  • Page 1: Table Of Contents

    Read this manual carefully before operating this vehicle. Location of important labels OWNER’S MANUAL Safety information Description Instrument and control functions For your safety – pre-operation checks Operation and important riding points Periodic maintenance and adjustment Motorcycle care and storage Specifications MOTORCYCLE Consumer information...
  • Page 2 EAU10045 Operating, servicing and maintaining a passenger vehicle or off-road vehicle can expose you to chemicals including engine exhaust, carbon monoxide, phthalates, and lead, which are known to the State of California to cause cancer and birth defects or other reproductive harm. To minimize exposure, avoid breathing exhaust, do not idle the engine except as necessary, service your vehicle in a well-ventilated area and wear gloves or wash your...
  • Page 3 Yamaha has met these standards without reducing the performance or economy of operation of the motorcycle. To maintain these high standards, it is important that you and your Yamaha dealer pay close attention to the recommended maintenance schedules and operating instructions contained within this manual.
  • Page 4 Important manual information EAU10134 Particularly important information is distinguished in this manual by the following notations: This is the safety alert symbol. It is used to alert you to potential personal injury hazards. Obey all safety messages that follow this symbol to avoid possible injury or death.

  • Page 5: Owner's Manual

    Important manual information EAU10194 XSR700P OWNER’S MANUAL ©2023 by Yamaha Motor Corporation, U.S.A. 1st edition, September 2022 All rights reserved. Any reprinting or unauthorized use without the written permission of Yamaha Motor Corporation, U.S.A. is expressly prohibited. Printed in Japan.
  • Page 6 Table of contents Location of important labels... 1-1 For your safety – pre-operation Adjusting the clutch lever free checks ..........5-1 play..........7-20 Safety information......2-1 Checking the brake lever free Operation and important riding play..........7-21 Description ........3-1 points ..........6-1 Brake light switches .....
  • Page 7 Diagnostic connector ....10-3 Vehicle data recording ....10-3 Reporting safety defects ....10-4 Motorcycle noise regulation ..10-5 Maintenance record ......10-6 YAMAHA MOTOR CORPORATION, U.S.A. 2020 AND LATER MODEL STREET & DUAL-PURPOSE MOTORCYCLE LIMITED WARRANTY .......10-8 YAMAHA EXTENDED SERVICE (Y.E.S.) ........10-10 Index ..........11-1...

  • Page 8: Location Of Important Labels

    Read and understand all of the labels on your vehicle. They contain important information for safe and proper operation of your vehicle. Never remove any labels from your vehicle. If a label becomes difficult to read or comes off, a replacement label is available from your Yamaha dealer.
  • Page 9 Location of important labels WARNING VACUUM HOSE ROUTING BEFORE YOU OPERATE THIS VEHICLE, READ PRESS. SENSOR THE OWNER’S MANUAL AND ALL LABELS. ALWAYS WEAR AN APPROVED MOTORCYCLE HELMET, eye protection, and protective clothing. 1TP-2118K-A2 INTAKE MANIFOLD 34B-21684-01 SOLENOID VALVE TIRE INFORMATION C ol d ti re no r ma l p ress ure sh o ul d b e s et a s f ol l ow s.

  • Page 10: Safety Information

    Safety information  Never operate a motorcycle with- pears to be very effective in reduc- EAU1028C out proper training or instruction. ing the chance of this type of Take a training course. Beginners accident. Be a Responsible Owner should receive training from a cer- Therefore: As the vehicle’s owner, you are re- tified instructor.
  • Page 11 Safety information  Many accidents involve inexperi- • Always signal before turning or Protective Apparel enced operators. In fact, many op- changing lanes. Make sure that The majority of fatalities from motorcy- erators who have been involved in other motorists can see you. cle accidents are the result of head in- ...
  • Page 12 Safety information  Do not run engine outdoors where Avoid Carbon Monoxide Poisoning When loading within this weight limit, All engine exhaust contains carbon engine exhaust can be drawn into keep the following in mind:  Cargo and accessory weight monoxide, a deadly gas.
  • Page 13 Yamaha accessories, which are avail- performed to your vehicle that change lightweight as possible and able only from a Yamaha dealer, have any of the vehicle’s design or operation should be kept to a minimum. been designed, tested, and approved characteristics can put you and others •...
  • Page 14 Safety information  Remove all loose items from the operator and may limit control ability, therefore, such accesso- motorcycle.  Check that the fuel cock (if ries are not recommended.  Use caution when adding electri- equipped) is in the off position and cal accessories.

