fan Trays—Sun Fire 4800 System FIGURE 9-3 Fan Trays—Sun Fire 3800 System FIGURE 9-4 Sun Fire 6800/4810/4800/3800 Systems Service Manual • April 2001...
Page 121: Fan Tray Leds
1. Make sure you have a replacement fan tray or filler panel available. 2. Power off the fan tray. Refer to the Sun Fire 6800/4810/4800/3800 Systems Platform Administration Manual for complete procedures for powering off the fan tray. 3. If you are removing the top fan tray, FT1, from a Sun Fire 4800 system, remove the bezel by snapping it off.
Page 122: Installing A Fan Tray
5. If you are installing the top fan tray, FT1, into a Sun Fire 4800 system, replace the bezel by snapping it on. 6. Power on the fan tray. Refer to the Sun Fire 6800/4810/4800/3800 Systems Platform Administration Manual for complete procedures for powering on the fan tray. Sun Fire 6800/4810/4800/3800 Systems Service Manual • April 2001...
Page 123: Replacing Fan Trays In A Sun Fire 3800 System
1. Make sure you have a replacement fan tray or filler panel available. 2. Power off the fan tray. Refer to the Sun Fire 6800/4810/4800/3800 Systems Platform Administration Manual for complete procedures for powering off the fan tray. 3. Loosen the two captive screws.
Page 124: Installing A Fan Tray
4. Tighten the two captive screws. 5. Power on the fan tray. Refer to the Sun Fire 6800/4810/4800/3800 Systems Platform Administration Manual for complete procedures for powering on the fan tray. Sun Fire 6800/4810/4800/3800 Systems Service Manual • April 2001...
Page 125: Cabinet Fan Trays
Cabinet Fan Trays Two fan trays provide additional cooling for the Sun Fire 6800 system. Both are located on the cabinet top immediately behind the FrameManager ( FIGURE 9-7 Cabinet fan trays Cabinet Fan Trays FIGURE 9-7 Note – Each RTU has two “unswitched” power outlets (the topmost outlets on each side of the RTU).
Page 126: Replacing The Cabinet Fan Trays
3. Disconnect and then remove the two connectors from the rear of the fan tray FIGURE 9-8 4. Loosen and then remove the two screws from the fan assembly top plate FIGURE 9-9 9-10 Sun Fire 6800/4810/4800/3800 Systems Service Manual • April 2001...
Page 127: Figure 9-9 Cabinet Fan Tray Top Plate
Screws (2) Top plate Cabinet Fan Tray Top Plate FIGURE 9-9 5. Remove the fan assembly top plate. This will reveal two captive screws. 6. Loosen the two captive screws. 7. Remove the fan tray assembly by supporting the fan tray with one hand while raising the end containing the connectors and then pulling slightly forward.
Page 128 9-12 Sun Fire 6800/4810/4800/3800 Systems Service Manual • April 2001...
Page 129: Centerplane And Id Source Boards
6800/4810/4800/3800 systems. Also described is how to replace the ID Source board from the these systems Section 10.1 “Replacing Centerplanes in a Sun Fire 6800 System” on page 10-1 Section 10.2 “Replacing the Centerplanes in a Sun Fire 4810 System” on page 10-13 Section 10.3 “Replacing the Centerplane in a Sun Fire 4800 System”...
Page 130: Removing The System Centerplane
Removing the System Centerplane 1. Halt the Solaris operating environment in each domain and power off the system. Refer to the Sun Fire 6800/4810/4800/3800 Systems Platform Administration Manual for complete procedures for powering off the system. 2. Remove the front and rear doors by lifting the door panels off the hinges FIGURE 10-1 Removing the Door—Sun Fire 6800 System...
Page 131: Figure 10-2 Removing All Components From The Front Of The Sun Fire 6800 System
Controller boards, and filler boards or filler panels from the front and rear of the system ( FIGURE 10-2 Removing All Components From the Front of the Sun Fire 6800 System FIGURE 10-2 Note – Do not remove the ID Source board from the centerplane.
Page 132: Figure 10-4 Loosening The Bus Bar Captive Screws-Sun Fire 6800 System
7. Loosen the upper-right and upper-left bus bar captive screws, by reaching through the access area ( FIGURE 10-4 There are four captive screws at each location. Loosening the Bus Bar Captive Screws—Sun Fire 6800 System FIGURE 10-4 10-4 Sun Fire 6800/4810/4800/3800 Systems Service Manual • April 2001...
Page 133: Figure 10-5 Disconnecting The Two Cables From The System Centerplane-Sun Fire 6800 System
8. Disconnect the two cables from the system centerplane ( FIGURE 10-5 Disconnecting the Two Cables From the System Centerplane—Sun Fire 6800 FIGURE 10-5 System 9. At the front of the system, remove the 19 screws securing the centerplane to the...
Page 134: Figure 10-7 Moving The System Centerplane Forward Off The Guide Pins-Sun Fire 6800 System
10. Move the centerplane forward off the guide pins ( FIGURE 10-7 Moving the System Centerplane Forward Off the Guide Pins—Sun Fire 6800 FIGURE 10-7 System 11. Tilt the top of the centerplane forward about 30 degrees. 12. Remove the centerplane (...
