Power Key
Reset Key
SD Card Slot
Lens
Power Light
Microphone
PIR Sensor
Working
Status Light
Speaker
USB Charge
Port
Thumb Screw
Wi-Fi
Antenna
Press and hold the power button for 5 seconds to
turn on the camera
Press and hold RESET for 5 seconds to reset the
device (if you have modified the settings, they will
revert to the factory default settings)
Support local SD card storage (up to 128G)
Support FHD 1080P resolution
Red means charging is in progress
Blue means charging is complete
Capture sound for your videos
Can detect moving objects up to 10 meters away
Red light continuously on: camera network
abnormal
Red light flashing slowly: waiting for Wi-Fi
connection
Red light flashing fast: Wi-Fi connection in
progress
Blue light continuously on: camera is running
normally
Two-way voice call sound output
Use 5V/2A power supply to charge the camera
For fixing the camera and the bottom bracket
Using 3DB signal antenna
