PROAIM AP-PTP-SCSR Assembly Manual

Mounting plate for scissor crane

Mounting Plate for Scissor Crane

(AP-PTP-SCSR)

A s s e m b l y M a n u a l

What's In The Box

Please inspect the contents of your shipped package to ensure you have received everything that is listed

below.

1 x 4mm Allen Key

Proaim Mounting Plate for Scissor Crane

No part of this document may be reproduced, stored in a retrieval system, or transmitted by any form or by any means,

electronic, mechanical, photo-copying, recording, or otherwise, except as may be expressly permitted by the applicable copyright

statutes or in writing by the Publisher.

Table of Contents

Need help?

Do you have a question about the AP-PTP-SCSR and is the answer not in the manual?

Page 1 Please inspect the contents of your shipped package to ensure you have received everything that is listed below. 1 x 4mm Allen Key Proaim Mounting Plate for Scissor Crane All rights reserved. No part of this document may be reproduced, stored in a retrieval system, or transmitted by any form or by any means, electronic, mechanical, photo-copying, recording, or otherwise, except as may be expressly permitted by the applicable copyright statutes or in writing by the Publisher.
Page 2 Mounting Plate Setup  Firstly, remove the fluid head (Not Included) attached to the 17ft Powermatic Scissor Jib by loosening the front and rear bolts using a 4mm Allen key.  Remove the bolts and then remove the Gimbal fluid head from the Powermatic scissor jib (Not Included).
Page 3  Attach the pan tilt head (Not Included) to the Scissor Crane Mounting plate by adequately aligning the hole and inserting the bolt, as shown in the image.  After inserting the bolt, insert the washer and wing nut from the top. ...
Page 4 YOUR PROAIM MOUNTING PLATE FOR SCISSOR CRANE ALL DRESSED UP AND READY TO GO! (SHOWN WITH OPTIONAL ACCESSORIES) Warranty: We offer one year warranty for our products from date of purchase. Within this period of time, we will repair it without charge for labor or parts. Warranty doesn’t cover transportation costs nor does it cover a product subjected to misuse or accidental damage.
