Sun Fire
™
This document describes how to update the doors and bolt your system to the floor.
Install the Door Supports
1. Unlock and open the cabinet door.
2. Pull down the upper hinge pin, lift the door off the lower hinge pin and remove the door.
Caution –
Do not perform Step 3 in the computer room. Drilling the metal door in the computer
room could lead to metal contamination.
3. Drill out the four rivets on the door that secure the door restraint bracket.
Use a number 30 or 1/8-inch drill bit.
4. Secure the new door restraint bracket using the four POP rivets provided. See figure.
The tool to secure the POP rivets is not provided.
Note –
This new door restraint provides both vertical and horizontal stability so the cabinet door doesn't
bend the upper and lower hinge brackets.
5. Reinstall the cabinet door.
6. Repeat Step 1 through Step 5 for the other cabinet door.
6800 System Hold-down Kit
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Sun Microsystems Sun Fire 6800
Summary of Contents for Sun Microsystems Sun Fire 6800
- Page 1 Sun Fire 6800 System Hold-down Kit ™ This document describes how to update the doors and bolt your system to the floor. Install the Door Supports 1. Unlock and open the cabinet door. 2. Pull down the upper hinge pin, lift the door off the lower hinge pin and remove the door. Caution –...
- Page 3 2. Move the system away from the operating location to provide space for drilling. Note – NEBS Zone 4 earthquake brackets have been tested by Sun Microsystems for installation directly to a concrete floor. As the performance of connection systems onto reinforced raised floors can vary, a qualified structural engineer should be consulted prior to installation on a raised floor.
- Page 4 5. Release the catches and remove the kick-panels. The kick-panels snaps off. 6. Remove the inner and outer kick-panel brackets. Discard the outer kick-panel brackets. Save the bolts andd the inner kick-panel brackets for Step 7. 7. Place the NEBS Zone 4 earthquake bracket between the new outer kick-panel bracket and the inner kick-panel bracket and secure the assembly to the cabinet using the existing bolts.
- Page 5 Sun is interested in improving its documentation and welcomes your comments and suggestions. You can submit your comments by going to: http://www.sun.com/hwdocs/feedback Please include the title and part number of your document with your feedback: Sun Fire 6800 System Hold-down Kit, part number 817-2664-12...
- Page 6 Copyright 2003 Sun Microsystems, Inc. All rights reserved. Use is subject to license terms. Third-party software, including font technology, is copyrighted and licensed from Sun suppliers. Portions may be derived from Berkeley BSD systems, licensed from U. of CA. Sun, Sun Microsystems, the Sun logo, and Solaris are trademarks or registered trademarks of Sun Microsystems, Inc.
