  • Page 1 TW-MR3220 3G/4G Wireless N Router Rev: 2.1.1 1910011711...
  • Page 2 No part of the specifications may be reproduced in any form or by any means or used to make any derivative such as translation, transformation, or adaptation without permission from TP-LINK TECHNOLOGIES CO., LTD . Copyright © 2016 TP-LINK TECHNOLOGIES CO., LTD. All rights reserved.
  • Page 3 FCC STATEMENT This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications.
  • Page 4 in conjunction with any other antenna or transmitter.” CE Mark Warning This is a class B product. In a domestic environment, this product may cause radio interference, in which case the user may be required to take adequate measures. Canadian Compliance Statement This device complies with Industry Canada license-exempt RSSs.
  • Page 5 cm de distance entre la source de rayonnement et votre corps. Industry Canada Statement CAN ICES-3 (B)/NMB-3(B) NCC Notice 注意！ 低功率電波輻射性電機管理辦法 依據 第十二條 經型式認證合格之低功率射頻電機，非經許可，公司、商號或使用者均不得擅自變更頻 加大功率或變更原設計之特性或功能 率、 。 低功率射頻電機之使用不得影響飛航安全及干擾合法通行 第十四條 ；經發現有干擾現象 時，應立即停用，並改善至無干擾時方得繼續使用。前項合法通信，指依電信規定作業之無線電 信。低功率射頻電機需忍受合法通信或工業、科學以及醫療用電波輻射性電機設備之干擾。 減少電磁波影響，請妥適使用。 BSMI Notice 安全諮詢及注意事項  請使用原裝電源供應器或只能按照本產品注明的電源類型使用本產品。  清潔本產品之前請先拔掉電源線。請勿使用液體、噴霧清潔劑或濕布進行清潔。 ...
  • Page 6 When product has power button, the power button is one of the way to shut off the product;  when there is no power button, the only way to completely shut off power is to disconnect the product or the power adapter from the power source. Don’t disassemble the product, or make repairs yourself.
  • Page 7 Hazard live parts Energy efficiency Marking Protection earth RECYCLING This product bears the selective sorting symbol for Waste electrical and electronic equipment (WEEE). This means that this product must be handled pursuant to European directive 2012/19/EU in order to be recycled or dismantled to minimize its impact on the environment.
  • Page 8 TP-LINK TECHNOLOGIES CO., LTD DECLARATION OF CONFORMITY For the following equipment: Product Description: 3G/4G Wireless N Router Model No.:TL-MR3220 Trademark: TP-LINK We declare under our own responsibility that the above products satisfy all the technical regulations applicable to the product within the scope of Council Directives:...

  • Page 9: Table Of Contents

    CONTENTS Chapter 1. Introduction ..................1 Overview of the Router ....................1 Conventions ........................1 Main Features ......................... 1 Panel Layout ........................2 1.4.1 The Front Panel ....................2 1.4.2 The Rear Panel ....................3 1.4.3 The Side Panel ....................3 Chapter 2.
  • Page 10 4.8.2 Port Triggering ....................46 4.8.3 DMZ ........................48 4.8.4 UPnP ......................... 49 Security ......................... 50 4.9.1 Basic Security ....................50 4.9.2 Advanced Security .................... 51 4.9.3 Local Management ................... 53 4.9.4 Remote Management ..................54 4.10 Parental Control ......................54 4.11 Access Control ......................
  • Page 11 Appendix C: Specifications..................90 Appendix D: Glossary ....................91 Appendix E: Compatible 3G/4G USB Modem ............93...

  • Page 12: Chapter 1. Introduction

    Chapter 1. Introduction 1.1 Overview of the Router TP-LINK understands the need for sharing the 3G/4G connection locally that benefits our end users. We realize the convenience with our latest wireless N 3G/4G Routers ----- they give you the freedom to quickly set up a stable and high speed wireless network, up to 150Mbps, on-the-go and share a 3G/4G connection.

  • Page 13: Panel Layout

    TL-MR3220 3G/4G Wireless N Router User Guide 1T2R MIMO, CCA technologies deliver greater coverage and higher speed  Wireless security encryption easily at a push of “WPS” button  WDS wireless bridge provides seamless bridging to expand your wireless network ...

