ASTEC Phoenix FURY Operation And Service Manual page 17

Burner Model PF-25
Maximum
2.9 GPM
Capacity
LF Oil Inlet
*
Pressure
*
New Design, Refer to Burner Profile Sheets
Discharge Line In Feet,
Burner Model 0' to 25'
PF-25 3/4"
PF-35 3/4"
PF-50 1"
PF-75 1"
PF-100 1"
1. For recommended pipe sizes, see Table 9.
2. Before attaching the fuel lines, purge the piping to remove scale, dirt, and other contaminates that
could clog and damage the fuel system.
3. Adjust the pressure control valve until the required oil pressure is achieved. (See the Individual
Burner Performance Data Sheets for the approximate settings.)
4. Depending on the system design, the final pump pressure will have to be adjusted to attain the
desired burner output.
5. The low oil pressure switch is factory set at 30 PSIG.
6. Leak test the piping before start-up, then check for leaks daily.
7. The manual low fire bypass oil control valve is used to set and maintain the low fire oil flow at the
burner. (See the Individual Burner Performance Data Sheets for the low fire oil setting.)
8. The high fire oil flow can be set by varying the fuel pressure, or by changing the valve profile in the
control system. (See the Individual Burner Performance Data Sheets for proper fuel flows.)
9. Oil flow rates can be checked with the inline oil flow meter in the fuel control valve train.
10. Oil flow rates can be confirmed using the nozzle pressure and the burner performance data sheet.
WARNING!
•
The settings are for the initial set-up only.
•
Final settings will have to be adjusted for the particular operating conditions.
•
Be sure not to have more fuel flow than there is combustion air available to burn or "puffing", and
a dangerously rich firing condition could occur.
OIL TRAIN SETTINGS
PF-35
4.1 GPM
50 PSI
PSI
Table 8 – Oil Train Settings
OIL LINE SIZES
Light Oil (Up to 100 SSU)
25' to 49' 50' to 100' 0' to 25'
3/4" 1" 1"
1" 1" 1"
1" 1" 1"
1" 1" 1"
1" 1-1/4" 1-1/4"
Table 9 – Minimum Oil Line Size for various lengths
Phoenix FURY - Operation and Service Manual
PF-50
5.9 GPM
*
PSI
Return Line In Feet,
25' to 49' 50' to 100'
1" 1"
1" 1"
1" 1-1/4"
1-1/4" 1-1/4"
1-1/4" 1-1/4"
17
PF-75 PF-100
8.8 GPM 11.7 GPM
88 PSI 108 PSI
Return Line In Feet,
Heavy Oil (Over 100 SSU)
0' to 25' 25' to 49' 50' to 100'
1" 1 1/4" 1 1/4"
1 1/4" 1 1/4" 1 1/4"
1-1/4" 1-1/4" 1-1/2"
1-1/4" 1-1/2" 2"
1-1/4" 1-1/2" 2"
