Pictorial index
AUTO
1
ACCESS SEAT
Maintenance
2
When trouble
3
arises
Index
This manual contains information about the AUTO
ACCESS SEAT. Refer to the "OWNER'S MANUAL" for
other information regarding your vehicle.
SIENNA_AAS_OM08011U_(U)
Search by illustration
Information regarding the AUTO ACCESS SEAT,
including usage procedure
Checking fuses and replacing the battery of the
wireless remote control
Points to check when you think a malfunction has
occurred
Alphabetical listing of information contained in this
manual

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Sienna and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Toyota Sienna

Summary of Contents for Toyota Sienna

  • Page 1 Pictorial index Search by illustration AUTO Information regarding the AUTO ACCESS SEAT, ACCESS SEAT including usage procedure Checking fuses and replacing the battery of the Maintenance wireless remote control When trouble Points to check when you think a malfunction has arises occurred Alphabetical listing of information contained in this...

  • Page 2: Table Of Contents

    TABLE OF CONTENTS Reading this manual ...... 4 Maintenance How to search........ 5 Pictorial index ........ 6 Maintenance AUTO ACCESS SEAT Checking and replacing fuses........38 Wireless remote control 1-1. AUTO ACCESS SEAT battery .......40 AUTO ACCESS SEAT ..8 Head restraint...... 10 When trouble arises Armrests......
  • Page 3 SIENNA_AAS_OM08011U_(U)

  • Page 4: Reading This Manual

    Reading this manual WARNING: Explains something that, if not obeyed, could cause death or serious injury to people. NOTICE: Explains something that, if not obeyed, could cause damage to or a malfunction in the vehicle or its equipment. 1 2 3 Indicates operating or working procedures.

  • Page 5: How To Search

    How to search Searching by name ■ • Alphabetical index ..P. 62 Searching installation ■ position • Pictorial index....P. 6 Searching by title ■ • Table of contents .....P. 2 SIENNA_AAS_OM08011U_(U)

  • Page 6: Pictorial Index

    Pictorial index Pictorial index Wireless remote control ......P. 16 Head restraint........P. 10 Armrests .
  • Page 7 AUTO ACCESS SEAT 1-1. AUTO ACCESS SEAT AUTO ACCESS SEAT..8 Head restraint ..... 10 Armrests......12 Footrest....... 13 Correct riding posture ..14 Wireless remote control ..16 1-2. Operating the AUTO ACCESS SEAT Before operating the AUTO ACCESS SEAT....20 Moving the AUTO ACCESS SEAT outside the vehicle......

  • Page 8: Auto Access Seat

    1-1. AUTO ACCESS SEAT AUTO ACCESS SEAT Seat position adjustment switch Seatback angle adjustment switch ■ Operating condition The seat position and seatback angle cannot be adjusted if the AUTO ACCESS SEAT is not stowed correctly inside the vehicle. ■ Seat movement amount The AUTO ACCESS SEAT can be moved 3.1 in.
  • Page 9 1-1. AUTO ACCESS SEAT WARNING Observe the following precautions. Failing to do so may cause death or serious injury in the event of sudden braking, sudden swerving or an accident. ■ Wearing a seat belt Read and follow the explanations and precautions under the “Seat belts” headings in Section 1-1 of the “OWNER’S MANUAL”.

  • Page 10: Head Restraint

    1-1. AUTO ACCESS SEAT Head restraint Head restraint is provided for the AUTO ACCESS SEAT. Pull the head restraint up. Down Lock Push the head restraint down while release pressing the lock release button. button ■ Removing the head restraint Pull the head restraint up while pressing the lock release button.
  • Page 11 1-1. AUTO ACCESS SEAT ■ Adjusting the height of the head restraint Make sure that the head restraint is adjusted so that the center of the head restraint is closest to the top of your ears. WARNING ■ Head restraint precautions Observe the following precautions regarding the head restraint.

  • Page 12: Armrests

    1-1. AUTO ACCESS SEAT Armrests Lower the armrests as far as they will go when rotating or rais- ing/lowering the AUTO ACCESS SEAT. Raise Lower ■ Wearing the seat belt Wearing the seat belt is easier with the armrest raised. WARNING ■...

  • Page 13: Footrest

    1-1. AUTO ACCESS SEAT Footrest Lower the footrest as far as it will go when rotating or raising/ lowering the AUTO ACCESS SEAT. Raise Lower WARNING ■ When operating the footrest Operate the footrest by holding the front edge. You may be injured if your fingers get caught in the rotating parts. SIENNA_AAS_OM08011U_(U)

  • Page 14: Correct Riding Posture

    1-1. AUTO ACCESS SEAT Correct riding posture Maintain the correct posture while sitting in the seat, as follows: Sit while keeping both knees aligned and inside the AUTO ACCESS SEAT. Lower the armrests and keep both arms inside the armrests and inside the AUTO ACCESS SEAT.
  • Page 15 1-1. AUTO ACCESS SEAT WARNING ■ When sitting in the seat ● When the seat is being used by a person who is unable to bend his/her knees or neck, or by a person that is unable to sit far back in the seat, be careful as their head, feet etc.