  • Page 14: The Rear Panel

    TL-MR3220 3G/4G Wireless N Router User Guide Quick A wireless device failed to be added to the network by WPS Flash function.  Note: After a device is successfully added to the network by WPS function, the WPS LED will keep on for about 5 minutes and then turn off.

  • Page 15: Chapter 2. Connecting The Router

    DSL/Cable Modem to the WAN port of the Router (as shown in Figure 2-2). Please visit our website http://www.tp-link.com to get the latest USB modems compatibility, and we recommend you to check whether the modem in your hand has already been tested by us.
  • Page 16 TL-MR3220 3G/4G Wireless N Router User Guide...

  • Page 17: Chapter 3. Quick Installation Guide

    TL-MR3220 3G/4G Wireless N Router User Guide Chapter 3. Quick Installation Guide This chapter will show you how to configure the basic functions of your 3G/4G Wireless N Router using Quick Setup Wizard within minutes. 3.1 TCP/IP Configuration The default IP address of the 3G/4G Wireless N Router is 192.168.0.1. And the default Subnet Mask is 255.255.255.0.
  • Page 18 TL-MR3220 3G/4G Wireless N Router User Guide  Note: If the above screen does not pop-up, it means that your Web-browser has been set to a proxy. Go to Tools menu>Internet Options>Connections>LAN Settings, in the screen that appears, cancel the Using Proxy checkbox, and click OK to finish it. After successful login, you can click the Quick Setup to quickly configure your Router.
  • Page 19 TL-MR3220 3G/4G Wireless N Router User Guide 3G/4G Preferred  In this mode, the Router will try 3G/4G access first. If 3G/4G access fails and WAN access is valid, or if no 3G/4G USB modem is inserted, the Router would switch to WAN access.
  • Page 20 TL-MR3220 3G/4G Wireless N Router User Guide Configure the Wireless settings on the screen as shown below, then click Next. Wireless Radio - Enable or disable the wireless radio choosing from the pull-down list.  Wireless Network Name - Enter a value of up to 32 characters. The same name of ...
  • Page 21 TL-MR3220 3G/4G Wireless N Router User Guide For ASCII, the key can be made up of any numbers 0 to 9 and any letters A to Z, the length should be between 8 and 63 characters. For Hexadecimal, the key can be made up of any numbers 0 to 9 and letters A to F, the length should be between 8 and 64 characters.

  • Page 22: Chapter 4. Configuring The Router

    TL-MR3220 3G/4G Wireless N Router User Guide Chapter 4. Configuring the Router This chapter will show each Web page's key functions and the configuration way. 4.1 Login After your successful login, you will see the fifteen main menus on the left of the Web-based utility. On the right, there are the corresponding explanations and instructions.

  • Page 23: Quick Setup

    TL-MR3220 3G/4G Wireless N Router User Guide 4.3 Quick Setup Please refer to Section 3.2: "Quick Installation Guide." 4.4 WPS This section will guide you to add a new wireless device to an existing network quickly by WPS (Wi-Fi Protected Setup) function. Choose menu “WPS”, you will see the next screen as shown below.
  • Page 24 TL-MR3220 3G/4G Wireless N Router User Guide WPS Status - Enable or disable the WPS function here.  Current PIN - The current value of the Router's PIN displayed here. The default PIN of the  Router can be found in the label or User Guide. Restore PIN - Restore the PIN of the Router to its default.
  • Page 25 TL-MR3220 3G/4G Wireless N Router User Guide Step 3: Wait for a while until the next screen appears. Click Finish to complete the WPS configuration. The WPS Configuration Screen of wireless adapter Method Two: Step 1: Press the WPS/RESET button on the rear panel of the Router. Step 2: For the configuration of the wireless adapter, please choose Push the button on my access point in the configuration utility of the WPS as below, and click Next.
  • Page 26 TL-MR3220 3G/4G Wireless N Router User Guide configuration. The WPS Configuration Screen of wireless adapter Method Three: Step 1: Keep the default WPS Status as Enabled and click the Add device button, then the following screen will appear. Step 2: Choose Press the button of the new device in two minutes and click Connect.
  • Page 27 TL-MR3220 3G/4G Wireless N Router User Guide The WPS Configuration Screen of Wireless adapter Step 4: Wait for a while until the next screen appears. Click Finish to complete the WPS configuration. The WPS Configuration Screen of Wireless adapter II. By PIN If the wireless adapter supports Wi-Fi Protected Setup or Quick Secure Setup and the PIN method, you can add it to the network by PIN with the following two methods.
  • Page 28 TL-MR3220 3G/4G Wireless N Router User Guide Step 2: Choose Enter the new device's PIN and enter the PIN code of the wireless adapter in the field behind PIN in the above figure. Then click Connect.  Note: The PIN code of the wireless adapter is always displayed on the WPS or QSS configuration screen.
  • Page 29 TL-MR3220 3G/4G Wireless N Router User Guide The WPS Configuration Screen of Wireless adapter  Note: The default PIN code of the Router can be found in its label or the WPS configuration screen as Figure 4-2. You will see the following screen when the new device successfully connected to the network.