Page 135: Removing The Fan Centerplane
Removing the Fan Centerplane 1. Halt the Solaris operating environment in each domain, and power off the system. Refer to the Sun Fire 6800/4810/4800/3800 Systems Platform Administration Manual for complete procedures for powering off the system. 2. Attach a wrist strap or foot strap. Connect the ESD jack from the system to your wrist strap or foot strap.
Page 136: Removing The Power Centerplane
Removing the Power Centerplane 1. Halt the Solaris operating environment in each domain and power off the system. Refer to the Sun Fire 6800/4810/4800/3800 Systems Platform Administration Manual for complete procedures for powering off the system. Caution – Use a grounding wrist strap to prevent static damage. Attach a wrist strap or foot strap.
Page 137: Figure 10-11 Centerplane Cables-Sun Fire 6800 System
Disconnect the power cable that connects the power centerplane to the fan centerplane ( FIGURE 10-11 Centerplane Cables—Sun Fire 6800 System FIGURE 10-11 9. Remove the left and right bus bars as follows: a. From the rear of the cabinet, remove the bus bar access panels.
Page 138: Figure 10-12 Disconnecting The Screws Securing The Power Centerplane Bus Bars
Remove the bus bar ( FIGURE 10-12 Disconnecting the Screws Securing the Power Centerplane Bus Bars FIGURE 10-12 10. Remove the nine screws securing the centerplane to the cabinet. 11. Remove the centerplane. 10-10 Sun Fire 6800/4810/4800/3800 Systems Service Manual • April 2001...
Page 139: Installing The System Centerplane
10.1.4 Installing the System Centerplane 1. Insert and align the centerplane within the chassis cabinet ( FIGURE 10-8 page 10-6). 2. At the front of the system, install the 19 screws securing the centerplane to the chassis. 3. Connect the system cable to the centerplane. 4.
Page 140: Replacing The Power Centerplane
8. Install the power supplies. 9. Install the CPU/Memory boards. 10. Power on the system. Refer to the Sun Fire 6800/4810/4800/3800 Systems Platform Administration Manual for complete procedures for powering on the system. 10-12 Sun Fire 6800/4810/4800/3800 Systems Service Manual • April 2001...
Page 141: Replacing The Centerplanes In A Sun Fire 4810 System
Centerplane 1. Halt the Solaris operating environment in each domain and power off the system. Refer to the Sun Fire 6800/4810/4800/3800 Systems Platform Administration Manual for complete procedures for powering off the system. 2. Attach a wrist strap or foot strap. Connect the ESD jack from the system to your wrist strap or foot strap.
Page 142: Figure 10-13 Removing All Boards, Fan Trays, Ac Input Box, And Power Supplies From The Front Of The Sun Fire 4810 System
5. At the rear of the system, remove the screws securing the rear screen panel to the system ( FIGURE 10-14 Remove the screen by first swinging the left side out past the mounting bracket and then remove the screen. 10-14 Sun Fire 6800/4810/4800/3800 Systems Service Manual • April 2001...
Page 143: Figure 10-14 Rear Screen Panel-Sun Fire 4810 System
Mounting bracket screws Rear Screen Panel—Sun Fire 4810 System FIGURE 10-14 6. Disconnect the cable connecting the system backplane and the power backplane FIGURE 10-15 Disconnecting the Signal Cable—Sun Fire 4810 System FIGURE 10-15 Chapter 10 Centerplane and ID Source Boards 10-15...
Page 144: Figure 10-16 Removing The Screws Securing The Cover To The Bus Bar And Removing The Bus Bar Insulator-Sun Fire 4810 System
8. Remove the eight screws securing the bus bar to the backplanes ( FIGURE 10-17 There are four screws at the lower left and four screws at the upper right. Removing the Bus Bar—Sun Fire 4810 System FIGURE 10-17 10-16 Sun Fire 6800/4810/4800/3800 Systems Service Manual • April 2001...
Page 145: Installing The System Centerplane Or The Power Centerplane
10.2.1.1 Removing the System Centerplane 1. Remove the 36 screws securing the system centerplane to the chassis ( FIGURE 10-18 2. Remove the system centerplane carefully from the chassis. Removing the System Centerplane— Sun Fire 4810 System FIGURE 10-18 10.2.1.2 Removing the Power Centerplane The power centerplane is located at the very bottom of the chassis.
Page 146 10. Make sure that the three power switches on the AC input box are turned on. 11. Power on the system. Refer to the Sun Fire 6800/4810/4800/3800 Systems Platform Administration Manual for complete procedures for powering on the system. 10.2.2.2 Installing the Power Centerplane 1.
Page 147: Replacing The Centerplane In A Sun Fire 4800 System
Removing the Centerplane 1. Halt the Solaris operating environment in each domain and power off the system. Refer to the Sun Fire 6800/4810/4800/3800 Systems Platform Administration Manual for complete procedures for powering off the system. 2. Remove the power cord.