  • Page 16: Wireless Remote Control

    1-1. AUTO ACCESS SEAT Wireless remote control The wireless remote control can be used to rotate and raise or lower the AUTO ACCESS SEAT. Indicator light Seat raise switch Seat lower switch Effective range Approximately 3.3 ft. (1 m) from the AUTO ACCESS SEAT SIENNA_AAS_OM08011U_(U)
  • Page 17 1-1. AUTO ACCESS SEAT ■ Operating conditions ● The effective range of the wireless remote control changes in accordance with surroundings. ● Interference from other radio waves may cause the AUTO ACCESS SEAT to stop moving temporarily even when pressing the wireless remote control switches.
  • Page 18 Unlocking and locking the doors using the wireless remote control ■ When replacing either the transmitter or the receiver of the wireless remote control It is necessary to replace both the transmitter and the receiver. Contact your Toyota dealer. ■ Certification for the wireless remote control U.S.A. ...
  • Page 19 1-1. AUTO ACCESS SEAT WARNING ■ Wireless remote control precautions Observe the following precautions to reduce the risk of injury. ● Operate the AUTO ACCESS SEAT from a position from which you can see the occupant of the seat. ● Make sure that the occupant’s head, arms and legs will not get caught between the seat and the body of the vehicle.

  • Page 20: 1-2. Operating The Auto Access Seat

    1-2. Operating the AUTO ACCESS SEAT Before operating the AUTO ACCESS SEAT The AUTO ACCESS SEAT (right-hand second seat) can be rotated, raised and lowered electrically to help the seat occupant easily enter and exit the vehicle. Have all operations carried out by an assistant. Park the vehicle on a flat surface and leave the engine running.
  • Page 21 1-2. Operating the AUTO ACCESS SEAT Manual seat  Fold the front passenger seat- back while pulling the seatback angle adjustment lever. Power seat  Fold the front passenger seat- back by moving the seatback angle adjustment switch for- ward. Unfasten the seat belt on the AUTO ACCESS SEAT.
  • Page 22 1-2. Operating the AUTO ACCESS SEAT ■ Beep sounds The beep makes the following sounds in response to operating procedures and conditions. Beep Operation/Condition When the wireless remote control switches or the seat raise/lower switch is pressed and the AUTO ACCESS Once SEAT operates.
  • Page 23 1-2. Operating the AUTO ACCESS SEAT WARNING ■ When operating the AUTO ACCESS SEAT ● Do not operate while parked on an incline or on uneven ground. The occu- pant may fall from the seat or from their wheelchair, or you may be hit by the wheelchair while putting it away, possi- bly causing an injury.
  • Page 24 1-2. Operating the AUTO ACCESS SEAT WARNING ■ When operating the AUTO ACCESS SEAT ● Do not place luggage or hands and feet underneath around AUTO ACCESS SEAT. Hands and feet could get caught, possi- bly resulting in an injury. ●...
  • Page 25 1-2. Operating the AUTO ACCESS SEAT NOTICE ■ To prevent seat damage ● Before operating the AUTO ACCESS SEAT, make sure that there are no luggage items or other obstacles around the moving parts of the seat. The AUTO ACCESS SEAT may be damaged if it hits an obstacle. ●...

  • Page 26: Moving The Auto Access Seat Outside The Vehicle

    1-2. Operating the AUTO ACCESS SEAT Moving the AUTO ACCESS SEAT outside the vehicle Park the vehicle on a flat surface and leave the engine running. Shift the shift lever to P and set the parking brake. Confirm the following: •...
  • Page 27 1-2. Operating the AUTO ACCESS SEAT The beep will sound once, and the AUTO ACCESS SEAT will begin to move automatically. The indicator light on the wire- less remote control will flash. The AUTO ACCESS SEAT will rotate while the seatback reclines and while moving towards the front of the vehi- cle.
  • Page 28 1-2. Operating the AUTO ACCESS SEAT ■ Operating conditions Under the following conditions, the seat will not rotate or lower even if the seat lower switch is pressed. ● The right-hand sliding door is not opened completely. ● The seat belt is caught up in the AUTO ACCESS SEAT. ●...
  • Page 29 1-2. Operating the AUTO ACCESS SEAT WARNING ■ Before moving the AUTO ACCESS SEAT outside the vehicle ● Check that the right-hand third seat occupant is safe. ● Do not try to close the right-hand sliding door while operating AUTO ACCESS SEAT.