  • Page 30: Network

    TL-MR3220 3G/4G Wireless N Router User Guide 4.5 Network There are five submenus under the Network menu ( as shown above): Internet Access, 3G/4G, WAN, MAC Clone and LAN. Click any of them, and you will be able to configure the corresponding function.
  • Page 31 TL-MR3220 3G/4G Wireless N Router User Guide  Note: 1. If you are using the 3G/4G Preferred or WAN Preferred, the Router would connect, disconnect or switch the current access automatically. The Connect/Disconnect button (on 3G/4G, PPPoE, PPTP, L2TP) and some related parameters could not be set manually. 2.
  • Page 32 TL-MR3220 3G/4G Wireless N Router User Guide the Router to automatically re-establish your connection as soon as you attempt to access the Internet again. If you wish to activate Connect on Demand, click the radio button. If you want your Internet connection to remain active at all times, enter 0 in the Max Idle Time field.
  • Page 33 TL-MR3220 3G/4G Wireless N Router User Guide Location / Mobile ISP – These two fields will display the location and the ISP you have  selected in the previous page. While you tick the below option Set the Dial Number and APN manually, there will be no specific information in these two fields.

  • Page 34: Wan

    To add 3G/4G USB Modem entries, follow the steps below. 1. Download a most recent 3G/4G USB modem configuration file from our website (http://www.tp-link.com). 2. Click the Add New... button in the figure above, and then you will see below.
  • Page 35 TL-MR3220 3G/4G Wireless N Router User Guide This page will display the WAN IP parameters assigned dynamically by your ISP, including IP address, Subnet Mask, Default Gateway, etc. Click the Renew button to renew the IP parameters from your ISP. Click the Release button to release the IP parameters. MTU Size (in bytes) - The normal MTU (Maximum Transmission Unit) value for most ...
  • Page 36 TL-MR3220 3G/4G Wireless N Router User Guide IP Address - Enter the IP address in dotted-decimal notation provided by your ISP.  Subnet Mask - Enter the subnet Mask in dotted-decimal notation provided by your ISP,  usually is 255.255.255.0. Default Gateway - (Optional) Enter the gateway IP address in dotted-decimal notation ...
  • Page 37 TL-MR3220 3G/4G Wireless N Router User Guide User Name/Password - Enter the User Name and Password provided by your ISP. These  fields are case-sensitive. Secondary Connection - It’s available only for PPPoE Connection. If your ISP provides an  extra Connection type such as Dynamic/Static IP to connect to a local area network, then you can check the radio button of Dynamic/Static IP to activate this secondary connection.
  • Page 38 TL-MR3220 3G/4G Wireless N Router User Guide Only when you have configured the system time on System Tools -> Time page, will the Time-based Connecting function can take effect.  Connect Manually - You can click the Connect/ Disconnect button to connect/disconnect immediately.
  • Page 39 TL-MR3220 3G/4G Wireless N Router User Guide Click the Save button to save your settings. If your ISP provides BigPond Cable (or Heart Beat Signal) connection, please select BigPond Cable. And you should enter the following parameters as shown below: User Name/Password - Enter the User Name and Password provided by your ISP.
  • Page 40 TL-MR3220 3G/4G Wireless N Router User Guide down. Connect Manually - You can click the Connect/Disconnect button to connect/disconnect  immediately. This mode also supports the Max Idle Time function as Connect on Demand mode. The Internet connection can be disconnected automatically after a specified inactivity period and re-established when you attempt to access the Internet again.
  • Page 41 TL-MR3220 3G/4G Wireless N Router User Guide Connect on Demand - You can configure the Router to disconnect from your Internet  connection after a specified period of inactivity (Max Idle Time). If your Internet connection has been terminated due to inactivity, Connect on Demand enables the Router to automatically re-establish your connection as soon as you attempt to access the Internet again.
  • Page 42 TL-MR3220 3G/4G Wireless N Router User Guide User Name/Password - Enter the User Name and Password provided by your ISP. These  fields are case-sensitive. Dynamic IP/ Static IP - Choose either as you are given by your ISP and enter the ISP’s IP ...

