9.1.6 Power Supply technical data:

9.1.6.1 Characteristics:
Brand: GLOBTEK (HONG KONG) LTD
Frequency range: 50/60Hz
Input voltage: 100-240V
Output voltage: 5V
Input current: 0.2A
Output current: 1A

10 Failures guide

Tableau 3 : Failures guide
Problem
The monitor does not switch on.
The LED of the activator does not
switch on.
The RF communication between
monitor and capsule is not
working.
Inappropriate autonomy of the
monitor
Inappropriate autonomy of the
capsule
Probable cause
Monitor in sleep mode
The battery of the monitor is
discharged
The monitor is in end of life
The monitor may require a
maintenance action
The activator is not property
connected
The activator is in end of life
The activator may require
maintenance action
The distance is too large
The capsule is not associated
Non-recharged battery
Battery in end of life
Old battery
Incorrect connection
35
User Guide e-CELSIUS Performance.2
Solution
Check that the monitor is not in
sleep mode or deep sleep mode
Connect it on the mains supply
and wait few minutes before
interacting the monitor (on the
mains supply)
The manufacturing date is printed
on the label. The proper operation
of the monitor is warranted for
500 recharges cycles.
Return to your distributor or to the
manufacturer.
Ensure that the connections are
correct and the power outlet has
power
The manufacturing date is printed
on the label. The proper operation
of the activator is warranted for 2
years
Return to your distributor or to the
manufacturer
Ensure that the capsule is in the
range of the monitor, check the
date of the last temperature data
received.
Respect the activation process.
If the association is difficult,
ensure that the capsule is close
enough to the monitor or please
turn the capsule in the hole of the
activator.
The monitor indicates the number
of associated capsules.
Connect the monitor to the mains
supply and wait few minutes
before interacting with the monitor
(on the mains supply).
Scrap it to a DEEE organism.
Check the date printed on the
label.
Check that the cable is properly
connected.