Page 148: Figure 10-19 Removing The Bottom Fan Tray, Cpu/Memory Boards, And I/O Assemblies-Sun Fire 4800 System
Assemblies—Sun Fire 4800 System 5. Remove the front door ( FIGURE 10-20 a. Open the door. b. Push down on the spring latch inside the top cover of the door. 10-20 Sun Fire 6800/4810/4800/3800 Systems Service Manual • April 2001...
Page 149: Figure 10-20 Removing The Front Door- Sun Fire 4800 System
c. Remove the door. Removing the Front Door— Sun Fire 4800 System FIGURE 10-20 Chapter 10 Centerplane and ID Source Boards 10-21...
Page 150: Figure 10-21 Removing A Power Supply At The Front Of The Sun Fire 4800 System
6. At the front of the system, remove all power supplies. shows removing one power supply from the system. FIGURE 10-21 Removing a Power Supply at the Front of the Sun Fire 4800 System FIGURE 10-21 10-22 Sun Fire 6800/4810/4800/3800 Systems Service Manual • April 2001...
Page 151: Figure 10-22 Disconnecting Cables From The Connectors On The Centerplane-Sun Fire 4800 System
7. Disconnect the two cables from the connectors on the centerplane. Both cables are on the right. You will need to use force to disconnect the cables. Disconnecting Cables From the Connectors on the Centerplane—Sun Fire FIGURE 10-22 4800 System Chapter 10 Centerplane and ID Source Boards 10-23...
Page 152: Figure 10-23 Removing The Top And Bottom Power Supply Supports-Sun Fire 4800 System
With both hands, firmly pull the upper power supply support away from the centerplane and rotate the front of the upper power supply support downward, and then remove it. Removing the Top and Bottom Power Supply Supports—Sun Fire 4800 FIGURE 10-23 System 10-24 Sun Fire 6800/4810/4800/3800 Systems Service Manual • April 2001...
Page 153: Figure 10-24 Removing The Cable Guide-Sun Fire 4800 System
9. Remove the plastic cable guide located on the bottom of the power supply bay, next to the right wall. Removing the Cable Guide—Sun Fire 4800 System FIGURE 10-24 Chapter 10 Centerplane and ID Source Boards 10-25...
Page 154: Figure 10-25 Removing The Screws Securing The Centerplane To The System-Sun Fire 4800 System
10. Using a long handled #2 Phillips screwdriver, remove the 30 screws securing the centerplane to the system enclosure. Removing the Screws Securing the Centerplane to the System—Sun Fire 4800 FIGURE 10-25 System 10-26 Sun Fire 6800/4810/4800/3800 Systems Service Manual • April 2001...
Page 155: Figure 10-26 Removing The Centerplane And Insulator-Sun Fire 4800 System
11. Remove the insulator and the centerplane together ( FIGURE 10-26 It may be necessary to rotate the centerplane to clear cables along the right-hand wall. Removing the Centerplane and Insulator—Sun Fire 4800 System FIGURE 10-26 Chapter 10 Centerplane and ID Source Boards 10-27...
Page 156: Installing The Centerplane
10. At the back of the system, replace the bottom two fan tray assemblies and boards FIGURE 10-19 11. Power on the system. Refer to the Sun Fire 6800/4810/4800/3800 Systems Platform Administration Manual for complete procedures for powering on the system. 10-28...
Page 157: Replacing The Centerplane In A Sun Fire 3800 System
To remove the centerplane from a powered-off system: 1. Halt the Solaris operating environment in each domain and power off the system. Refer to the Sun Fire 6800/4810/4800/3800 Systems Platform Administration Manual for complete procedures for powering off the system.
Page 158: Figure 10-27 Removing The Boards- Sun Fire 3800 System
Note – When you remove the boards and assemblies from the system, do not stack the boards and assemblies of top of each other. Removing the Boards— Sun Fire 3800 System FIGURE 10-27 10-30 Sun Fire 6800/4810/4800/3800 Systems Service Manual • April 2001...
Page 159: Figure 10-28 Disconnecting The Led Cable-Sun Fire 3800 System
6. At the front of the system, disconnect the LED cable ( FIGURE 10-28 The connector key is on the top horizontal surface. Disconnecting the LED Cable—Sun Fire 3800 System FIGURE 10-28 Chapter 10 Centerplane and ID Source Boards 10-31...
Page 160: Figure 10-29 Removing A Fan Tray-Sun Fire 3800 System
Slide the fan trays out. d. Remove the fan tray filler panel (if installed). Filler panel Fan tray Fan tray Removing a Fan Tray—Sun Fire 3800 System FIGURE 10-29 10-32 Sun Fire 6800/4810/4800/3800 Systems Service Manual • April 2001...
Page 161: Figure 10-30 Removing A Power Supply-Sun Fire 3800 System
8. Remove the power supplies and power supply filler panels. illustrates how to remove a power supply. You must remove all the FIGURE 10-30 power supplies and the filler panels as well. Following are abbreviated steps. See Section 8.1.5.1 “Removing a Sun Fire 3800 System Power Supply”...