  • Page 15: Description

    Description EAU10411 Left view 1. Fuel tank cap (page 4-14) 9. Coolant reservoir (page 7-14) 2. Seat lock (page 4-17) 3. Tool kit (page 7-2) 4. Shift pedal (page 4-12) 5. Engine oil filler cap (page 7-11) 6. Engine oil drain bolt (page 7-11) 7.

  • Page 16: Right View

    Description EAU10421 Right view 1. Fuses (page 7-33) 2. Battery (page 7-31) 3. Spring preload adjuster (page 4-17) 4. Headlight (page 7-35) 5. Brake pedal (page 4-12) 6. Rear brake fluid reservoir (page 7-22)

  • Page 17: Controls And Instruments

    Description EAU10431 Controls and instruments 1. Clutch lever (page 4-11) 2. Left handlebar switches (page 4-10) 3. Multi-function meter unit (page 4-4) 4. Main switch/steering lock (page 4-1) 5. Front brake fluid reservoir (page 7-22) 6. Right handlebar switches (page 4-10) 7.

  • Page 18: Instrument And Control Functions

    Instrument and control functions To lock the steering EAU10462 EAU10664 Main switch/steering lock All electrical systems are off. The key can be removed. EWA10062 WARNING Never turn the key to “OFF” or “LOCK” while the vehicle is moving. Otherwise the electrical systems will be switched off, which may result in LOCK loss of control or an accident.

  • Page 19: Indicator Lights And Warning

    6. Neutral indicator light “ ” then remain on until the engine is start- 7. High beam indicator light “ ” ed. Otherwise, have a Yamaha dealer 8. Right turn signal indicator light “ ” check the vehicle. ECA21211 EAU88280 NOTICE Turn signal indicator lights “...
  • Page 20 EAU88550 Engine trouble warning light “ ” stop the engine and have a Yamaha the vehicle as soon as possible. This warning light comes on if a prob- dealer check the vehicle. lem is detected in the engine. If this oc-...

  • Page 21: Multi-Function Meter Unit

    Instrument and control functions EAU92181 EAU94261 Multi-function meter unit The multi-function meter is controlled using the A and B buttons or the “TRIP/INFO” switch. See page 4-11 for “TRIP/INFO” switch. EAU94271 Switching the display units 1. “TRIP/INFO” switch To switch the display units between ki- ZAUM11328 lometers and miles, hold the “TRIP”...
  • Page 22 Instrument and control functions EAU87180 EAU94280 Tachometer Fuel meter If a problem is detected in the fuel me- ter electrical circuit, the fuel meter seg- ments, frame, and “ ” will flash repeatedly. Have the vehicle inspect- EAU90821 Eco indicator ZAUM1331 ZAUM1330 1.
  • Page 23 Instrument and control functions  Avoid high engine speeds during Use the “TRIP” switch/button B to cy- EAU94302 Multi-function display acceleration. cle between the information display  Travel at a constant speed. items in the following order:  Select the transmission gear that ODO →...
  • Page 24 Instrument and control functions To switch between “km/L” and “L/100 EAU94311 EAU94331 Tripmeters Instantaneous fuel consumption km” hold the “TRIP” switch/button B The tripmeters show the distance trav- display while the instantaneous fuel consump- eled since they were last reset. tion is visible on the display.
  • Page 25 Instrument and control functions  “AVE_ _._ L/100 km”: The average EAU90710 EAU90684 Coolant temperature display Air temperature display amount of fuel necessary to travel 100 km.  “AVE_ _._ MPG”: The average dis- tance that can be traveled on 1.0 US gal of fuel.
  • Page 26 Instrument and control functions 3. Turn the main switch to “ON” and EAU94293 Clock continue holding button B for 5  You can check the time even seconds until the display switches when the vehicle is off by pressing to the brightness control mode. button B.

