The monitor is in power supply mode. In this case, the screen is constantly switched on
without user action.

The monitor displays data temperature screen. This screen is very important for subject
monitoring. In this case, the monitor does not automatically go into standby.
In any case, to go or to come back to standby mode, you may simply press the side button of
the monitor, represented by the following logo:
and communicates with the associated pills.

6.7.12 Low battery

The monitor has a limited autonomy depending on usage (screen on / off, number of capsules
associated, etc ...).
Therefore, it is important to always check the battery level of the monitor when using the
monitor in battery mode. The orange/green LED allows you to be notified when the battery of
the monitor is in a critical state while you need to plug it in USB ASAP.
If not, however, the monitor is switched off without being recharged on time, you simply have
to put the monitor in charge (you may have to wait a few minutes before you can use the screen
again), and reset immediately the time on the monitor.
Indeed, the radiofrequency part will restart only when the date & time of the monitor has been
reset. Warning, if an invalid time is entered, the data may be corrupted.
This action of setting the time may be done directly on the monitor or through the e-
Performance Manager software. If capsules are associated, the time setting will only be
possible from the monitor interface.
While the battery is in charge, the battery logo turns purple and always filled (indicating the
state of charge and not the battery level). Once the cable is disconnected, the logo becomes
green and shows the real percentage of the battery.

6.7.13 Overview of the alarm system

The monitor combines three categories of alarms related to the state of the system.
The conditions for triggering and warning of each are summarized in the table below.
Function Alarm condition
controlled
Battery of the The
capsule autonomy
capsule will reach a
maximum
measures
Battery of the The
monitor monitor is low or critical
Loss of Black star if some data
communication are missing and orange
star
communication with the
pills is disrupted for
Delay due to
the alarm
condition
remaining 30
of the maximum in the
case of a real
of 500 time
communication
battery of the Immediate
Depends on the
sampling
if the frequency
previously set
25
In this mode, the monitor is still working
Alarm mode
seconds The message "Low"
appears in the column
Batt (Picture
Detailed visualization
screen of a capsule) of
detailed visualization
screen (§ 6.7.5).
Battery status
indicated by the LEDs
on the front side of the
monitor
Star Displayed
User Guide e-CELSIUS Performance.2
Priority
Low
20:
are Medium
Medium*
EN
