1 . I N T R O D U C T I O
1 . I N T R O D U C T I O
UNIO4 is a modern IP-based signalling and control device for monitoring and controlling stand-alone
equipment that has a contact input or contact output for control or status information.The device
sends notifications to the user's smartphone when the status of the inputs changes and also
provides the possibility to send events to monitoring station. Remote operation of output relays is
also possible via control from the app. As it uses both WIFI and mobile network connections for
communication, it provides reliable signalling and stable, fast control. A big advantage is that the
device sends a confirmation of the control of the output relays to the user, so that it is 100% visible
that the switching has actually taken place.
The contact events can be transmitted to both the user's smartphone and the monitoring station,
making the device suitable as a remote monitoring communicator for systems where few, but up to
4 types of signals need to be distinguished, e.g. fire alarm systems.
1.1

Main features

 4 supervised contact inputs, triggered with dry contact (shortcut to ground)
 4 controlled relay outputs with switching confirmation
 2 parallel communication channels, WIFI and mobile network communication
 Unlimited number of signals with simultaneous notification of all users
 Reports sending to two independent Monitoring stations (SIA DC-09 receivers)
 AES-128 encrypted communication
 Serial port for remote programming of external device
 Inputs status supervision and control of outputs from web page or from smartphone application
 Connecting to WIFI network using device web page, in hotspot mode
 Full remote management via WEB interface (configuration, diagnostics)
 Supply voltage supervision
 MQTT 5.0 support
1.2

Usage Areas

Supervision and control of remote device or multiple devices on one App platform:
 Controling relays and switching events monitoring via mobile App
 Remote programming of Alarm panels, Fire panels, PLC or any standalone device with serial
connection to a software (vending machines, car diagnostic, sensor reading..)
 Control gates from mobile application
 Status change signaling to maintenance with immediate multiple reporting and confirmation with
identification (Error is sent to all maintenance workers on smartphone, one can confirm to "take
the case" and other see that error is being handled by that operator)
UNIO4 WxG
