Exaco HOKLARTHERM Riga XL 5 Assembly Instructions Manual

Aluminium greenhouse
Hide thumbs Also See for HOKLARTHERM Riga XL 5:

Advertisement

Quick Links

Download this manual
ALU MI NI UM
Greenhouse
Riga XL Factory Manual
Version 2.2021
Assembly
Instructions
Riga XL 5, 6, 7, 8, 9
www.exaco.com
Assembly Animation Video
is available on our YouTube page,
877-760-8500
find the link at www.exaco.com or
customerservice@exaco.com
scan the QR code above.

Advertisement

loading
Need help?

Need help?

Do you have a question about the HOKLARTHERM Riga XL 5 and is the answer not in the manual?

Questions and answers

Related Manuals for Exaco HOKLARTHERM Riga XL 5

Summary of Contents for Exaco HOKLARTHERM Riga XL 5

  • Page 1 ALU MI NI UM Greenhouse Riga XL Factory Manual Version 2.2021 Assembly Instructions Riga XL 5, 6, 7, 8, 9 www.exaco.com Assembly Animation Video is available on our YouTube page, 877-760-8500 find the link at www.exaco.com or customerservice@exaco.com scan the QR code above.
  • Page 2 If you are missing a box or if any of the boxes are damaged - write this on the Bill of Lading before the driver leaves. Notify Exaco as soon as possible if any of the boxes are damaged or missing.

  • Page 3: What You Will Need

    Important note regarding polycarbonate glazing during assembly: The ISO-celluar sheets (polycarbonate glazing) must be placed with the UV-coated side to the outside. On the protective film, there will be a corresponding note indicating "UV" or "2UV", most panels should be coated on both sides, but if you are unsure, please give us a call. Loosen the protection film only at the edge and the complete rest of the foil only after the panel is securely in place.
  • Page 4 Recommended Support Structure for Riga XL Assembly (7,8,9) Wh e n a s s e mb l i n g g r e e n h o u s e s o f t h i s l e n g t h , we r e c o mme n d c o n t s t r u c t i n g s u p p o r t s f r o m 2 x 4 s t o s u p p o r t t h e r i d g e p r o fi...
  • Page 5 Packaging Counts and Contents: Depending on the size greenhouse you have, your box count will vary. Quantity Content table Basic construc- Page 6 Gables tions Basic construc- Page 6 Long parts (with fl oor profi le - gable) tions You may have additional smaller boxes of roof Page 8 und 9 Roof window/door windows depending on model size...
  • Page 6 Contents of main box - basic construction components. Note: Some of this inventory section does not include XL 7, 8, 9. Please refer to the XL 7, 8, 9 parts list that you have been sent. Profi les for both gables: Quan- Length Profi...
  • Page 7 Accessories bag basic construction Part design Pos. Description Quantity 100 Plastic corner connector 101 Straight connector plate for cross bars above doors 102 T-connector slanted for door upright and edge clamp 103 T-connector door profi les to cross bars vertical profi le middle/cross bar/ 104 T-connector slanted edge clamp 105 Floor profi...
  • Page 8 Profi les for each roof window Quan- Length Profi le design Pos. Description tity [mm] Window profi le - roof Window profi le - roof Profi les for each divided revolving door - at the bottom Quan- Length Profi le design Pos.
  • Page 9 Accessories bag for divided revolving door - at the bottom Quan- Length Part Design Pos. Description tity [mm] 135 Hinge 136 Sash lock 137 End cap for rectangular tube 138 T-seal 139 Phillips head screw 4,8 x 25 (for hinges) 140 Phillips head screw 4,8 x 16 (for hinges) 112 Phillips head screw 4,2 x 60...
  • Page 10 Connecting Long Profiles NOTE: Connectors are now shorter with 4 set screws (not 6) Ridge Beam shown below. Floor profile and foundation profile (if using) will also be connected using connectors with 4 set screws.
  • Page 11 Extra Bracing for Riga XL 7/8/9 ONLY Assembly of the bracing Length Dimensions Pos. Profile/part design Description Quantity [mm] [mm] 1 (XL7) Bracing strut 1980 30 x 4 2 (XL8) 3 (XL9) 2 per SM11 Hexagon head screw M6 x 55 bracing strut 2 per SM30...
  • Page 12 Extra Bracing for Riga XL 7/8/9 ONLY Assembly of the bracing strut Step 2 Slot for the bracing strut in the curved center profiles Step 3 curved center profile hexagon head screw M6 x 55 with nut M6 curved center profile bracing strut 30 x 4 bracing strut 30 x 4 hexagon head screw...
  • Page 13 Attaching the foundation frame (optional accessory) Profiles and hardware for foundation frame: Quantity/Length in mm Profile/part design Pos. Description Typ IV Typ V Typ VI Foundation frame profile for gable 4085 4085 4085 Foundation frame profile for the sides 3864 4859 5853 Note: Foundation frame profiles are...
  • Page 14 Anchoring the greenhouse to your own foundation Mounting brackets to attach base/floor profile to existing foundation. Quantity/Length in mm Part design Pos. Description Typ IV Typ V Typ VI Mounting brackets XL Hexagon head screw M6 x 12 + nut M6 Note: You will need to insert 2 bolts (M6 x 12) in each vertical profile (gable ends and curved profiles) to...
  • Page 15 Foundation plan Riga XL Construction of your greenhouse with a concrete perimeter or strip foundation If you did not buy a foundation frame, the greenhouse has to be erected safely by means of a perimeter/strip foundation. Please build this according to the dimensions in the chart below.
  • Page 16 Gable Assembly - Start with the assembly of the gables - front and rear gables are identical. Warning: If you are using the foundation frame, it has to be attached to the base profiles FIRST! (Page 8) Step 1 Attention: Before Step 2 Ensure top assembly, insert...
  • Page 17 Step 7 View from inside Connect Crossbar (pos. 8) with straight connector plate (pos. 101)and inserted bolts M6 x 16 (pos. 107) and nuts Straight con- nector plate (pos. 101) Step 8 View from inside Attention: Insert noted bolts M6 x 16 (pos. 107) profile groove before assembly.

