Device tries to access Internet through SIM card with entered APN parameters immediately after
starting, and in case of failure it will restart. Therefore wrong APN data may cause continuous
restarting of device, instable operation.
Note: Some providers do not request an Username and password, only the APN Name.

4.2.10 WIFI Network Connection Settings

Setting up a WIFI connection reduces the data traffic on the SIM card, and also increases the
signaling transfer speed. If a WIFI network is available at the installation, we recommend setting up
access to the network in the unit. However for setting up of SINGULAR WIFI device the local WIFI
network access is required, moreover access to 2 different WIFI networks can be set, thus further
increasing functional safety!
1. Setup is started by clicking on the gear icon of the WIFI network value field in the MODULE
STATUS window.
2. Accessible WIFI networks are listed by clicking on the Explore button.
3. After selecting the appropriate network, and entering the valid password, click on the Save button
to establish the WIFI connection. Successful connection is indicated by the green flash of status
indicator LED, while an error is indicated by a red flash. In addition the information window shows
the appropriate status message as well.
The "Assign MAC" option will lock the connection to the selected access point. This should be used
in case when the device is installed in a position where multiple SSID with same names are visible
(eg. in case of WIFI signal repeaters). This way the device will always connect to same access point
(node) after every restart.

Reset to factory default

4.3
Device must be online (at least one led flashing green) to perform the reset. Press and hold down
the SETUP/RESET button on back of device (immage on next page) for 20 seconds. LEDs will start
blinking fast yellow, then on and finally turn off. After that you can release the button. All settings of
device will be reset to default values. Concerning Puloware service device will be deleted from all
accounts and from all smartphones. Refreshing (restarting) the site and application will remove the
deleted device.
Note: If the device was LOCKED (section 4.2.2. Locking features and device), the defaulting
procedure will fail. You must remove the LOCK to perform the successful procedure
UNIO4 WxG 11 EN