  • Page 27: Handlebar Switches

    Instrument and control functions Right EAU1234T EAU12461 Handlebar switches Turn signal switch “ ” To signal a right-hand turn, push this Left switch to “ ”. To signal a left-hand turn, push this switch to “ ”. When released, the switch returns to the cen- ter position.

  • Page 28: Clutch Lever

    Instrument and control functions used in case of an emergency or to To use the “TRIP” switch, move the EAU12823 Clutch lever warn other drivers when your vehicle is “TRIP/INFO” switch in direction (a) stopped where it might be a traffic haz- (same function as button B on the mul- ard.

  • Page 29: Shift Pedal

    Instrument and control functions EAU12876 EAU26827 EAU12944 Shift pedal Brake lever Brake pedal 1. Shift pedal 1. Brake lever 1. Brake pedal 2. Distance The shift pedal is located on the left The brake pedal is located on the right 3.

  • Page 30: Abs

    Instrument and control functions EAU63041  The ABS performs a self-diagnos- The Yamaha ABS (Anti-lock Brake tic test each time the vehicle first System) features a dual electronic con- starts off after the key is turned to trol system, which acts on the front and “ON”...

  • Page 31: Fuel Tank Cap

    Instrument and control functions EAU13077 EAU13222 Fuel tank cap Fuel The fuel tank cap cannot be closed un- Make sure there is sufficient gasoline in less the key is in the lock. In addition, the tank. the key cannot be removed if the cap is EWA10882 WARNING not properly closed and locked.
  • Page 32 ECA11401 NOTICE EAU86100 Use only unleaded gasoline. The use Your Yamaha engine was designed to of leaded gasoline will cause severe use regular unleaded gasoline. Con- damage to internal engine parts, firm the pump octane number [(R+M)/2 such as the valves and piston rings, 1.

  • Page 33: Fuel Tank Overflow Hose

    Instrument and control functions EAU86160 EAU13435 Fuel tank overflow hose Catalytic converter See page 7-11 for canister information. The exhaust system contains catalytic converter(s) to reduce harmful exhaust emissions. EWA10863 WARNING The exhaust system is hot after op- eration. To prevent a fire hazard or burns: ...

  • Page 34: Seat

    Instrument and control functions EAU83140 EAU47003 Seat Adjusting the shock absorber assembly To remove the seat This shock absorber assembly is Insert the key into the seat lock, turn it equipped with a spring preload adjust- counterclockwise, and then pull the ing ring.

  • Page 35: Auxiliary Dc Connectors

     Do not subject the shock ab- iary DC connector and a grip warmer sorber assembly to an open DC connector. Consult your Yamaha flame or other high heat source. dealer before installing any accesso- This may cause the unit to ex- ries.

  • Page 36: Sidestand

    EAU15306 EAU44895 Sidestand Ignition circuit cut-off system Yamaha dealer repair it if it does not The sidestand is located on the left This system prevents in-gear engine function properly. side of the frame. Raise the sidestand...
  • Page 37 The neutral switch may not be working. 6. Move the sidestand up. The motorcycle should not be ridden until 7. Pull the clutch lever. checked by a Yamaha dealer. 8. Shift transmission into gear. 9. Move the sidestand down. Does the engine stall? The sidestand switch may not be working.