  • Page 43: Mac Clone

    TL-MR3220 3G/4G Wireless N Router User Guide Connect Automatically - Connect automatically after the Router is disconnected. To use  this option, click the radio button. Connect Manually - You can configure the Router to make it connect or disconnect ...

  • Page 44: Lan

    TL-MR3220 3G/4G Wireless N Router User Guide Your PC's MAC Address - This field displays the MAC address of the PC that is  managing the Router. If the MAC address is required, you can click the Clone MAC Address button and this MAC address will fill in the WAN MAC Address field. Click Restore Factory MAC to restore the MAC address of WAN port to the factory default value.

  • Page 45: Wireless Settings

    TL-MR3220 3G/4G Wireless N Router User Guide Click any of them, and you will be able to configure the corresponding function. 4.6.1 Wireless Settings Choose menu “Wireless→Wireless Settings”, you can configure the basic settings for the wireless network on this page. Wireless Network Name - Enter a value of up to 32 characters.
  • Page 46 TL-MR3220 3G/4G Wireless N Router User Guide necessary to change the wireless channel unless you notice interference problems with another nearby access point. Mode - Select the desired mode. The default setting is 11bgn mixed.  11b only - Select if all of your wireless clients are 802.11b. 11g only - Select if all of your wireless clients are 802.11g.

  • Page 47: Wireless Security

    TL-MR3220 3G/4G Wireless N Router User Guide Key type - This option should be chosen according to the AP's security configuration.  It is recommended that the security type is the same as your AP's security type. WEP Index - This option should be chosen if the key type is WEP(ASCII) or ...
  • Page 48 TL-MR3220 3G/4G Wireless N Router User Guide notice in red as show below. Type - you can choose the type for the WEP security on the pull-down list. The default • setting is Automatic, which can select Open System or Shared Key authentication type automatically based on the wireless station's capability and request.

  • Page 49: Wireless Mac Filtering

    TL-MR3220 3G/4G Wireless N Router User Guide Radius Server IP - Enter the IP address of the Radius Server. • Radius Port - Enter the port that radius service used. • Radius Password - Enter the password for the Radius Server. •...
  • Page 50 TL-MR3220 3G/4G Wireless N Router User Guide To filter wireless users by MAC Address, click Enable. The default setting is Disabled. MAC Address - The wireless station's MAC address that you want to filter.  Status - The status of this entry either Enabled or Disabled. ...

  • Page 51: Wireless Advanced

    TL-MR3220 3G/4G Wireless N Router User Guide To modify or delete an existing entry: Click the Modify in the entry you want to modify. If you want to delete the entry, click the Delete. Modify the information. Click the Save button. For example: If you desire that the wireless station A with MAC address 00-0A-EB-00-07-8A and the wireless station B with MAC address 00-0A-EB-00-23-11 are able to access the Router, but all the other wireless stations cannot access the Router, you can configure the Wireless...

  • Page 52: Wireless Statistics

    TL-MR3220 3G/4G Wireless N Router User Guide Beacon Interval - Enter a value between 20-1000 milliseconds for Beacon Interval here.  The beacons are the packets sent by the Router to synchronize a wireless network. Beacon Interval value determines the time interval of the beacons. The default value is 100.

  • Page 53: Dhcp

    TL-MR3220 3G/4G Wireless N Router User Guide STA-ASSOC / STA-JOINED / WPA-Enterprise / WPA-Personal / WPA2-Enterprise / WPA2-Personal / AP-UP / AP-DOWN / Disconnected Received Packets - Packets received by the station  Sent Packets - Packets sent by the station ...

