ASSEMBLY INSTRUCTIONS
Assembly Videos can
be found by scanning
the code to the left
smartphone.
Or find the link to our YouTube page at
www.exaco.com. Go to the Victorian
Greenhouse Playlist for all videos.
HELIOS/EOS T-model
with your
Note: This is an all-inclusive manual.
It shows optional accessories and customizations that may not
apply to your greenhouse. Direct any questions to Exaco.
Version 2022
www.exaco.com
877-760-8500

Advertisement

loading
Need help?

Need help?

Do you have a question about the HELIOS/EOS T and is the answer not in the manual?

Questions and answers

Related Manuals for Exaco HELIOS/EOS T

Summary of Contents for Exaco HELIOS/EOS T

  • Page 1 Or find the link to our YouTube page at Note: This is an all-inclusive manual. www.exaco.com. Go to the Victorian It shows optional accessories and customizations that may not Greenhouse Playlist for all videos. apply to your greenhouse. Direct any questions to Exaco.

  • Page 2: Product Information

    RODUCT NFORMATION Dear customer Thank you for buying a high-quality aluminum greenhouse. REMARKS In all drawings you find the mounting-instructions for all basic standard-models. However this manual should be a sufficient guidance for all special-case greenhouses. This greenhouse is designed for cultivation of plants/flowers.
  • Page 4 Standard Royal Orangerie Please call Exaco for measurements if you have a custom greenhouse. Notes: Do not set anchors in concrete until the entire greenhouse frame is complete, level  and square. You will need some play to attach the uprights.
  • Page 5 Royal Orangerie on a Stem Wall HELIOS T MUR + EOS T MUR 829mm 3.098mm = 1+2+3 829mm 3.098mm = 4+5 829mm 200 | 400 600 | 1.025 All dimensions are external dimensions of the aluminum profiles...
  • Page 27 ACCESSORIES This section contains many of the optional accessories. You will have some, but likely not all, items seen in this section. IMPORTANT: Find Janssens Accessory installation video on our site here: https://www.exaco.com/greenhouse-victorian.php It will be immensely helpful! Page: H_33...
  • Page 28 Sliding door (standard for most models) Some models will have double sliding doors. Important: Door rollers may be M 4,8 x 32 adjusted front to back to hold door closer to greenhouse frame. M 4,8 x 19 Place rollers As needed, use washer underneath 4"...
  • Page 29 OPTION: Double Sliding Door If you have a double sliding door, you will have an extra bundle with the following 2 pieces. The top piece adds support. The piece below OPTION closes the gap between the two doors. Note: Apply upward pressure when installing the door support(in red).
  • Page 30 NOTE: You may have one of two styles of door hanger VERSION 1 hardware packed in your door bundle. Please use the page that applies to the style you have. Version 1 on double door option OPTION PAGE: H_35-36...
  • Page 31 VERSION 2 NOTE: You may have one of two styles of door hanger hardware packed in your door bundle. Please use the page that applies to the style you have. Version 2 on double door OPTION PAGE: H_35-36...
  • Page 32 Slide door rollers into top door hanger (PRO7546 or PRO7876) and slide a stopper on either side. Determine how far you want your door to slide, then tighten the screw on the bottom of the stopper to secure. Finish with STOP door hanger caps.