  • Page 38: For Your Safety - Pre-Operation Checks

    • If necessary, add recommended coolant to specified level. 7-14 Coolant • Check cooling system for leakage. • Check operation. • If soft or spongy, have Yamaha dealer bleed hydraulic system. • Check brake pads for wear. Front brake • Replace if necessary. 7-22, 7-22 •...
  • Page 39 • Make sure that operation is smooth. • Check throttle grip free play. 7-17, 7-27 Throttle grip • If necessary, have Yamaha dealer adjust throttle grip free play and lubricate ca- ble and grip housing. • Make sure that operation is smooth. Control cables 7-26 •...
  • Page 40 • Tighten if necessary. Instruments, lights, signals • Check operation. — and switches • Correct if necessary. • Check operation of ignition circuit cut-off system. Sidestand switch 4-19 • If system is not working correctly, have Yamaha dealer check vehicle.

  • Page 41: Operation And Important Riding Points

    ECA23060 NOTICE there is a control or function you do not between 0 and 1600 km (1000 mi). For understand, ask your Yamaha dealer. this reason, you should read the fol-  Keep the engine speed out of EWA10272 lowing material carefully.

  • Page 42: Starting The Engine

    Yamaha dealer check the vehicle. tion. Turn the vehicle power off To start the engine 3. Shift the transmission into the and then back on again to cancel 1.

  • Page 43: Shifting

    Operation and important riding points 3. Open the throttle gradually, and at EAU16675 ECA10262 Shifting NOTICE the same time, release the clutch  When shifting, press the shift lever slowly. pedal firmly until you feel the 4. At the recommended shift points gear shift is complete.

  • Page 44: Parking

    Operation and important riding points 3. When the motorcycle reaches 25 accident and injury. It could also EAU17214 Parking km/h (16 mph), the engine is about cause engine or drive train dam- When parking, stop the engine, and to stall or runs roughly, pull the age.

  • Page 45: Periodic Maintenance And Adjustment

    To avoid possible burns, let tivities incorrectly may increase brake components cool before your risk of injury or death during touching them. service or while using the vehicle. If you are not familiar with vehicle ser- vice, have a Yamaha dealer perform service.

  • Page 46: Tool Kit

    However, a torque wrench and other tools are necessary to perform certain maintenance work correctly. If you do not have the tools or experi- ence required for a particular job, have your Yamaha dealer perform it for you.

  • Page 47: Periodic Maintenance Chart For The Emission Control System

     From 24000 mi (37000 km) or 36 months, repeat the maintenance intervals starting from 8000 mi (13000 km) or 12 months.  Items marked with an asterisk require special tools, data and technical skills, have a Yamaha dealer perform the ser- vice.
  • Page 48 Periodic maintenance and adjustment INITIAL ODOMETER READINGS 600 mi 4000 mi 8000 mi 12000 mi 16000 mi 20000 mi ITEM ROUTINE (1000 km) (7000 km) (13000 km) (19000 km) (25000 km) (31000 km) 1 month 6 months 12 months 18 months 24 months 30 months •...

  • Page 49: General Maintenance And Lubrication Chart

    30 months 1 month • Perform dynamic inspection us- Diagnostic system √ √ √ √ √ √ ing Yamaha diagnostic tool. check • Check the error codes. Air filter element • Replace. Every 24000 mi (37000 km) √ √ √ √...
  • Page 50 Periodic maintenance and adjustment INITIAL ODOMETER READINGS 600 mi 4000 mi 8000 mi 12000 mi 16000 mi 20000 mi ITEM ROUTINE (1000 km) (7000 km) (13000 km) (19000 km) (25000 km) (31000 km) 1 month 6 months 12 months 18 months 24 months 30 months •...
  • Page 51 Periodic maintenance and adjustment INITIAL ODOMETER READINGS 600 mi 4000 mi 8000 mi 12000 mi 16000 mi 20000 mi ITEM ROUTINE (1000 km) (7000 km) (13000 km) (19000 km) (25000 km) (31000 km) 1 month 6 months 12 months 18 months 24 months 30 months Brake pedal pivot...
  • Page 52 • Change coolant. Front and rear √ √ √ √ √ √ 28 * • Check operation. brake switches • Apply Yamaha cable lubricant or √ √ √ √ √ √ 29 * Control cables other suitable cable lubricant thoroughly.
  • Page 53 Periodic maintenance and adjustment • Every two years replace the internal components of the brake master cylinders and calipers, and change the brake fluid. • Replace the brake hoses every four years or sooner if cracked or damaged.

