ASSEMBLY RATING
The Assembly Rating is a 5-point system that
shows the degree of effort needed in
assembling a specific product (with 1 being
easy and 5 being difficult). For some
products, two persons are recommended.
EASY
Assembly Instructions
DIFFICULT
CM3438T
Tools Required For Assembly:
Allen Wrench
2 PERSONS RECOMMENDED
Page 1 of 7
(Included)
Rev: 18-07-23
Advertisement
Related Manuals for Furniture of America CM3438T
Summary of Contents for Furniture of America CM3438T
- Page 1 Assembly Instructions For more information contact our team: service.ec@foagroup.com CM3438T ASSEMBLY RATING Tools Required For Assembly: The Assembly Rating is a 5-point system that shows the degree of effort needed in assembling a specific product (with 1 being Allen Wrench easy and 5 being difficult).
- Page 2 LOOSEN OVER TIME AND MAY CAUSE THE FURNITURE TO BE WOBBLY AND UNABLE TO SUPPORT ITS INTENDED WEIGHT CAPACITY. THIS MAY LEAD TO COLLAPSE AND MAY CAUSE SERIOUS INJURY. FAILURE TO FOLLOW THE GUIDELINES ABOVE MAY RESULT IN INJURY AND/OR PROPERTY DAMAGE. FURNITURE OF AMERICA.ALL RIGHTS RESERVED. Page 2 of 7...
- Page 3 Before you begin, please read Page 2 of "Assembly and Care Advice". And remember, do not tighten until each step is completed or instructed. #1 x 1pc #A x 4pcs Table Top Bolt Ø5/16"x3" #B x 20pcs #2 x 1pc Table Leaf Bolt Ø5/16"x1-1/2"...
- Page 4 Align mounting plate (#3) to the legs (#4), then secure by using bolts (#B) with washers (#C,D). #B x 6pcs #C x 6pcs #D x 6pcs Align cross bar (#5) to the legs (#4), then secure by using bolts (#A) with washers (#C,D). #A x 4pcs #C x 4pcs #D x 4pcs...
- Page 5 Attach wooden plugs (#6) to the holes of the legs (#4). Align legs (#4) to the table top (#1), then secure by using bolts (#B) with washers (#C,D). #B x 8pcs #C x 8pcs #D x 8pcs Page 5 of 7...
- Page 6 Unlock the table from the mechanism below. Extend table and insert the leaf (#2). Page 6 of 7...
- Page 7 Lock the leaf to table by using the mechanism below the table. ASSEMBLY IS COMPLETED Page 7 of 7...
