- Page 1 Version 2016_1 ASSEMBLY INSTRUCTIONS JUNIOR VICTORIAN...
- Page 2 Product Information Dear customer, Thank you for buying a high-quality Junior Victorian aluminium greenhouse. Remarks In the drawings you will find the assembly instructions for all standard models. However this manual includes instructions for optional accessories and should provide sufficient guidance for all special-case greenhouses. The aluminium profiles may show black stains, these stains are not a production error.
- Page 3 JVIC 23 - 2340 x 3080 JVIC 24 - 234 x 381 PROFILE Used on page Drawing Piece Piece Description Article Length Length FOUNDATION PROFILE PRO 7605 7605-XX 3.074 mm 3.812 mm FOUNDATION PROFILE PRO 7605 7605-XX 2.336 mm 2.336 mm GUTTER PROFILE PRO 7606 7606-XX...
- Page 4 Foundation Profile Ridge Profile Gutter Profile Horizonal Door Profile Top Window Profile Bottom Window Profile Vertical Window Profile Gable Roof Profile Corner Profile Verical Glazing Profile Horizontal Gable Profile Vertical Door Profile PRO39796 Door Frame Support Post Bottom Door Guide Roof Glass Holder PRO 210 Foundation Anchor...
- Page 5 JVIC 23 2340 mm 3080 mm 92 1/8" 121 1/4" 7 ' 8 1/8" 10' 1 1/4" JVIC 24 3810 mm 2340 mm 150" 92 1/8" 12' 6" 7 ' 8 1/8" Note: Do not set concrete in the corners until the entire greenhouse frame is complete.
- Page 7 JVIC 23 7'8" x 10'2" JVIC 24 7'8" x 12'6"...
- Page 8 Note: When assembling the foundation in this step only hand-tighten the nuts. The corners may need to be slightly loose to attach the corner uprights Note: Before assembling the foundation insert 3 M6x15 bolts as shown for the sliding door guide. See page J14-1.
- Page 9 Insert a bolt in corner of front and back wall for Seed Tray (optional accessory). See page ZB2.
- Page 11 Note: If you have purchased shade curtains, insert the slider loops into the gutter profile before this assembly step. This is shown below. 1-Twist lock per end Trim the square plate Insert 28 slider loops on the round-hook in each gutter profile (which screws down) if you have ordered a to be able to insert it...
- Page 12 Suggestion: Now is a good time to install the L1 corner wind braces shown on page J9.
- Page 13 Insert a bolt in each upright where the seed tray shelf support will be located Refer to page...
- Page 14 1 - Twist Lock Hook Trim the square plate on the round-hook (which screws down) to be able to insert it in the channel. If you have a shadecloth, insert 28 hook sliders into the ridge profile at this time. See page JSD...
- Page 15 Note: Roof windows can be installed in any bay. Note: When installing the roof profiles, make note of which bays will have roof windows and insert a bolt for the connection plate.
- Page 16 Note: Wait until assembly is complete before attaching the roof braces. Use a level to ensure greenhouse is square.
- Page 17 Notes on attaching the gutter downspout: Use a small self-tapping screw to attach the plastic gutter down spout to the gutter profile and also the down pipe to the plastic downspout (Shown below) Note: The gutter down pipe is attached to the base of the greenhouse with a screw that goes through the back of the...
- Page 19 Roof Window 1 inch long bolt Note: A 1 inch long bolt is inserted into the lower profile. This bolt is for the optional manual opener or the spindle Glass opener. Note: Rubber seal is only installed on the sides of the roof window.
- Page 20 Roof Window Installation Slide roof window into the roof beam from either end of the greenhouse. The hook part on the top of the roof window will slide into a groove in the roof beam. (shown below) Note: Inserting a bolt on either side of the roof window will prevent it from moving side to side . Manual Opener is shown above.
- Page 21 Automatic Opener Installing the automatic opener requires 2 bolts to be inserted into the roof crossbar for the lower mount. The upper mount will clamp onto the lower roof window framing profile. (As shown in the diagram below) The automatic opener comes with its own instructions and care guide. These are located in the box with the opener. Insert 2 bolts for lower mount...
- Page 22 SLIDING DOOR (GUIDES)
-
Page 24: Sliding Door
SLIDING DOOR... - Page 26 Insert 28 slider loops per curtain plus 1 twist-lock loop at the end...
- Page 27 Seed Tray (Optional Accessory) 1 Support for every 10 foot section 1. Assemble three sides of the seed tray. Note: Make sure to slide 1 bolt into the bottom of the front and back seed tray profiles.(2 for a Vi34) 2.
- Page 28 Seed Tray (Optional Accessory) 4. Use the bolts that you previously inserted into the uprights to mount the shelf end Note: If you have forgotten to insert the bolts support. Choose whatever height works you can use screws. Make sure to use a screw best for you.
- Page 29 Customer Service or Assembly Questions? Give us a call Toll free: 1-877-760-8500 customerservice@exaco.com Exaco Trading www.EXACO.com Janssens NV Mechelsesteenweg 388, B-2500 Lier Belgium (T) +32 15 30 67 80 (W) www.janssens-alusystems.be (E) info@janssens-alusystems.be...