  • Page 54: Checking The Spark Plugs

    1/2 turn past finger tight. However, the Yamaha dealer. Since heat and depos- with a wire thickness gauge and, if spark plug should be tightened to the its will cause any spark plug to slowly necessary, adjusted to specification.

  • Page 55: Canister

    Periodic maintenance and adjustment EAU36113 EAU60474 Canister Engine oil and oil filter car- tridge The engine oil level should be checked before each ride. In addition, the oil must be changed and the oil filter car- tridge replaced at the intervals speci- fied in the periodic maintenance and lubrication chart.
  • Page 56 Periodic maintenance and adjustment An oil filter wrench is available at a Yamaha dealer. 6. Apply a thin coat of clean engine oil to the O-ring of the new oil filter cartridge. 1. Engine oil filler cap 1. Engine oil drain bolt 2.
  • Page 57 Periodic maintenance and adjustment Recommended engine oil: See page 9-1. Oil quantity: Oil change: 2.30 L (2.43 US qt, 2.02 Imp.qt) With oil filter removal: 2.60 L (2.75 US qt, 2.29 Imp.qt) Be sure to wipe off spilled oil on any 1.

  • Page 58: Why Yamalube

    We form the periodic maintenance chart. gine off and have a Yamaha dealer teams of specialists in the fields of me- check the vehicle. Recommended coolant:...
  • Page 59 The coolant must be changed at the in- tervals specified in the periodic main- tenance and lubrication chart. Have a Yamaha dealer change the coolant. WARNING! Never attempt to remove the radiator cap when the engine is 1. Coolant reservoir cap hot.

  • Page 60: Replacing The Air Filter Element And Cleaning The Check Hose

    Yamaha dealer. placed at the intervals specified in the periodic maintenance and lubrication Engine idling speed: chart. Have a Yamaha dealer replace 1250–1450 r/min the air filter element more frequently if you are riding in unusually wet or dusty areas. However, the air filter check...

  • Page 61: Checking The Throttle Grip Free Play

    3.0–5.0 mm (0.12–0.20 in) proper tire pressure may cause se- Periodically check the throttle grip free vere injury or death from loss of play and, if necessary, have a Yamaha control.  The tire air pressure must be dealer adjust it.
  • Page 62 Never overload your vehicle. Opera- has a nail or glass fragments in it, or if characteristics. tion of an overloaded vehicle could the sidewall is cracked, have a Yamaha cause an accident. dealer replace the tire immediately. Minimum tire tread depth (front and rear): 1.0 mm (0.04 in)
  • Page 63 2. Tire air valve core ed below have been approved for this surfaces until they have been 3. Tire air valve cap with seal model by Yamaha. “broken in”. Therefore, it is ad- This model is equipped with tubeless visable before doing any high- Front tire: tires and rubber tire air valves.

  • Page 64: Cast Wheels

    2. Loosen the locknut at the crank- ride. If any damage is found, have case. a Yamaha dealer replace the wheel. Do not attempt even the smallest repair to the wheel. A de- formed or cracked wheel must be replaced.

  • Page 65: Checking The Brake Lever Free Play

    Yamaha dealer. 1. No brake lever free play There should be no free play at the brake lever end. If there is free play, have a Yamaha dealer inspect the brake system. EWA14212 WARNING A soft or spongy feeling in the brake lever can indicate the presence of air in the hydraulic system.

  • Page 66: Checking The Front And Rear Brake Pads

    EAU22393 EAU40262 Checking the front and rear Checking the brake fluid level Yamaha dealer replace the brake pads brake pads Before riding, check that the brake fluid as a set. is above the minimum level mark.
  • Page 67 Periodic maintenance and adjustment  Use only the specified brake flu- Rear brake fluid level goes down suddenly, have a Yamaha dealer check the cause before id; otherwise, the rubber seals may deteriorate, causing leak- further riding. age.  Refill with the same type of brake fluid.