Page 162: Figure 10-31 Removing The Clamp-Sun Fire 3800 System
There are two screws on the top and two screws on each of the two sides. c. Put your fingers in the holes and remove the clamp. Removing the Clamp—Sun Fire 3800 System FIGURE 10-31 10-34 Sun Fire 6800/4810/4800/3800 Systems Service Manual • April 2001...
Page 163: Figure 10-32 Removing The Subchassis
10. Remove the nine smaller screws with a Phillips screwdriver ( ). Make FIGURE 10-32 sure that the power supply cables are clear and remove the subchassis. Removing the Subchassis FIGURE 10-32 11. Remove the six screws of the lower bulkhead with a Phillips screwdriver ).
Page 164: Figure 10-34 Removing The Centerplane-Sun Fire 3800 System
( ). Remove the centerplane. FIGURE 10-34 Removing the Centerplane—Sun Fire 3800 System FIGURE 10-34 10-36 Sun Fire 6800/4810/4800/3800 Systems Service Manual • April 2001...
Page 165: Installing The Centerplane
10.4.2 Installing the Centerplane These installation steps assume that you have removed the centerplane from the system. 1. Attach a wrist strap or foot strap. Connect the ESD jack from the system to your wrist strap or foot strap. Place a grounded ESD mat close to the system. 2.
Page 166 Tighten the two captive screws. d. Attach the power supply cable. e. Install the power supply filler panels in the empty power supply slots. Tighten the captive screws. 10-38 Sun Fire 6800/4810/4800/3800 Systems Service Manual • April 2001...
Page 167 8. Install the fan trays ( FIGURE 10-29 The bottom two fan trays are installed with the captive screws on the top. The top two fan trays are installed with the captive screws on the bottom. The default configuration is three fan trays installed in this order ( TABLE 10-1 Default Fan Tray Configuration TABLE 10-1...
Page 168: Replacing The Sun Fire 3800 System Led Board
14. Power on the system. Refer to the Sun Fire 6800/4810/4800/3800 Systems Platform Administration Manual for complete procedures for powering on the system. 10.5 Replacing the Sun Fire 3800 System LED Board The purpose of the system LED board is to show the current state of the active ASIC hardware on the centerplane.
Page 169: Figure 10-35 Removing The I/O Assembly-Sun Fire 3800 System
Note – When you remove the assemblies from the system, do not stack the assemblies of top of each other. Removing the I/O Assembly—Sun Fire 3800 System FIGURE 10-35 4. From the front of the system, disconnect the LED cable from the centerplane FIGURE 10-36 The connector key is on the top horizontal surface.
Page 170: Installing The Led Board
4. From the front of the system, connect the LED cable from the centerplane FIGURE 10-36 5. At the front of the system, reinstall the I/O assemblies or I/O assembly filler board FIGURE 10-35 See Chapter 5 for the I/O assembly replacement procedures. 10-42 Sun Fire 6800/4810/4800/3800 Systems Service Manual • April 2001...
Page 171: Replacing Id Source Boards
1. Halt the Solaris operating environment in each domain and power down the entire system. Refer to the Sun Fire 6800/4810/4800/3800 Systems Platform Administration Manual for complete procedures for powering off the system. 2. Facing the rear of the system, remove the upper left I/O assembly IB9, from the system.
Page 172: Installing The Id Source Board In The Sun Fire 6800 System
Source board by the edges and remove it from the centerplane ( FIGURE 10-38 ID Source board Removing the ID Source Board From the Centerplane—Sun Fire 6800 System FIGURE 10-38 10.6.2 Installing the ID Source Board in the Sun Fire 6800 System 1.
Page 173: Removing The Id Source Board From The Sun Fire 4810 System
4. Power on the system. Refer to the Sun Fire 6800/4810/4800/3800 Systems Platform Administration Manual for complete procedures for powering on the system. 10.6.3 Removing the ID Source Board From the Sun Fire 4810 System 1. Halt the Solaris operating environment in each domain, and power down the entire system.
Page 174: Figure 10-40 Removing The Id Source Board From The Centerplane-Sun Fire 4810 System
Source board by the edges and remove it from the centerplane ( FIGURE 10-40 ID Source board Removing the ID Source Board From the Centerplane—Sun Fire 4810 System FIGURE 10-40 10-46 Sun Fire 6800/4810/4800/3800 Systems Service Manual • April 2001...
Page 175: Installing The Id Source Board In The Sun Fire 4810 System
3. Install IB8 I/O assembly into the system ( FIGURE 10-39 4. Power on the system. Refer to the Sun Fire 6800/4810/4800/3800 Systems Platform Administration Manual for complete procedures for powering on the system. 10.6.5 Removing the ID Source Board From the Sun Fire 4800 System 1.
