- Page 1 USER MANUAL SU12/UT12 FCS4053 Read the user manual before working on the device. Keep the manual with the device and pass the manual on to the next operator if the device is sold or transferred to a third party.
-
Page 3: Table Of Contents
Table of contents Franke Kaffeemaschinen AG TABLE OF CONTENTS For your safety .................... 4 Intended use .................... 4 Non-authorized use .................. 4 Explanation of safety instructions.............. 5 General safety concerns ................ 6 Scope of delivery.................. 12 Usage...................... 14 Installation .................... 14 Function.................... -
Page 4: For Your Safety
FOR YOUR SAFETY Intended use – The cooling unit is designed exclusively to keep milk and ready-to-drink beverages cool for the preparation of beverages with a Franke coffee ma- chine. – Only use pre-cooled milk and pre-cooled ready-to-drink beverages. – Remove the milk and ready-to-drink beverages when the cooling unit is not in use. -
Page 5: Explanation Of Safety Instructions
CAUTION CAUTION indicates a hazardous situation which, if not avoided, could result in minor or moderate injury. NOTICE NOTICE directs your attention to the risk of damage to machinery. User manual SU12/UT12... -
Page 6: General Safety Concerns
Do not immerse the appliance in liquid. d) Never disconnect the appliance from the power grid with wet hands. e) Disconnect the appliance from the power grid in the event of a leak or if liquid/moisture enters the appliance. User manual SU12/UT12... - Page 7 To minimize the risk of ignition, this device may only be installed by a spe- cialist authorized by Franke. c) The device must be installed in a room with sufficient space. d) Make sure that the device's ventilation openings are never blocked or ob- structed.
- Page 8 Do not place anything flammable on the hot surface of the heated cup tray. CAUTION Irritation from cleaners Cleaning tablets, milk system cleaning agents, and descaler can lead to irrita- tions of the skin or eyes. User manual SU12/UT12...
- Page 9 Germs in unpasteurized milk could pose a health hazard. a) Do not use any unpasteurized milk. b) Only use pasteurized or long-life milk. NOTICE Damage to the device Connection lines could be damaged by tensile load. Moisture entering the device can cause damage. User manual SU12/UT12...
- Page 10 Place the container lid with the suction hose on a clean surface only. NOTICE Formation of mold Mold can form if the appliance is empty for an extended period. a) Switch the appliance off. User manual SU12/UT12...
- Page 11 Only open the door of the appliance for as long as necessary. Do you have any questions that are not addressed in these instructions? Please do not hesitate to contact your local customer service partner, Franke Customer Service, or Franke Kaffeemaschinen AG in Aarburg.
-
Page 12: Scope Of Delivery
2 | Scope of delivery Franke Kaffeemaschinen AG SCOPE OF DELIVERY The scope of delivery may vary, depending on the device configuration. Addi- tional accessories may be obtained directly from your retailer or from Franke Kaffeemaschinen AG in Aarburg, Switzerland. Item description Material number... - Page 13 Scope of delivery | 2 Item description Material number Reversible adapter 560.0006.338 (SU12/UT12 FM CM (2OM)) Separating rail 560.0006.637 Wire basket 560.0651.743 (option for SU12/UT12 FM CM) (USA) Hose kit for milk bag 560.0664.869 (option for SU12/UT12 FM CM) (USA) User manual SU12/UT12...
-
Page 14: Usage
The cooling unit is designed exclusively to keep milk and other media (ready- to-drink beverages such as Cold Brew) cool for the preparation of beverages with a SB1200 Franke coffee machine. Only use precooled milk or media (2-5 °C). The cooling unit has the following functions: –... -
Page 15: Components Of The Cooling Unit
1 On/off switch for cooling unit 2 Temperature display and temperature control 3 Switch for milk/cleaning mode 4 On/off switch for heated cup tray (SU12) 5 Cleaning agent cartridge 6 Milk/medium container (1x12 l or 2x4.5 l) 7 Reversible adapter (milk feed/cleaning) - Page 16 Versions – SU12 with 12 l milk container – SU12 with 2 x 4.5 l milk containers for the use of 2 milk types – SU12 FM CM 2OM with 2 x 4.5 l medium containers for keeping 2 milk types (milk and milk drink) or 1 milk type and an additional ready-to-drink beverage (e.g.
-
Page 17: Operation And Care
Cleaners must not find their way into drinks. CAUTION Spoiled milk and ready-to-drink beverages Spoiled milk and spoiled ready-to-drink beverages could represent a health hazard. a) Use only fresh, refrigerated milk and fresh, refrigerated ready-to-drink beverages. User manual SU12/UT12... - Page 18 NOTICE Spoiled milk and ready-to-drink beverages Insufficient cooling or hygiene can cause milk and ready-to-drink beverages to spoil. a) Only use pre-cooled milk and pre-cooled ready-to-drink beverages (2,0-5,0 °C). User manual SU12/UT12...
- Page 19 Formation of mold Mold can form if the appliance is empty for an extended period. a) Switch the appliance off. b) Allow the appliance to defrost. c) Clean the appliance. d) Leave the door of the appliance open. User manual SU12/UT12...
-
Page 20: Malfunctions
• Interior chamber, inside of the door, tray and lip seal • Container(s) • Suction hoses • Plug-in couplings Cleaning of cup tray (SU12) 1. Switch off the heated cup 3. Clean the now cooled tray tray. with a damp microfiber cloth. -
Page 21: Decommissioning, Transport, Disposal
The appliance complies with European Directive 2012/19/EU regarding Waste Electrical and Electronic Equipment (WEEE) and must not be disposed of with household waste. Dispose of electronic parts separately. Dispose of plastic parts in accordance with their marking. User manual SU12/UT12... -
Page 22: Technical Data
Humidity (%) Max. 80 Electrical connection data Voltage Mains power Current con- Fuse Frequency connection sumption (max.) 100 V 1LNPE 1,7 A 10 A 50-60 Hz 110–127 V 1LNPE 1,7 A 10 A 60 Hz 220 V 1LNPE 0,8 A 10 A 50 Hz 220–240 V 1LNPE 0,8 A 10 A 50-60 Hz User manual SU12/UT12... - Page 24 Franke Kaffeemaschinen AG Franke Coffee Systems GmbH Franke-Str. 9 Franke Strasse 1 CH-4663 Aarburg 97947 Grünsfeld Switzerland Deutschland Tel. +41 62 787 31 31 Tel.: +49 9346 9278 0 www.franke.com Fax: +49 9346 9278 100 www.franke.de Franke Coffee Systems Franke Coffee Systems UK...