  • Page 68: Changing The Brake Fluid

    EAU22734 EAU22762 Changing the brake fluid Drive chain slack Have a Yamaha dealer change the The drive chain slack should be brake fluid every 2 years. In addition, checked before each ride and adjusted have the seals of the master cylinders if necessary.
  • Page 69 3. Tighten the axle nut, and then EAU59921 To adjust the drive chain slack tighten the locknuts to the speci- Consult a Yamaha dealer before ad- fied torques. justing the drive chain slack. 1. Loosen the locknut at each end of...

  • Page 70: Cleaning And Lubricating The Drive Chain

    If a cable is wet areas. Service the drive chain as damaged or does not move smoothly, follows. have a Yamaha dealer check or re- place it. WARNING! Damage to the ECA10584 NOTICE outer housing of cables may result...

  • Page 71: Checking And Lubricating The Throttle Grip And Cable

    In pedals should be checked before each addition, the cable should be lubricat- ride, and the pedal pivots should be lu- ed by a Yamaha dealer at the intervals bricated if necessary. specified in the periodic maintenance Brake pedal chart.

  • Page 72: Checking And Lubricating The Brake And Clutch Levers

    EWA10732 Clutch lever WARNING If the sidestand does not move up and down smoothly, have a Yamaha dealer check or repair it. Otherwise, the sidestand could contact the ground and distract the operator, re- sulting in a possible loss of control.

  • Page 73: Lubricating The Rear Suspension

    The swingarm pivots must be lubricat- ce and hold it in an upright posi- sion must be lubricated by a Yamaha ed by a Yamaha dealer at the intervals tion. WARNING! To avoid injury, dealer at the intervals specified in the...

  • Page 74: Checking The Steering

    [EWA10752] the periodic maintenance and lubrica- 2. Hold the lower ends of the front have a Yamaha dealer check or re- tion chart. If there is play in the wheel fork legs and try to move them for- pair it.

  • Page 75: Battery

    Periodic maintenance and adjustment  Batteries produce explosive hy- 3. Remove the diagnostic connector EAUM3751 Battery by pulling it upward. drogen gas. Therefore, keep This model is equipped with a VRLA sparks, flames, cigarettes, etc., 4. Remove the battery cover by re- (Valve Regulated Lead Acid) battery.
  • Page 76 6. Install the diagnostic connector by To charge the battery switch off, then disconnect the pushing it downward. Have a Yamaha dealer charge the bat- negative lead before discon- 7. Install the seat holder by installing tery as soon as possible if it seems to necting the positive lead.

  • Page 77: Replacing The Fuses

    Periodic maintenance and adjustment EAUM3675 Replacing the fuses The main fuse and the fuse boxes are located under the seat. To access the fuses 1. Remove the seat. (See page 4-17.) 2. Remove the seat holder by remov- ing the bolts. 1.
  • Page 78 4. If the fuse immediately blows [EWA15132] again, have a Yamaha dealer Specified fuses: check the electrical system. Main fuse: 5. After the fuse is changed, place 30.0 A...

  • Page 79: Vehicle Lights

    Vehicle lights License plate light Supporting the motorcycle If the license plate light does not come on, have a Yamaha dealer check the electrical circuit or replace the bulb. 1. Headlight/Auxiliary light 1. Maintenance stand (example) Except for the license plate light bulb, Since this model is not equipped with a this model’s lights are all LED.

  • Page 80: Troubleshooting

    The following troubleshooting charts represent quick and easy procedures for checking these vital systems your- self. However, should your motorcycle require any repair, take it to a Yamaha dealer, whose skilled technicians have the necessary tools, experience, and know-how to service the motorcycle properly.