Page 176 See Chapter 4 for I/O assembly, and Chapter 6 for System Controller board replacement procedures. 4. Power on the system. Refer to the Sun Fire 6800/4810/4800/3800 Systems Platform Administration Manual for complete procedures for powering on the system. 10-48 Sun Fire 6800/4810/4800/3800 Systems Service Manual • April 2001...
Page 177: Patch Panel
11.1 Patch Panel There is one patch panel in the Sun Fire 6800 system cabinet. The patch panel provides an interface between the system controllers and the system. The patch panel is located in the rear of the cabinet directly above the AC input boxes and RTU.
Page 178: Replacing The Patch Panel
1. Label and remove all cabling. 2. Loosen the four captive screws. 3. Remove the Patch Panel unit. 4. Install the replacement unit by reversing Step 1 through Step 3. 11-2 Sun Fire 6800/4810/4800/3800 Systems Service Manual • April 2001...
Page 179: Framemanager
C H A P T E R FrameManager This chapter provides procedures for field-replaceable FrameManager units within a Sun Fire 6800 system cabinet. The following sections are included in this chapter: Section 12.1 “FrameManager” on page 12-1 Section 12.2 “FrameManager LEDs” on page 12-2 Section 12.3 “Replacing the FrameManager”...
Page 180: Framemanager Leds
1. Loosen the screws at the back of the assembly ( FIGURE 12-2 Note – You may have to remove the two middle screws and reinstall them after you slide the replacement assembly into place. FrameManager Removal—Step 1 FIGURE 12-2 12-2 Sun Fire 6800/4810/4800/3800 Systems Service Manual • April 2001...
Page 181: Figure 12-1 Framemanager
2. Slide the assembly forward and carefully flip it onto the top of the cabinet to access the cable connector on the rear of the assembly ( FIGURE 12-3 FrameManager Removal—Step 2 FIGURE 12-3 3. Disconnect the five cables from the assembly ( FIGURE 12-4 FrameManager Cable Location FIGURE 12-4...
Page 182 12-4 Sun Fire 6800/4810/4800/3800 Systems Service Manual • April 2001...
Page 183: Functional Description
FIGURE A-5 The Sun Fire 6800 system has card cage slots for the System Controller boards and the CPU/Memory boards in the front of the system. In the rear of the system are slots for the I/O boards and the Repeater boards.
Page 184: System Packaging
CompactPCI I/O assemblies. The power supplies are the same on the Sun Fire 6800 and Sun Fire 4810 systems. The Sun Fire 4800 system has a different power supply style. The Sun Fire 3800 system has a third power supply style.
Page 185: Figure A-1 Sun Fire 6800 System-Front And Rear Views
Rear view Front view Sun Fire 6800 System—Front and Rear Views FIGURE A-1 Appendix A Functional Description...
Page 186: Sun Fire 4810 System
AC input box Rear View Front View Sun Fire 4810 System Mounted in Sun Fire Cabinet—Front and Rear Views FIGURE A-2 Air circulation for the system boards is provided by the fan trays. Sun Fire 6800/4810/4800/3800 Systems Service Manual • April 2001...
Page 187: Sun Fire 4800 System
A.2.3 Sun Fire 4800 System At the rear of the system there are slots for the following: Up to two I/O assemblies Up to two System Controller boards Two Repeater boards Up to three CPU/Memory boards Up to three fan trays AC input box Front View Rear View...
Page 188: Sun Fire 3800 System
Up to two System Controller boards Up to two Compact PCI I/O assemblies The equivalent of two Repeater boards are integrated into the active centerplane of the system. Sun Fire 3800 System—Front View FIGURE A-4 Sun Fire 6800/4810/4800/3800 Systems Service Manual • April 2001...
Page 189: Figure A-5 Sun Fire 3800 System-Rear View
At the rear of the system ( ), there are slots for: FIGURE A-5 Up to three power supplies Up to four fan trays Sun Fire 3800 System—Rear View FIGURE A-5 Appendix A Functional Description...
Page 190: Software
Some of the secondary functions of the FrameManager in the future may include entering the name and IP address of the system cabinet or access control (for entering a password). Sun Fire 6800/4810/4800/3800 Systems Service Manual • April 2001...
Page 191: Device Hot-Plug Procedures
The FrameManager manages three LEDs: power, fault, and service ( TABLE A-2 FrameManager LED Functions TABLE A-2 Function Operation Activated LED Power On when the RTS has been commanded to enable (green) switched power. Fault LED Fault On only when a fault condition exists somewhere in (amber) the frame.
Page 192: Figure A-6 Cpu/Memory Board With The Cover Removed
Location Sun Fire 6800 system SB0–SB5 Front Sun Fire 4810 system SB0, SB2, SB4 Front Sun Fire 4800 system SB0, SB2, SB4 Rear Sun Fire 3800 system SB0, SB2 Front A-10 Sun Fire 6800/4810/4800/3800 Systems Service Manual • April 2001...
Page 193: Cpu Processors
Note – Board slot numbers are marked on the chassis. A.5.1 CPU Processors Each CPU/Memory board has four CPU processors. If you do not have all four CPU processors installed, you must install a CPU processor filler panel to cover the unused CPU processor land area.
