NOTE:
If the Gas run is more than 25', use the connection size on the burner shown in Table 2 below.
Burner Model PF-25
Pipe Size
(Minimum Dia.)
NOTE:
If the Gas run is 25 feet or less. Use the connection size on the burner shown in Table-3 below.
Burner Model PF-25
Pipe Size
(Minimum Dia.)
4. The supplied manual shutoff valve, must be installed upstream of the gas safety valve.
a. Shutoff valve facilitates servicing of the gas train.
b. The strainer protects the valves from destructive dirt that could lodge in them.
c. The Siemens double block gas valve has an integral strainer at the inlet.
5. The gas company should purge the main gas line for scale and dirt before it is attached to the burner
gas manifold.
NOTE:
Install the flexible fitting supplied with the burner gas manifold to reduce flexing of the manifold produced
by plant vibrations.
Burner Model PF-25
ASTEC
076046
Part Number
NOTE:
The low and high gas pressure switches should be set just above and below the safe operating range of
gas inlet pressures respectively. This should be individually determined on each installation. Typically this
would be 50% of the running pressure for the low gas pressure switch and 125% of the operating
pressure for the high gas pressure switch.
Burner Model PF-25
Maximum 25,000
Capacity Cu Ft/Hr
Gas Inlet
5.5 PSI
Pressure
Gas Inlet
Pipe Size
FEED PIPE SIZE, FOR GAS RUNS OVER 25 FEET
PF-35
4" 4"
Table 2 - Feed Pipe Size, for Gas Runs Over 25 Feet
FEED PIPE SIZE, FOR GAS RUNS 25 FEET OR UNDER
PF-35
4" 4"
Table 3 - Feed Pipe Size, for Gas Runs 25 Feet or Under
ASTEC PART NUMBERS, FLEXIBLE PIPE NIPPLES
PF-35
076046
Table 4 - Recommended Pipe Nipple
NATURAL GAS REGULATOR REQUIREMENTS
PF-35
35,000
Cu Ft/Hr
5.5 PSI
4" 4"
Table 5 - Natural Gas Regulators
Phoenix FURY - Operation and Service Manual
PF-50
4"
PF-50
4"
PF-50
076046 048292
PF-50 PF-75
50,000 75,000
Cu Ft/Hr Cu Ft/Hr
5.5 PSI 5.5 PSI
4"
14
PF-75 PF-100
6" 6"
PF-75 PF-100
4" 4"
PF-75 PF-100
048292
PF-100
100,000
Cu Ft/Hr
5.5 PSI
6" 6"