  • Page 81: Troubleshooting Chart

    Remove the spark plug and check the electrodes. The engine does not start. Have a Yamaha dealer check the vehicle. Check the compression. 4. Compression The engine does not start. There is compression.
  • Page 82 Start the engine. If the engine overheats again, have a The coolant level Yamaha dealer check and repair the cooling system. is OK. If coolant is not available, tap water can be temporarily used instead, provided that it is changed to the recommended cool- ant as soon as possible.

  • Page 83: Motorcycle Care And Storage

    Be performance and extend the useful life sure to wash the underside and sure to consult a Yamaha dealer for of many components. Washing, clean- chassis parts after riding in such ing, and polishing will also give you a advice on what products to use be- areas.
  • Page 84 Motorcycle care and storage  harsh chemicals, including 5. Remove road grime and oil stains been exposed to salt. Warm wa- strong acidic wheel cleaners, with a biodegradable degreaser ter will increase salt’s corrosive especially on spoke or magne- (YAMACLEAN Pro-Wash Spray) properties.
  • Page 85 Motorcycle care and storage  Make sure there is no lubricant 2. For drive chain-equipped models, 7. Wax all painted surfaces using a dry and then lubricate it to prevent non-abrasive wax or use a detail or wax on the brakes or tires. ...

  • Page 86: Storage

    Motorcycle care and storage 1. Make all necessary repairs and a. Remove the spark plug cap EAU84141 Storage perform any outstanding mainte- and spark plug. Always store the vehicle in a cool, dry nance. b. Pour a teaspoonful of engine place.
  • Page 87 Motorcycle care and storage 8. Check and correct the tire air pressure, and then lift the vehicle so that all wheels are off the ground. Otherwise, turn wheels a little once a month in or- der to prevent the tires from be- coming degraded in one spot.

  • Page 88: Specifications

    Specifications Dimensions: Coolant quantity: Starting system: Electric starter Overall length: Coolant reservoir (up to the maximum level Engine oil: 2075 mm (81.7 in) mark): Overall width: Recommended brand: 0.25 L (0.26 US qt, 0.22 Imp.qt) 820 mm (32.3 in) Radiator (including all routes): Overall height: 1.60 L (1.69 US qt, 1.41 Imp.qt) 1130 mm (44.5 in)
  • Page 89 Specifications Front tire: Battery: Type: Model: Tubeless YTZ10S Size: Voltage, capacity: 120/70 ZR 17 M/C (58W) 12 V, 8.6 Ah (10 HR) Manufacturer/model: Bulb wattage: MICHELIN/ROAD 5 Headlight: Rear tire: Type: Brake/tail light: Tubeless Size: Front turn signal/position light: 180/55 ZR 17 M/C (73W) Manufacturer/model: Rear turn signal light: MICHELIN/ROAD 5...

  • Page 90: Consumer Information

    Vehicle identification number ed when registering the vehicle with the authorities in your area and when EAU26442 Engine serial number ordering spare parts from a Yamaha dealer. VEHICLE IDENTIFICATION NUMBER: 1. Vehicle identification number ENGINE SERIAL NUMBER: The vehicle identification number is 1.
  • Page 91 This information will it for reference when ordering a new illustration. This label shows specifica- be needed when ordering spare parts key. tions related to exhaust emissions as from a Yamaha dealer. required by federal law, state law and Environment Canada. 10-2...

  • Page 92: Diagnostic Connector

    Consumer information Yamaha will not disclose this data to a EAU69910 EAU90250 Diagnostic connector Vehicle data recording third party except in the following cas- This model’s ECU stores certain vehi- es. In addition, Yamaha may provide cle data to assist in the diagnosis of...

  • Page 93: Reporting Safety Defects

    If you believe that your vehicle has a defect which could cause a crash or could cause injury or death, you should immedi- ately inform the National Highway Traffic Safety Administration (NHTSA) in addition to notifying Yamaha Motor Corporation, U.S.A. If NHTSA receives similar complaints, it may open an investigation, and if it finds that a safety defect exists in a group of vehicles, it may order a recall and remedy campaign.