Page 194: I/O Assemblies
0, 1, 2, 4, 5, and 6 operate at 33 MHz, 64-bit, and 5V I/O. The PCI cards in slots 3 and 7 operate at 66 MHz, 64-bit, and 3.3V I/O. shows the PCI I/O assembly. FIGURE A-7 A-12 Sun Fire 6800/4810/4800/3800 Systems Service Manual • April 2001...
Page 195: Compact Pci I/O Assembly
PCI I/O Assembly FIGURE A-7 shows a PCI card. FIGURE A-8 PCI Card FIGURE A-8 A.6.2 Compact PCI I/O Assembly The CompactPCI I/O assembly for the Sun Fire 3800 system supports six CompactPCI I/O cards ( FIGURE A-9 Appendix A Functional Description A-13...
Page 196: Figure A-7 Pci I/O Assembly
Peak I/O throughput for the full-length PCI I/O slots (0, 1, 2, 4, 5, and 6) is 33 MHz, 64-bit and 5V I/O. Peak I/O throughput for the short PCI I/O slots (3 and 7) is 66/33 MHz, 64-bit, and 3.3V I/O. A-14 Sun Fire 6800/4810/4800/3800 Systems Service Manual • April 2001...
Page 197: Network Interfaces
Power Supplies There are three styles of power supplies. The Sun Fire 6800 and Sun Fire 4810 systems have one style of power supply. The Sun Fire 4800 system has the second style of power supply. The Sun Fire 3800 system has a third style of power supply.
Page 198: Figure A-10 Sun Fire 6800 And Sun Fire 4810 Systems Power Supply
Sun Fire 6800 and Sun Fire 4810 Systems Power Supply FIGURE A-10 Sun Fire 3800 System Power Supply FIGURE A-11 A-16 Sun Fire 6800/4810/4800/3800 Systems Service Manual • April 2001...
Page 199: Fan Trays
Number of Fan Trays, CPU Fan Trays, and Blower Assemblies TABLE A-6 System Type Total Number of Fan Trays and Blower Assemblies Sun Fire 6800 system 4 fan trays Sun Fire 4810 system 3 fan trays Sun Fire 4800 system...
Page 200: System Controller Board
Virtual domain keyswitches Network Solaris console for each domain Virtual time-of-day for each domain Environmental monitoring illustrates the System Controller board for the Sun Fire 6800/4810/4800 FIGURE A-13 systems. illustrates the System Controller board for the Sun Fire 3800 FIGURE A-14 system.
Page 201: Figure A-13 System Controller Board-Sun Fire 6800/4810/4800 Systems
System Controller Board—Sun Fire 6800/4810/4800 Systems FIGURE A-13 System Controller Board—Sun Fire 3800 System FIGURE A-14 Appendix A Functional Description A-19...
Page 202 A-20 Sun Fire 6800/4810/4800/3800 Systems Service Manual • April 2001...
Page 203: System Serial Number Locations And Rules For System Configuration
Your system serial number is needed whenever you make a service call. B.1.1 Location for the Sun Fire 6800 System The serial number location is in the rear of the system, to the left of the patch panel. FIGURE B-1...
Page 204: Figure B-1 Sun Fire 6800 System Serial Number Location
Serial number label location Sun Fire 6800 System Serial Number Location FIGURE B-1 Sun Fire 6800/4810/4800/3800 Systems Service Manual • April 2001...
Page 205: Location For The Sun Fire 4810 System
B.1.2 Location for the Sun Fire 4810 System The serial number location is in the front of the system, on top of the chassis, to the right. Serial number label location Sun Fire 4810 System Serial Number Location FIGURE B-2 Appendix B System Serial Number Locations and Rules for System Configuration...
Page 206: Location For The Sun Fire 4800 System
Sun Fire 4800 System Serial Number Location FIGURE B-3 B.1.4 Location for the Sun Fire 3800 System The serial number location is in the rear of the system, to the right of the FT0 and FT2 label. Sun Fire 6800/4810/4800/3800 Systems Service Manual • April 2001...
Page 207: Figure B-4 Sun Fire 3800 System Serial Number Location
Serial number label location Sun Fire 3800 System Serial Number Location FIGURE B-4 Appendix B System Serial Number Locations and Rules for System Configuration...
Page 208: Boards And Assemblies
Slots SB0, SB2, and SB4 in the Sun Fire 4810/4800 systems Slots SB0 and SB2 for the Sun Fire 3800 system 2. Requirement—For the Sun Fire 6800 system, the CPU/Memory boards are populated from left to right, beginning with SB0 and ending with SB5. For the Sun Fire 4810/4800 systems, the CPU/Memory boards are populated from left to right, beginning with SB0 and ending with SB2.
Page 209: I/O Assemblies
I/O Assemblies 1. Requirement—Install I/O assemblies in their designated slots: Slots IB6 – IB9 in the Sun Fire 6800 system Slots IB6 and IB8 in the Sun Fire 4810/4800/3800 systems 2. Requirement—Populate the I/O assemblies from right to left. That is, populate I/O locations IB6 and IB8 before you populate the left I/O locations, IB7 and IB9.
Page 210: System Controller Board