  • Page 30: Returning The Auto Access Seat To The Vehicle

    1-2. Operating the AUTO ACCESS SEAT Returning the AUTO ACCESS SEAT to the vehicle Park the vehicle on a flat surface and leave the engine running. Shift the shift lever to P and set the parking brake. Confirm the following: •...
  • Page 31 1-2. Operating the AUTO ACCESS SEAT The beep will sound once, and the AUTO ACCESS SEAT will begin to move automatically while the seat- back reclines. The indicator light on the wire- less remote control will flash. The AUTO ACCESS SEAT will rotate while the seatback raises and while moving towards the rear of the vehi-...
  • Page 32 1-2. Operating the AUTO ACCESS SEAT ■ Jam protection function If the operation of the AUTO ACCESS SEAT is interrupted by collision with an obstacle etc., the beep will sound twice and the seat will retreat slightly and then stop. If this happens, make sure that the hands, feet etc. of the occupant will not hit the body of the vehicle, and operate the seat once again after removing the obstacle.
  • Page 33 1-2. Operating the AUTO ACCESS SEAT WARNING ■ When the AUTO ACCESS SEAT has been returned to the vehicle ● Shake the AUTO ACCESS SEAT gently to check that the seat is stowed prop- erly. If not stowed properly, the seat may move unexpectedly, and could cause injuries.

  • Page 34: Operating With The Seat Raise/Lower Switch

    1-2. Operating the AUTO ACCESS SEAT Operating with the seat raise/lower switch If the battery of the wireless remote control has discharged or another malfunction has occurred, the seat raise/lower switch can be used to operate the AUTO ACCESS SEAT. (The AUTO ACCESS SEAT will operate in the same way as when operated using the wireless remote control).
  • Page 35 1-2. Operating the AUTO ACCESS SEAT ■ Seat raise/lower switch When the seat raise/lower switch is pressed, the beep will sound once and the AUTO ACCESS SEAT will begin to operate. The seat will not operate if the switch is pressed repeatedly. NOTICE ■...
  • Page 36 1-2. Operating the AUTO ACCESS SEAT SIENNA_AAS_OM08011U_(U)

  • Page 37: Maintenance

    Maintenance Maintenance Checking and replacing fuses ......... 38 Wireless remote control battery ....... 40 SIENNA_AAS_OM08011U_(U)

  • Page 38: Maintenance Checking And Replacing Fuses

    2. Maintenance Checking and replacing fuses If the AUTO ACCESS SEAT does not operate when the switches are pressed, a fuse may have blown. If this happens, check and replace the fuses as necessary. Fuse layout and amperage rating AUTO ACCESS SEAT ■...
  • Page 39 2. Maintenance ■ After a fuse is replaced Have the vehicle inspected by your Toyota dealer in the following situations. ● If the replaced fuse blows again. ● If the AUTO ACCESS SEAT does not operate. WARNING ■ To prevent system breakdowns and vehicle fire Observe the following precautions.

  • Page 40: Wireless Remote Control Battery

    2. Maintenance Wireless remote control battery Replace the battery with a new one if it is discharged. You will need the following items: ● Flathead screwdriver ● Lithium battery CR2032 Replacing the battery Remove the cover using a coin protected with tape etc. Remove the depleted battery using a flathead screwdriver.
  • Page 41 The wireless remote control will not function properly. ■ Use a CR2032 lithium battery ● Batteries can be purchased at your Toyota dealer, local electrical appliance shops or camera stores. ● Replace only with the same or equivalent type recommended by the Toyota dealer.
  • Page 42 2. Maintenance SIENNA_AAS_OM08011U_(U)

  • Page 43: When Trouble Arises

    When trouble arises When you think a malfunction has occurred AUTO ACCESS SEAT..44 If the AUTO ACCESS SEAT does not move while outside the vehicle .... 47 Wireless remote control ..59 SIENNA_AAS_OM08011U_(U)

  • Page 44: Auto Access Seat

    If the seat still does not operate even after trying the procedures, it is likely that the seat is malfunctioning. Do not use the AUTO ACCESS SEAT, and have the seat inspected by your Toyota dealer immediately. If the AUTO ACCESS SEAT does not move after being moved outside the vehicle P.
  • Page 45 3. When you think a malfunction has occurred Reason Correction procedure Start the engine. If the AUTO ACCESS SEAT is operated The engine is not running. while the engine is stopped and the vehi- cle battery is low, the AUTO ACCESS SEAT may stop during operation.
  • Page 46 3. When you think a malfunction has occurred If the AUTO ACCESS SEAT retreats a little and then stops Reason Correction procedure The AUTO ACCESS SEAT has Remove the obstacle and try operating hit an obstacle, or operation the AUTO ACCESS SEAT again. has been otherwise obstructed.