  • Page 18: Side Wall Assembly

    Side Wall Assembly Warning: If you are using the foundation frame, it has to be attached to the base profiles FIRST! (Page 8) Attention: Step 10 Step 11 Attach roof beam to back gable with Insert bolts M6 x 16 endcap/cover plate (pos.
  • Page 19 Step 16 Step 17 fl o or profi le connector (pos. 105) + bolt M6 x 16 Attach doors with hinge + nut M6 (pos. 107) hardware. Roof windows slide into the roof beam from the end. Note digram below for proper insertion.
  • Page 20 Assembly roof window plastic corner connector (pos. 127) window profile (pos. 34)(No T-seal in this profile! First, connect three profiles with screw 4,2 x 60 (pos. 112), then insert glazing and attach fourth profile. Important! Neutral cure silicone must be used to seal the corner connectors/caps (pos.
  • Page 21 Automatic Window Opener opener frame pressure cylinder cotter pin mounting plate window profile mounting plate cross bar Auto Opener Installation Check whether the greenhouse window can open and close freely and unhindered. Install the opener with the mounting plate (4) in the center of the lower roof window profile (pos 4.2) Secure the cylinder by lining up the hole in the piston with the upper hole in the T-coupling, then insert the cotter pin.
  • Page 22 Riga Greenhouse Window Auto Opener Correct Installation In the correct position, the opener is sitting parallel to the window, which means that it will not demand a lot of pressure from the cylinder when the opening starts. Before fitting a new cylinder to the openers, you must check that the window can open freely right from the start.
  • Page 23 If you get strong wind gusts, we recommend protecting your roof vents and openers with restraint cables. Roof vent restraints can be purchased from Exaco Trading (US distributor of Rigas) or can be made. They are not a standard part from the Riga manufacturer.
  • Page 24 Mounting divided revolving door - at the bottom View from outside Place the profiles on a flat surface according to the diagram below (a cardboard surface works well). rectangular tube and plastic corner connector door-profi le - (pos. 127) attached with 4,2 x 50 (pos.
  • Page 25 Mounting revolving divided door - top View from outside Place the profiles on a flat surface according to the diagram below (a cardboard surface works well). plastic corner connector (pos. 127) Important! Silicone should be used to seal the corner connectors/caps (pos. 127) where they meet the aluminum profiles, as well as all around the window glazing where...
  • Page 26 Assembly instructions for lockable handle Riga XL Metal Door Holder After the door is assembled and installed, you may place the door holder as seen to the left. You may use self-tapping screws or predrill a small hole.
  • Page 27 The sheets will not suffer any damage from this. Attention: Only neutral cure silicone should be used due to possible stress cracks in the polycarbonate glazing. Exaco has Boss 399 Silicone, or GE Advanced Silicone 2 is readily available at most local home improvement stores. Cleansing and maintenance: Clean the greenhouse with water and a soft cloth or soft brush (ex.
  • Page 28 Polycarbonate Glazing Panels: 16mm triple wall Curved Panel Square Panel 5 Sided Panel Riga XL Size Curved Panel Side wall panels Side Wall Door Panels Roof Windows small (gables) (gables) (gables) for Gables under roof windows Panels Large 888 x 943 980 x 3893 602 x 1922 980 x 727...
  • Page 29 OPTIONAL ACCESSORY: Exhaust Fan installation for RIGA XL, RIGA 4 & RIGA 5 If you have both an intake shutter vent and exhaust fan, you will want them to be opposite/diagonal from each other to get the best cross-breeze. Plug the fan into the thermostat (optional) to control when it turns on.
  • Page 30 OPTIONAL ACCESSORY: Intake Shutter Vent Installation for RIGA XL, RIGA 4 & 5 You will want your intake shutter vent to be opposite from your exhaust fan (i.e. opposite wall and lower part of the greenhouse) to get the best cross-breeze.
  • Page 31 Notes:...
  • Page 32 Customer Service or Assembly Questions? Give us a call Toll free: 1-877-760-8500 customerservice@exaco.com Exaco Trading www.EXACO.com Please watch our animated assembly video on our Exaco Trading Co YouTube Channel. Find the link at www.exaco.com...