  • Page 54: Dhcp Clients List

    TL-MR3220 3G/4G Wireless N Router User Guide End IP Address - Specify an IP address for the DHCP Server to end with when assigning  IP addresses. 192.168.0.199 is the default end address. Address Lease Time - The Address Lease Time is the amount of time a network user ...
  • Page 55 TL-MR3220 3G/4G Wireless N Router User Guide MAC Address - The MAC address of the PC for which you want to reserve IP address.  Reserved IP Address - The IP address of the Router reserved.  Status - The status of this entry either Enabled or Disabled. ...

  • Page 56: Forwarding

    TL-MR3220 3G/4G Wireless N Router User Guide 4.8 Forwarding There are four submenus under the Forwarding menu (shown above): Virtual Servers, Port Triggering, DMZ and UPnP. Click any of them, and you will be able to configure the corresponding function. 4.8.1 Virtual Servers Choose menu “Forwarding→Virtual Servers”, you can view and add virtual servers in the...

  • Page 57: Port Triggering

    TL-MR3220 3G/4G Wireless N Router User Guide Enter the IP Address of the computer in the IP Address box. Select the protocol used for this application, either TCP or UDP, or All. Select the Enable check box to enable the virtual server. Click the Save button.
  • Page 58 TL-MR3220 3G/4G Wireless N Router User Guide Once the Router is configured, the operation is as follows: 1. A local host makes an outgoing connection using a destination port number defined in the Trigger Port field. 2. The Router records this connection, opens the incoming port or ports associated with this entry in the Port Triggering table, and associates them with the local host.

  • Page 59: Dmz

    TL-MR3220 3G/4G Wireless N Router User Guide either TCP or UDP, or All. Select Enable in Status field. Click the Save button to save the new rule. To modify or delete an existing entry: Click the Modify in the entry you want to modify. If you want to delete the entry, click the Delete.

  • Page 60: Upnp

    TL-MR3220 3G/4G Wireless N Router User Guide To assign a computer or server to be a DMZ server: Click the Enable radio button. Enter the local host IP Address in the DMZ Host IP Address field. Click the Save button. ...

  • Page 61: Security

    TL-MR3220 3G/4G Wireless N Router User Guide 4.9 Security There are four submenus under the Security menu as shown above: Basic Security, Advanced Security, Local Management and Remote Management. Click any of them, and you will be able to configure the corresponding function. 4.9.1 Basic Security Choose menu “Security →...

  • Page 62: Advanced Security

    TL-MR3220 3G/4G Wireless N Router User Guide PPTP Passthrough - Point-to-Point Tunneling Protocol (PPTP) allows the  Point-to-Point Protocol (PPP) to be tunneled through an IP network. To allow PPTP tunnels to pass through the Router, keep the default, Enable. L2TP Passthrough - Layer 2 Tunneling Protocol (L2TP) is the method used to enable ...
  • Page 63 TL-MR3220 3G/4G Wireless N Router User Guide Packets Statistics Interval (5~60) - The default value is 10. Select a value between 5  and 60 seconds from the drop-down list. The Packets Statistics Interval value indicates the time section of the packets statistics. The result of the statistics is used for analysis by SYN Flood, UDP Flood and ICMP-Flood.

  • Page 64: Local Management

    TL-MR3220 3G/4G Wireless N Router User Guide TCP-SYN-FLOOD Packets Threshold (5~3600) - The default value is 50. Enter a value  between 5 ~ 3600. When the current TCP-SYN-FLOOD Packets numbers is beyond the set value, the Router will startup the blocking function immediately. Ignore Ping Packet From WAN Port - Enable or Disable Ignore Ping Packet From WAN ...

