CM3431T
ASSEMBLY RATING
Tools Required for Assembly:
The Assembly Rating is a 5-point system that
shows the degree of effort needed in
Allen Wrench
(Included)
assembling a specific product (with 1 being
easy and 5 being difficult). For some
products, two persons are recommended.
DIFFICULT
EASY
2 PERSONS RECOMMENDED
Page 1 of 5
Rev.14-09-18
Advertisement
Table of Contents
Related Manuals for Furniture of America CM3431T
Summary of Contents for Furniture of America CM3431T
- Page 1 Assembly Instructions CM3431T ASSEMBLY RATING Tools Required for Assembly: The Assembly Rating is a 5-point system that shows the degree of effort needed in Allen Wrench (Included) assembling a specific product (with 1 being easy and 5 being difficult). For some products, two persons are recommended.
- Page 2 Page 2 of 5...
- Page 3 Before you begin, please read Page 2 of “Assembly and Care Advice”. And remember, do not tighten until each step is completed or instructed. Hardware List Parts List #A x 8 pcs #1 x 1 pc Bolt 5/16”x3” Table Top #B x 8 pcs #2 x 1 pc Lock Washer...
- Page 4 With the help of another person, carefully place the table top (#1) facing down on a protected surface. Align the 4 legs (#3) with the pre-drilled holes on the bottom corners of the table top (#1). III. Prepare 8 bolt assemblies by inserting FIRST the lock washer (#B) onto the bolt #A) and then the flat washer (#C) onto the SAME bolt (#A), in that order.
- Page 5 To insert the leaf (#2), unlock the latches located under the table top (#1). Once unlocked, slide outward on both ends of the outer two- piece table top (#1) until there is sufficient opening to place the leaf (#2). Then slide inward on both ends of the outer two-piece table top (#1) until they are touching and sitting flush with the leaf (#2).