  • Page 47: If The Auto Access Seat Does Not Move While Outside The Vehicle

    If the AUTO ACCESS SEAT still does not move even after the fuses have been checked and replaced, have the seat inspected by your Toyota dealer. If the AUTO ACCESS SEAT stops moving while raising, lowering or rotating, or while it is outside the vehicle, you will not be able to close the right-hand sliding door.
  • Page 48 3. When you think a malfunction has occurred Press and hold the seat posi- tion adjustment switch on the right-hand side of the seat in either the front or back direction and, at the same time as press and hold the seat raise/lower switch in either the raise or lower direction for approxi- mately 10 seconds, until the...
  • Page 49 3. When you think a malfunction has occurred If the AUTO ACCESS SEAT moves when a switch is pressed ● Initialize the seat position information before conducting the opera- tions listed here. ● The movements of the seat while conducting these operations will be different from normal.
  • Page 50 3. When you think a malfunction has occurred Press the rear side of the seat position adjustment switch on the right-hand side of the seat, and slide the AUTO ACCESS SEAT toward the rear of the vehicle by 2 in. (5 cm). If the rear side of the seat position adjustment switch is pressed and held while the lower side of the...
  • Page 51 3. When you think a malfunction has occurred Press the rear side of the seat position adjustment switch on the right-hand side of the seat, and slide the AUTO ACCESS SEAT toward the rear of the vehicle until the beep sounds. If the rear side of the seat position adjustment switch is pressed and held while the lower side of the...
  • Page 52 3. When you think a malfunction has occurred Press and hold the front side of the seatback angle adjustment switch on the right-hand side of the seat until a long beep sounds. SIENNA_AAS_OM08011U_(U)
  • Page 53 3. When you think a malfunction has occurred If the AUTO ACCESS SEAT does not move even when a switch is pressed Before conducting this procedure, conduct the procedures explained in the “Initializing the seat position information” and “If the AUTO ACCESS SEAT moves when a switch is pressed”...
  • Page 54 3. When you think a malfunction has occurred Take combination wrench. Removal Replacement Combination wrench Remove the connector. Turn the bolt with yellow mark- using combination wrench, and move the AUTO ACCESS SEAT until the marks are aligned as shown in the illustration.
  • Page 55 3. When you think a malfunction has occurred Use the combination wrench to remove the 2 bolts on the underside AUTO ACCESS SEAT. Slide the AUTO ACCESS SEAT into the vehicle. Turn the bolt with yellow mark- using combination wrench, and move the AUTO ACCESS SEAT until the bolt can no longer be turned.
  • Page 56 3. When you think a malfunction has occurred Turn the bolt with yellow mark- ing clockwise using the combi- nation wrench, and slide the seat until the marks are aligned as shown in the illustration. If you are unable to slide the seat until marks aligned...
  • Page 57 Turn the power sliding door main switch off and close the right-hand sliding door manually. Have the seat inspected by your Toyota dealer immediately. The power sliding door will not operate if the AUTO ACCESS SEAT has been stowed inside the vehicle manually.
  • Page 58 3. When you think a malfunction has occurred WARNING ■ When stowing the AUTO ACCESS SEAT manually Do not put your feet or hands into the AUTO ACCESS SEAT stowage space. Your feet or hands may be caught in the movable parts of the AUTO ACCESS SEAT, which could cause injuries.

  • Page 59: Wireless Remote Control

    Use the seat raise/lower switch to operate the AUTO ACCESS SEAT (P. 34), and have the wireless remote control inspected by your Toyota dealer immediately. If the AUTO ACCESS SEAT does not move Reason Correction procedure Move to within approximately 3.3 ft.
  • Page 60 Replace the battery. (P. 40) control is discharged. If the indicator light is illuminated or flashing even though the wireless remote control switches are not being pressed Reason Correction procedure The wireless remote control may be Contact your Toyota dealer. malfunctioning. SIENNA_AAS_OM08011U_(U)

  • Page 61: Index

    Index Alphabetical index....62 SIENNA_AAS_OM08011U_(U)

  • Page 62: Alphabetical Index

    Alphabetical index Alphabetical index Armrests........12 Jam protection function ..28, 32 AUTO ACCESS SEAT....8 Maintenance Battery Checking and replacing Disconnecting ......8 fuses........38 Beep sounds ......22 Wireless remote control Before operating the seat ..20 battery ........40 Moving the seat outside the vehicle .......
  • Page 63 Alphabetical index When trouble arises AUTO ACCESS SEAT.... 44 If the seat does not move while outside the vehicle ..47 Wireless remote control ..59 When you think a malfunction has occurred AUTO ACCESS SEAT.... 44 If the seat does not move while outside the vehicle ..
  • Page 64 Alphabetical index SIENNA_AAS_OM08011U_(U)