Note – The equivalent of two Repeater boards are integrated into the centerplane of the Sun Fire 3800 system. 2. Requirement—In the Sun Fire 6800 system, Repeater boards work in pairs, pair RP0 and RP1 and pair RP2 and RP3. A minimum of four Repeater boards must be installed.
Page 211: Fan Trays
1. Requirement —You must replace a defective fan tray assembly in order to prevent the system from overheating. 2. Requirement —The Sun Fire 6800 system needs a minimum of one fan tray in the front (FT1) and two fan trays in the rear (FT0 and FT2). The bottom CPU fan tray (FT3) is redundant and can be removed.
Page 212: Power Supplies
3. Requirement—The Sun Fire 6800 system has two power grids, grid 0 and grid 1. For the Sun Fire 6800 system, power supplies ps0, ps1, and ps2 are assigned to power grid 0, and power supplies ps3, ps4, and ps5 are assigned to power grid 1.
Page 213: Serial Port
B.6.2 Serial Port 1. Requirement—The only serial port is on the System Controller board. The serial port connector (DB-25) allows console access from a terminal or modem. If you attach a Y serial cable to the System Controller board serial port, you will have TTYA and TTYB connections.
Page 214 B-12 Sun Fire 6800/4810/4800/3800 Systems Service Manual • April 2001...
Page 215: Illustrated Parts Breakdown
A P P E N D I X Illustrated Parts Breakdown This appendix lists and illustrates the replacement parts (field-replaceable units or FRUs) covered in this book. Finding Part Numbers Note – Part numbers in this section may differ from those found in your system. Before ordering replacement parts, find the label on the part to be replaced and place your order using that number.
Page 216: Sun Fire 6800 System Replacement Parts
C.2.1 Sun Fire 6800 System Replacement Parts Front view Rear view Sun Fire 6800 System—Front and Rear Views FIGURE C-1 Sun Fire 6800/4810/4800/3800 Systems Service Manual • April 2001...
Page 217 Description Part Number Redundant System Controller board, SSC1 F501-5407 Master System Controller board, SSC0 F501-5407 Power supplies (up to 6), PS0 - PS5 F300-1459 Air inlet cover F240-3530 CPU/Memory boards w/ 2 CPUs, 750 MHz, 0MB memory, SB0–SB5 F540-4729 CPU/Memory boards w/ 4 CPUs, 750 MHz, 0MB memory, SB0–SB5 F540-4730 Fan tray, FT1 F540-3632...
Page 218: Figure C-2 Sun Fire 6800 System Cabinet
Front view Rear view Sun Fire 6800 System Cabinet FIGURE C-2 Description Part Number FrameManager F540-3883 Fan trays F540-3662 RTS Module F300-1396 RTU Assembly F300-1335 Sun Fire 6800/4810/4800/3800 Systems Service Manual • April 2001...
Page 219: Sun Fire 4810 System Replacement Parts
C.2.2 Sun Fire 4810 System Replacement Parts Sun Fire 4810 System Mounted in Optional Sun Fire Cabinet—Front View FIGURE C-3 Description Part Number Redundant System Controller board, SSC1 F501-5407 I/O assemblies (up to 2), IB6, IB8, PCI F540-4404 Master System Controller board, SSC0 F501-5407 Fan tray, FT0 F540-3639...
Page 220 Fan tray, FT1 F540-3639 AC input box F540-4346 Air inlet cover F240-3534 Air outlet cover F240-3535 System centerplane F501-5878 Power centerplane F501-5029 ID source board F501-5880 Cable, system centerplane power F530-2543 Sun Fire 6800/4810/4800/3800 Systems Service Manual • April 2001...
Page 221: Sun Fire 4800 System Replacement Parts
C.2.3 Sun Fire 4800 System Replacement Parts Sun Fire 4800 System—Rear View FIGURE C-4 Description Part Number I/O assemblies (up to 2), IB6, IB8, PCI F540-4404 Redundant System Controller board, SSC1 F501-4502 Master System Controller board, SSC0 F501-4502 Fan tray, FT0 F540-4345 AC input box, AC F540-4346...
Page 222: Figure C-5 Sun Fire 4800 System-Front View
Description Part Number Fan tray, FT1 F540-4344 Power supplies (up to 3), PS0–PS2 F300-1460 Centerplane F501-5877 ID source board F501-5880 Cable, system centerplane power F530-2886 Cable, fan, and I/O centerplane F530-2887 Sun Fire 6800/4810/4800/3800 Systems Service Manual • April 2001...
Page 223: Sun Fire 3800 System Replacement Parts
C.2.4 Sun Fire 3800 System Replacement Parts Sun Fire 3800 System—Front View FIGURE C-6 Description Part Number Redundant System Controller board, SSC1 F501-5563 CPU/Memory boards w /2 CPUs, 750 MHz, 0MB memory, SB0, SB2 F540-4729 CPU/Memory boards w/ 4 CPUs, 750 MHz, 0MB memory, SB0, SB2 F540-4730 Master System Controller board, SSC0 F501-5563...
Page 224: Figure C-7 Sun Fire 3800 System-Rear View
Sun Fire 3800 System—Rear View FIGURE C-7 Description Part Number Fan trays (up to 4), FT0–FT3 F540-4193 Power supplies (up to 3), PS0–PS2 F300-1441 C-10 Sun Fire 6800/4810/4800/3800 Systems Service Manual • April 2001...
Page 225: Cpu/Memory Board Replacement Parts
C.2.5 CPU/Memory Board Replacement Parts CPU/Memory Board FIGURE C-8 Description DIMMs Description Part Number DIMM (256 Mbyte) F501-5401 DIMM (512 Mbyte) F501-5030 DIMM (1Gbyte) F501-5031 Appendix C Illustrated Parts Breakdown C-11...