  • Page 65: Remote Management

    TL-MR3220 3G/4G Wireless N Router User Guide RESET Button on the rear panel for about 5 seconds to reset the Router’s factory defaults on the Router’s Web-Based Utility. 4.9.4 Remote Management Choose menu “Security → Remote Management”, you can configure the Remote Management function in the screen as shown below.
  • Page 66 TL-MR3220 3G/4G Wireless N Router User Guide Parental Control - Check Enable if you want this function to take effect, otherwise check  Disable. MAC Address of Parental PC - In this field, enter the MAC address of the controlling PC, ...
  • Page 67 TL-MR3220 3G/4G Wireless N Router User Guide Select from the Effective Time drop-down list the schedule (e.g. Schedule_1) you want the entry to take effect. If there are not suitable schedules for you, click the Schedule in red below to go to the Advance Schedule Settings page and create the schedule you need. In the Status field, you can select Enabled or Disabled to enable or disable your entry.

  • Page 68: Access Control

    TL-MR3220 3G/4G Wireless N Router User Guide Enter “www.google.com” in the Allowed Domain Name field.  Select “Schedule_1” you create just now from the Effective Time drop-down list.  In Status field, select Enable.  4. Click Save to complete the settings. Then you will go back to the Parental Control Settings page and see the following list, as shown below.
  • Page 69 TL-MR3220 3G/4G Wireless N Router User Guide Enable Internet Access Control - Select the check box to enable the Internet Access  Control function, so the Default Filter Policy can take effect. Rule Name - Here displays the name of the rule and this name is unique. ...

  • Page 70: Host

    TL-MR3220 3G/4G Wireless N Router User Guide 1. Click “Access Control → Host” in the left to enter the Host Settings page. Add a new entry with the Host Description is Host_1 and MAC Address is 00-11-22-33-44-AA. 2. Click “Access Control → Target” in the left to enter the Target Settings page. Add a new entry with the Target Description is Target_1 and Domain Name is www.google.com.

  • Page 71: Target

    TL-MR3220 3G/4G Wireless N Router User Guide In the Mode field, select IP Address or MAC Address. If you select IP Address, the screen shown is above.  1) In Host Description field, create a unique description for the host (e.g. Host_1). 2) In LAN IP Address field, enter the IP address.
  • Page 72 TL-MR3220 3G/4G Wireless N Router User Guide Target Description - Here displays the description about the target and this description is  unique. Information - The target can be IP address, port, or domain name.  Modify - To modify or delete an existing entry. ...

  • Page 73: Schedule

    TL-MR3220 3G/4G Wireless N Router User Guide For example: If you desire to restrict the internet activities of host with MAC address 00-11-22-33-44-AA in the LAN to access www.google.com only, you should first follow the settings below: 1. Click Add New… button in Figure 4-55 to enter the Add or Modify an Access Target Entry page.
  • Page 74 TL-MR3220 3G/4G Wireless N Router User Guide Schedule Description - Here displays the description of the schedule and this description  is unique. Day - Here displays the day(s) in a week.  Time - Here displays the time period in a day. ...

  • Page 75: Advanced Routing

    TL-MR3220 3G/4G Wireless N Router User Guide 1. Click Add New... button shown in Figure 4-58 to enter the Advanced Schedule Settings page. 2. In Schedule Description field, create a unique description for the schedule (e.g. Schedule_1). 3. In Day field, check the Select Days radio button and then select Sat and Sun. 4.

  • Page 76: System Routing Table

    TL-MR3220 3G/4G Wireless N Router User Guide Click the Previous button to view the information in the previous screen. Click the Next button to view the information in the next screen. To add static routing entries: Click Add New… shown above, you will see the following screen. Enter the following data: Destination Network, Subnet Mask, Gateway.

  • Page 77: Bandwidth Control

    TL-MR3220 3G/4G Wireless N Router User Guide 4.13 Bandwidth Control There are two submenus under the Bandwidth Control menu as shown above. Click either of them, and you will be able to configure the corresponding function. The detailed explanations for each submenu are provided below. 4.13.1 Control Settings Choose menu “Bandwidth Control →...

  • Page 78: Ip & Mac Binding

    TL-MR3220 3G/4G Wireless N Router User Guide Egress bandwidth - This field displays the max and mix upload bandwidth through the  WAN port, the default is 0. Ingress bandwidth - This field displays the max and mix download bandwidth through the ...
  • Page 79 TL-MR3220 3G/4G Wireless N Router User Guide MAC Address - The MAC address of the controlled computer in the LAN.  IP Address - The assigned IP address of the controlled computer in the LAN.  Bind - Check this option to enable ARP binding for a specific device. ...