  • Page 94: Motorcycle Noise Regulation

    Consumer information EAU26561 Motorcycle noise regulation TAMPERING WITH NOISE CONTROL SYSTEM PROHIBITED: Federal law prohibits the following acts or the causing thereof: (1) The removal or rendering inoperative by any person other than for purposes of maintenance, repair, or replacement of any device or element of design incorporated into any new vehicle for the purpose of noise control prior to its sale or delivery to the ultimate purchaser or while it is in use or (2) the use of the vehicle after such device or element of design has been removed or rendered inoperative by any person.

  • Page 95: Maintenance Record

    Consumer information EAU26633 Maintenance record Copies of work orders and/or receipts for parts purchased and installed on your vehicle will be required to document that maintenance has been completed in accordance with the emissions warranty. The chart below is printed only as a reminder that maintenance work is required.
  • Page 96 Consumer information Maintenance Date of Servicing dealer Mileage Remarks interval service name and address 36000 mi (55000 km) or 54 months 40000 mi (61000 km) or 60 months 10-7...
  • Page 97 Consumer information EAU61803 YAMAHA MOTOR CORPORATION, U.S.A. 2020 AND LATER MODEL STREET & DUAL-PURPOSE MOTORCYCLE LIMITED WARRANTY ENGINE Yamaha Motor Corporation, U.S.A. hereby warrants that Give notice to an authorized Yamaha motorcycle DISPLACEMENT each new Yamaha motorcycle purchased from an...

  • Page 98: Yamaha Motor

    CUSTOMER SERVICE What costs are my responsibility during the warranty period? If your machine requires warranty service, you must take it to any authorized Yamaha The customer’s responsibility includes all costs of normal maintenance services, motorcycle dealer within the continental United States. Be sure to bring your warranty non-warranty repairs, accident and collision damages, and oil, oil filters, air filters, registration card or other valid proof of the original date of purchase.

  • Page 99: Yamaha Extended Service (Y.e.s.)

    This excellent Y.E.S. plan coverage is only available to warranty. See the sample contract at your Yamaha Yamaha owners like you, and only while your Yamaha is still dealer to see how comforting uninterrupted factory- within the Yamaha Limited Warranty period. So visit your backed protection can be.
  • Page 100 TRIP coverage right away, and you’ll rest easy knowing you’ll have strong factory-backed protection even after your Yamaha Limited Warranty expires. A special note: If visiting your dealer isn’t convenient, contact Yamaha with your VIN number and we’ll be happy to help you get the YAMAHA EXTENDED SERVICE Y.E.S.

  • Page 101: Index

    Index Dimmer switch ........4-10 Display units, switching ......4-4 ABS............4-13 Main switch/steering lock....... 4-1 Drive chain, cleaning and lubricating ... 7-26 ABS warning light ........4-3 Maintenance and lubrication, periodic ... 7-5 Drive chain slack ........7-24 Air filter element and check hose, Maintenance, emission control replacing and cleaning .......
  • Page 102 Index Steering, checking ........7-30 Stop/Run/Start switch ......4-10 Storage ...........8-4 Supporting the motorcycle ....7-35 Swingarm pivots, lubricating ....7-29 Tachometer..........4-5 Throttle grip and cable, checking and lubricating...........7-27 Throttle grip free play, checking ...7-17 Tires ............7-17 Tool kit ............7-2 Transmission gear display ......4-6 TRIP/INFO switch .........4-11 Troubleshooting ........7-36 Troubleshooting chart......7-37...
  • Page 103 Yamalube – Take care of your Yamaha with legendary Yamalube oils, lubricants, and care products. They’re formulated and approved by the toughest judges we know: the Yamaha engineering teams that know your Yamaha from the inside out.
  • Page 104 This Owner’s manual is also available online at the Yamaha Owner’s Manual Library. https://www.yamahamotorsports.com/yamaha-manuals PRINTED IN JAPAN 2022.10-0.3×1 CR (E)