Page 226: I/O Assembly Replacement Parts
There are two styles of I/O assemblies: PCI and CompactPCI. The Sun Fire 3800 system has only the CompactPCI style of I/O assembly. PCI I/O Assembly FIGURE C-9 CompactPCI I/O Assembly FIGURE C-10 C-12 Sun Fire 6800/4810/4800/3800 Systems Service Manual • April 2001...
Page 227 Description System Part Number Figure Reference PCI I/O assembly Sun Fire 6800/4810/4800 systems F501-4404 FIGURE C-9 page C-12 CompactPCI I/O Sun Fire 3800 system F501-5531 FIGURE C-10 assembly page C-12 Appendix C Illustrated Parts Breakdown C-13...
Page 228: Repeater Board Replacement Part
C.2.7 Repeater Board Replacement Part Repeater Board FIGURE C-11 Description System Part Number Repeater board Sun Fire 6800/4810/4800 systems F501-4953 C-14 Sun Fire 6800/4810/4800/3800 Systems Service Manual • April 2001...
Page 229: System Controller Board
C.2.8 System Controller Board System Controller Board—Sun Fire 6800/4810/4800 Systems FIGURE C-12 System Controller Board—Sun Fire 3800 System FIGURE C-13 Appendix C Illustrated Parts Breakdown C-15...
Page 230: Power Supply Replacement Parts
C-15 FIGURE C-12 System Controller board Sun Fire 3800 system F501-5563 on page C-15 FIGURE C-13 C.2.9 Power Supply Replacement Parts Sun Fire 6800/4810 Systems Power Supply FIGURE C-14 C-16 Sun Fire 6800/4810/4800/3800 Systems Service Manual • April 2001...
Page 231: Figure C-15 Sun Fire 3800 System Power Supply
Sun Fire 3800 System Power Supply FIGURE C-15 Sun Fire 4800 System Power Supply FIGURE C-16 Appendix C Illustrated Parts Breakdown C-17...
Page 232: C.2.10 Filler Boards And Filler Panels Replacement Parts
Sun Fire 4810 system F540-4200 Power supply filler panel Sun Fire 6800/4810 systems F540-4075 Power supply filler panel Sun Fire 3800 system F540-4246 Power supply filler panel Sun Fire 4800 system F340-4931 C-18 Sun Fire 6800/4810/4800/3800 Systems Service Manual • April 2001...
Page 233: C.2.11 Cables Replacement Parts
Cable, universal power cord Sun Fire 6800/4800 systems and Sun Fire F180-1945 cabinet Cable, AC input power Sun Fire 6800 system and Sun Fire cabinet F180-1943 (North American, Asian) Cable, AC input power Sun Fire 6800 system and Sun Fire cabinet...
Page 234 C-20 Sun Fire 6800/4810/4800/3800 Systems Service Manual • April 2001...
Page 235: Glossary
The I/O assembly contains I/O cards such as network cards. There are two styles of I/O assemblies: PCI and CompactPCI. There are four I/O assemblies in the Sun Fire 6800 system and two I/O assemblies in the Sun Fire 4810/4800/ 3800 systems. The Sun Fire 3800 system, which has two I/O assemblies, supports only the CompactPCI I/O assembly.
Page 236 I/O assemblies together. In the Sun Fire 4800 and Sun Fire 4810 systems, you need only one Repeater board. However, in the Sun Fire 6800 system, the Repeater boards work in pairs. In the Sun Fire 3800 system, the equivalent of two Repeater boards is integrated into the active centerplane.
Page 237: Index
CPU/Memory board Ecache components, 3-3 description, A-11 cooling and power issues, 3-7 Ethernet, conﬁguration, B-10 description, A-10 ﬁller board, 1-4, B-9 ﬁller panel, 1-4, B-9 installing, 3-11 LEDs, 3-3 fan tray installing Sun Fire 6800 system, 9-6 LEDs, 9-5 Index-1...
Page 238 CPU/Memory board, 3-3 fan tray, 9-5 I/O assembly, 4-7, 5-5 power supply, 8-7 system controller board repeater board, 7-5 description, 6-2, A-18 system controller board, 6-8 ﬁller panel, 1-4, B-9 hanging, 6-9 Index-2 Sun Fire 6800/4810/4800/3800 Systems Service Manual • April 2001...
Page 239 installing, 6-12 LEDs, 6-8 removing, 6-10 reset switch, 6-9 resetting, 6-9 rules, B-8 system overview, A-1 system precautions, 1-3 tools required, 1-4 Index-3...
Page 240 Index-4 Sun Fire 6800/4810/4800/3800 Systems Service Manual • April 2001...

Sun Microsystems Fire 6800 Service Manual

Table of Contents

Figures

Preface

1 Safety and Tools Requirements

2 Powering off and on

3 Cpu/Memory Boards and Components

4 PCI I/O Assemblies and Components

5 Compactpci I/O Assemblies and Components

6 System Controller Board

7 Repeater Board

8 Power

9 Fan Trays

10 Centerplane and ID Source Boards

System

3 Attach a Wrist Strap or Foot Strap. Connect the ESD Jack from the System to Your Wrist Strap or Foot Strap. Place a Grounded ESD Mat Close to the System

4 Reaching into the Opening Created by Removing the I/O Assembly, Grasp the ID Source Board by the Edges and Remove It from the Centerplane

11 Patch Panel

12 Framemanager

Functional Description

System Serial Number Locations and Rules for System Configuration

Illustrated Parts Breakdown

Quick Links

Chapters

Need help?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Sun Microsystems Fire 6800

Summary of Contents for Sun Microsystems Fire 6800