  • Page 80: Arp List

    TL-MR3220 3G/4G Wireless N Router User Guide 4.14.2 ARP List To manage the computer, you could observe the computers in the LAN by checking the relationship of MAC address and IP address on the ARP list, and you could configure the items on the ARP list also.

  • Page 81: Comexe.cn Ddns

    TL-MR3220 3G/4G Wireless N Router User Guide for DDNS service providers such as www.comexe.cn, www.dyndns.org, or www.no-ip.com. The Dynamic DNS client service provider will give you a password or key. 4.15.1 Comexe.cn DDNS If the dynamic DNS Service Provider you select is www.comexe.cn, the page will appear as shown below.

  • Page 82: Ip.com Ddns

    TL-MR3220 3G/4G Wireless N Router User Guide To set up for DDNS, follow these instructions: Type the User Name for your DDNS account. Type the Password for your DDNS account. Type the Domain Name you received from dynamic DNS service provider here. Click the Login button to log in to the DDNS service.

  • Page 83: System Tools

    TL-MR3220 3G/4G Wireless N Router User Guide Click the Login button to log in the DDNS service. Connection Status - The status of the DDNS service connection is displayed here. Click Logout to log out the DDNS service. 4.16 System Tools Choose menu “System Tools”, and you can see the submenus under the main menu: Time Settings, Diagnostic, Firmware Upgrade, Factory Defaults, Backup &...

  • Page 84: Diagnostic

    TL-MR3220 3G/4G Wireless N Router User Guide NTP Server I/II - Enter the address for the NTP Server, then the Router will get the time  from the NTP Server preferentially. In addition, the Router built-in some common NTP Servers, so it can get time automatically once it connects the Internet. To configure the system manually: Select your local time zone.
  • Page 85 IP Address/Domain Name - Type the destination IP address (such as 202.108.22.5) or  Domain name (such as http://www.tp-link.com) Pings Count - The number of Ping packets for a Ping connection.  Ping Packet Size - The size of Ping packet.

  • Page 86: Firmware Upgrade

     Note: 1) New firmware versions are posted at http://www.tp-link.com and can be downloaded for free. There is no need to upgrade the firmware unless the new firmware has a new feature you want to use. However, when experiencing problems caused by the Router rather than the configuration, you can try to upgrade the firmware.

  • Page 87: Factory Defaults

    TL-MR3220 3G/4G Wireless N Router User Guide otherwise, the Router may be damaged. 4) The Router will reboot after the upgrading has been finished. 4.16.4 Factory Defaults Choose menu “System Tools → Factory Defaults”, and you can restore the configurations of the Router to factory defaults on the following screen Click the Restore button to reset all configuration settings to their default values.

  • Page 88: Password

    TL-MR3220 3G/4G Wireless N Router User Guide Some settings of the Router will take effect only after rebooting, which include • Change the LAN IP Address (system will reboot automatically). • Change the DHCP Settings. • Change the Wireless configurations. •...
  • Page 89 TL-MR3220 3G/4G Wireless N Router User Guide Auto Mail Feature - Indicates whether auto mail feature is enabled or not.  Mail Settings - Set the receiving and sending mailbox address, server address, validation  information as well as the timetable for Auto Mail Feature, as shown below. From - Your mail box address.

  • Page 90: Statistics

    TL-MR3220 3G/4G Wireless N Router User Guide mailboxes that need User Name and Password to log in.  Note: Only when you select Authentication, do you have to enter the User Name and Password in the following fields. User Name - Your mail account name filled in the From field. The part behind @ is ...
  • Page 91 TL-MR3220 3G/4G Wireless N Router User Guide click the Enable button. If disabled, the function of DoS protection in Security settings will disabled. Packets Statistics Interval （5-60） - The default value is 10. Select a value between 5 and  60 seconds in the pull-down list.

