LW Scientific M2-I Specifications

M2 LabScope
Head
Binocular (Seidentopf)
Trinocular with C-mount or eye tube
35mm and digital camera adapters available
Diopter adjustment
Inclined 30° (45° available), rotates 360°
10X/20 high point eyepieces (10X/22 available)
Interpupillary distance range 50-75mm
Nosepiece
Reverse quadruple nosepiece
Multiple ball bearing mounted
Objectives
Infinity Plan, DIN Plan, or DIN Semi-Plan objectives
4X, 10X, 40XR, 100XR (oil)
Anti-fungal, parfocal, parcentric, color-coded
Stage
Mechanical stage (160mm x 140mm)
Coaxial drive controls, metal rack & pinion
Range of traverse: 77mm x 50mm
Stage locking lever
Slow-close hydraulic slide finger
Dual slide holder
Focus
Coarse adjustment: range of 20mm
Fine adjustment: graduation of 2µm
Tension control knob
Illumination
Moveable Abbe condenser, NA 1.25
Iris diaphragm
Halogen light source (12V/20W bulb)
Variable light adjustment: 0-20W output
Input 90-240V / 50-60Hz automatic switching
Accessories Included
One 2 amp fuse, spare 12V/20W bulb, blue, green,
and yellow filters, dust cover, immersion oil, manual
and warranty card
Options
Ceramic stage, dark field condenser, phase contrast
turret, polarization and Koehler-type illumination
See pages 6 & 7 for additional accessories
Warranty
Lifetime on materials and workmanship
One year on electronic components
Dimensions and Weight
Height: 16 1/2" (420mm)
Length: 10 5/8" (270mm)
Width: 7 7/8" (200mm)
Weight: 19.5 lbs. (9kg)
On the web: www.lwscientific.com
865 Marathon Parkway - Lawrenceville, Georgia 30045 - Ph: 770-270-1394 - Fx: 770-270-2389
•
Laboratory Grade
•
4-Position Nosepiece
•
10X/20 High Point Eyepieces
The M2 modular series LabScope features
exceptional optical quality and expandability for
top-notch performance in the lab. The 10X/20
high-point Plan eyepieces on super-wide
eyetubes offer an extremely broad field of view,
with ample eye relief for users who wear
eyeglasses. Infinity Plan, DIN Plan, or DIN Semi-
plan optics match quality with value within any
clinic's budget. The M2 LabScope provides
comfort, durability, dependability and superior
imaging for the lifetime of the laboratory.
Part # Head
M2-S Binoc
M2-ST Trinoc
M2-P Binoc
M2-PT Trinoc
M2-I Binoc
M2-IT Trinoc
- email: sales@lwscientific.com
Objectives
4-10-40-100 DIN Semi-PLAN
4-10-40-100 DIN Semi-PLAN
4-10-40-100 DIN PLAN
4-10-40-100 DIN PLAN
4-10-40-100 DIN Infinity PLAN
4-10-40-100 DIN Infinity PLAN
