PROAIM CINEMA P-GH-30 Assembly Manual

Universal camera gimbal tripod head
Hide thumbs
1
2
3
4

Advertisement

Table of Contents

1
Universal Camera Gimbal Tripod Head (
P-GH-30)
A s s e m b l y M a n u a l
What's In The Box
Please inspect the contents of your shipped package to ensure you have received everything that is
listed below.
2 x Mounting Screws
Sizes: 1/4''-20 & 3/8''-16
Proaim
Universal Camera
Gimbal Tripod Head
All rights reserved.
No part of this document may be reproduced, stored in a retrieval system, or transmitted by any form or by any means,
electronic, mechanical, photo-copying, recording, or otherwise, except as may be expressly permitted by the applicable copyright
statutes or in writing by the Publisher.

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the CINEMA P-GH-30 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for PROAIM CINEMA P-GH-30

Summary of Contents for PROAIM CINEMA P-GH-30

  • Page 1 Please inspect the contents of your shipped package to ensure you have received everything that is listed below. 2 x Mounting Screws Sizes: 1/4′′-20 & 3/8′′-16 Proaim Universal Camera Gimbal Tripod Head All rights reserved. No part of this document may be reproduced, stored in a retrieval system, or transmitted by any form or by any means, electronic, mechanical, photo-copying, recording, or otherwise, except as may be expressly permitted by the applicable copyright statutes or in writing by the Publisher.
  • Page 2 Gimbal Tripod Head Setup  Mount and secure the gimbal head on the tripod. NOTE: The gimbal head mounts directly to tripods with a 3/8′′-16 threaded mount. In addition to that, we provide you with the conversion adapter for 1/4″-20 mounting, making it universally compatible with the tripods.
  • Page 3  By loosening the adjustment knob, the dovetail plate can move backward/forward shown in the image. NOTE: The Gimbal Head has a double dovetail plate with 1/4′′-20 and 3/8′′-16 mounting screws fastened by the platform adjustment knob. NOTE: Before use, ensure that the head is vertically and horizontally balanced camera (Not Included)
  • Page 4 YOUR PROAIM UNIVERSAL CAMERA GIMBAL TRIPOD HEAD ALL DRESSED UP AND READY TO GO! (SHOWN WITH OPTIONAL ACCESSORIES) Warranty: We offer one year warranty for our products from date of purchase. Within this period of time, we will repair it without charge for labor or parts. Warranty doesn’t cover transportation costs nor does it cover a product subjected to misuse or accidental damage.
