- Page 1 Electric Height Adjustable Three Leg Desk Frame Instruction Manual SKU: DESK-V133E Scan the QR code with your mobile device or follow the link for helpful videos and specifications related to this product. https://vivo-us.com/products/desk-v133e help@vivo-us.com www.vivo-us.com 1-800-371-5654...
- Page 2 TOOLS NEEDED WARNING! If you do not understand these directions, or if you have any doubts about the safety of the installation, please call a qualified technician. Check carefully to make sure there are no missing or Phillips defective parts. Improper installation may cause damage or serious injury. Do not use this product Screwdriver for any purpose that is not explicitly specified in this manual and do not exceed weight capacity.
- Page 3 STEP 2 STEP 5 Place lifting columns on telescopic Remove the screws in the center part of the crossbar as shown. Attach the fixing plate (H) to the crossbar (1), and align the holes on frame using the previously removed screws. Tighten all screws with screwdriver. the end of the extension crossbar (B) with the holes on the center lifting column (G) and telescopic...
- Page 4 Step 8 CAUTION! Place the tabletop on the desk, connect the desk to power and adjust the desk to the highest position. Attach the table top to the frame using the fifteen (S-B) screws, then attach the control panel to the frame using the two (S-C) screws.
- Page 5 Love your new VIVO setup and want to share? Tag us in your photo! @vivo_us If any parts are received damaged or defective, please contact us. We are happy to replace parts to ensure you have a fully functioning product.