  • Page 33: Optional Upgrade

    OPTIONAL UPGRADE: Low Threshold for Sliding Door/s OPTION Double sliding door Single sliding door opening should be Cut foundation opening should be 1441mm frame 17mm from 703mm bolt hole Cut foundation frame 17mm from bolt hole SDL1...
  • Page 34 OPTION OPTIONAL UPGRADE: Low Threshold for Sliding Door/s p. 2 Attach bottom door guide to low threshold and foundation frame. SDL2 PAGE: H_38...
  • Page 35 OPTION Ø 10 Install lock at bottom of a: -Single Sliding Door -First door of double sliding doors -both of your double sliding doors 4,2 x 19 4,2 x 19...
  • Page 36 OPTION If you have a double sliding door, you may install one lock Ø 10 on the inside of your greenhouse as shown 4,2 x 19 4,2 x 19...
  • Page 37 Roof Window Vent - all hardware is in roof window package GLASS Note: Rubber seal is only installed on the sides of the roof window. Rubber gasket is not used on polycarbonate models. RUBBER E400330 Note: A 1 inch long bolt is inserted into the lower profile.
  • Page 38 Roof Window Installation Note: Inserting a bolt/ nut on both sides of the roof window will prevent it from moving side to side once it is in place. Standard manual opener shown (generally not installed). However, it may be used to secure the window in the closed position - auto opener MUST be detached.
  • Page 39 OPTION: Auto Opener (Ventomax) IMPORTANT! Read installation instructions included in your Ventomax auto opener box to ensure proper installation. There is also information to fully understand the functioning and maintenance of these unique openers. Installing the automatic opener requires 2 bolts to be inserted into the roof The Ventomax openers work with an oil filled crossbar for the lower mount.
  • Page 40 OPTION: Spindle Manual Opener Installation Option 1: Mount top of opener to window with a screw Next, hold the lower U-shaped mount up to the crossbar and mark the center of one Installation Option 2: Insert a 1 inch long bolt into hole.
  • Page 41 Louvre Window - All Standard Royal models include one louvred window Note: All louvered window are black (even with green models). It is likely that your kit include an automatic opener (SESAM LIBERTY) for the louvre vent. Please refer to the Installation and Care manual packaged with the Sesam Liberty opener.
  • Page 42 Louvred window may be installed on sidewall (under gutter profile (PRO20227)) or on gable end (under horizontal gable profile (PRO20229)). Both are shown to the left and below. PAGE: H_45...
  • Page 43 Insert a washer (not included) between black louvre frame and the greenhouse profile at all four bolt locations. Pinch louvre clamps together to hold glass. We recommend using a few dabs of silicone where the glass meets the clamps to hold the glass more securely.
  • Page 44 Louver Window Cover During cold weather, the louvered window may get drafty. Your kit includes as lexan cover to seal the louvers during this time. To install the Lexan panel: • Unscrew the piston from your auto opener • Go outside the greenhouse and pull back the heavy duty rubber gaskets that hold in the panes of glass to the left, right, and bottom of the louvered window (see picture to the right)
  • Page 45 OPTION: Push out window - no standard Royals include this option unless added 4,8 x 70 PAGE: H_47...
  • Page 46 4,8 x 19 4,8 x 19 PAGE: H_48...
  • Page 47 RUBBER E400330 RUBBER PRO1748 PAGE: H_49...
  • Page 48 Option: Hinged Door IMPORTANT: Find Janssens Accessory installation video on our site here: https://www.exaco.com/greenhouse-victorian.php HD 1 PAGE: H_50...
  • Page 49 item L 40X40 4 pc 36 mm PRO6280 2 pc 703 mm PRO6280 2 pc 1.441 mm PRO6280 2 pc 1.930 mm 4,2 x 13 8 pc HD 2 PAGE: H_51...
  • Page 50 Double Hinged door will need opening of 1441mm, 17mm from bolt holes on foundation frame. (Single door shown, double door jamb installation will be identical) (view from top) HD 3...
  • Page 51 OPTION: Hinged door on a stem wall (door extension kit will be needed) PAGE: H_52...
  • Page 52 Single hinged door (view from top) HD 4 PAGE: H_53...
  • Page 53 OPTION: Double Hinged Door HD 5 PAGE: H_54...
  • Page 54 Step 4: Slide face plates onto door handles and snap in place. 4.8 X 19 4.8 X 19 IMPORTANT: Find Janssens Accessory installation video on our site here: https:// www.exaco.com/greenhouse-victorian.php HD 6 PAGE: H_55...
  • Page 55 Insert lock cartridge and secure with screw. Attach latch catch plate to second door. HD 7 PAGE: H_56...
  • Page 56 HD 8 PAGE: H_57...
  • Page 57 HD 9 PAGE: H_58...
  • Page 58 *This page only applies to double hinged doors.* HD10 PAGE: H_59...

  • Page 59: Hinge Adjustment

    HINGE ADJUSTMENT (Left to Right)
  • Page 60 HINGE HINGE ADJUSTMENT ADJUSTMENT (Front/Back) (Up) ±0,5 ±0,5...
  • Page 61 OPTION: 2 Slat Shelf (TAB2) Note: Shelves do not meet the end of the bracket - allowing you to run these shelves end to end if desired. TAB2...
  • Page 62 OPTION: 5 Slat Shelf (TAB5) Note: Shelves do not meet the end of the bracket - allowing you to run these shelves end TAB5 to end if desired.
  • Page 63 OPTION: Narrow Top Shelf M6x12 STANDARD Insert bolts into SCREW channel of PRO1456 ALTERNATIVE and secure with nuts. Drill screws into PRO 1456 to secure...
  • Page 64 OPTION: SEEDTRAY (ST) Diagonal Support only for seedtrays longer than 11 1/2' ft STANDARD Secure back wall of seedtray with screws into PRO1456 SCREW M6x12 Attach L bracket to bolts inserted ALTERNATIVE into corner post and PRO1456...
  • Page 65 INSTALLING AN EXHAUST FAN IN A VICTORIAN GREENHOUSE The exhaust fan in a Victorian Greenhouse should be installed up high in one of the gable ends of the greenhouse. If you happen to have polycarbonate walls on your Victorian, you may cut an opening in the polycarbonate to accommodate the fan.

  • Page 66: Optional Accessory

    OPTIONAL ACCESSORY: Louvre Window Fly Screen (view from outside)
  • Page 68 OPTIONAL ACCESSORY: Sliding Screen Door (view from inside) 4,5 X 50 4,5 X 50 4,5 X 50 4,5 X 50 4,5 X 50 4,5 X 50...
  • Page 69 OPTIONAL ACCESSORY: ROYAL ORANGERIE SHADECLOTH Inserting the curlicue hooks into the curtain: The curlicue hooks that insert into the curtain will go in every 6 loop in the white ribbon– look at the picture diagram to ensure you are inserting them in the correct direction so the curtain hangs well. Your curtains will have one looped ribbon running across the center (for the ridge) and 3 white looped ribbons on either side.
  • Page 72 Toll free: 1-877-760-8500 customerservice@exaco.com Exaco Trading www.EXACO.com Please watch our animated assembly video on our Exaco Trading Co YouTube Channel. Find the link at www.exaco.com Mechelsesteenweg 388, B-2500 Lier Belgium Janssens NV (T) +32 15 30 67 80 (W) www.janssens-alusystems.be (E) info@janssens- alusystems.be...