  • Page 92: Appendix A: Faq

    TL-MR3220 3G/4G Wireless N Router User Guide Appendix A: FAQ How do I configure the Router to access Internet by ADSL users? First, configure the ADSL Modem configured in RFC1483 bridge model. Connect the Ethernet cable from your ADSL Modem to the WAN port on the Router. The telephone cord plugs into the Line port of the ADSL Modem.
  • Page 93 TL-MR3220 3G/4G Wireless N Router User Guide Some ISPs require that you register the MAC Address of your adapter, which is connected to your cable/DSL Modem during installation. If your ISP requires MAC register, login to the Router and click the "Network" menu link on the left of your browser, and then click "MAC Clone"...
  • Page 94 TL-MR3220 3G/4G Wireless N Router User Guide Figure A-5 Add or Modify a Virtual server Entry  Note: Your opposite side should call your WAN IP, which is displayed on the “Status” page. How to enable DMZ Host: Log in to the Router, click the “Forwarding” menu on the left of your browser, and click "DMZ"...
  • Page 95 TL-MR3220 3G/4G Wireless N Router User Guide Figure A-7 Basic Security I want to build a WEB Server on the LAN, what should I do? Because the WEB Server port 80 will interfere with the WEB management port 80 on the Router, you must change the WEB management port number to avoid interference.
  • Page 96 TL-MR3220 3G/4G Wireless N Router User Guide Figure A-9 Virtual Servers Figure A-10 Add or Modify a Virtual server Entry The wireless stations cannot connect to the Router. Make sure the "Wireless Router Radio" is enabled. Make sure that the wireless stations' SSID accord with the Router's SSID. Make sure the wireless stations have right KEY for encryption when the Router is encrypted.

  • Page 97: Appendix B: Configuring The Pcs

    TL-MR3220 3G/4G Wireless N Router User Guide Appendix B: Configuring the PCs In this section, we’ll introduce how to install and configure the TCP/IP correctly in Windows XP. First make sure your Ethernet Adapter is working, refer to the adapter’s manual if needed. Install TCP/IP component On the Windows taskbar, click the Start button, point to Settings, and then click Control Panel.
  • Page 98 TL-MR3220 3G/4G Wireless N Router User Guide The following TCP/IP Properties window will display and the IP Address tab is open on this window by default. You have two ways to configure the TCP/IP protocol below:  Setting IP address automatically Select Obtain an IP address automatically, Choose Obtain DNS server automatically, as shown in the Figure below: -87-...
  • Page 99 TL-MR3220 3G/4G Wireless N Router User Guide  Setting IP address manually a. Select Use the following IP address radio button. And the following items available b. If the Router's LAN IP address is 192.168.0.1, type IP address is 192.168.0.x (x is from 2 to 254), and Subnet mask is 255.255.255.0.
  • Page 100 TL-MR3220 3G/4G Wireless N Router User Guide Now click OK to keep your settings. -89-...
  • Page 101 TL-MR3220 3G/4G Wireless N Router User Guide Appendix C: Specifications General IEEE 802.11n, IEEE 802.11b, IEEE 802.11g, IEEE 802.3, IEEE Standards 802.3u, IEEE 802.1x, IEEE 802.11e, IEEE 802.11i, IEEE 802.3x Protocols TCP/IP, PPPoE, DHCP, ICMP, NAT, SNTP One RJ45 WAN port, Ports Four RJ45 LAN ports, One USB 2.0 WAN port (for 3G/4G network connection)
  • Page 102 TL-MR3220 3G/4G Wireless N Router User Guide Appendix D: Glossary 802.11n - 802.11n builds upon previous 802.11 standards by adding MIMO (multiple-input  multiple-output). MIMO uses multiple transmitter and receiver antennas to allow for increased data throughput via spatial multiplexing and increased range by exploiting the spatial diversity, perhaps through coding schemes like Alamouti coding.
  • Page 103 TL-MR3220 3G/4G Wireless N Router User Guide 152-bit shared key algorithm, as described in the IEEE 802.11 standard. Wi-Fi - A trade name for the 802.11b wireless networking standard, given by the Wireless  Ethernet Compatibility Alliance (WECA, see http://www.wi-fi.net), an industry standards group promoting interoperability among 802.11b devices.
  • Page 104 The UMTS/HSPA/EVDO USB modems we’ve tested in the field are listed below. You can find the latest compatibility list in our website: http://www.tp-link.com Compatible 3G/4G USB Modem (Tested in the field) E398(4G), E392(4G), E122, E1262, E1550, E1552, E156, E156B, E156C,...
