Related Manuals for SECURECOM SC-GSM M2
Summary of Contents for SECURECOM SC-GSM M2
- Page 1 Alarm system communicators that generate individual SMS messages and alarm calls via GSM network from Contact ID reports Installation manual v2.0 SC-GSM M2 1 EN manual v2.0...
-
Page 2: Table Of Contents
Transparent mode ........................7 Contact inputs events setting ....................8 General settings ........................8 Module status window ......................9 Latest events window ......................9 Administrative window ......................9 Technical data..........................10 Device package content ........................ 10 SC-GSM M2 2 EN manual v2.0... -
Page 3: General Information
General information The SC-GSM M2 is an alarm system communicator with 2 types of operation. In standalone mode, it generates an SMS message and an alarm call from Contact ID reports from alarm control panels or from status changes in its own contact inputs. Operation: it compares the... -
Page 4: Structure
Alarm contact inputs Triggered to negative supply (with dry contact) ❹ SIM card holder Type: 2FF/mini SIM ❺ USB mini B connector for configuration ❻ GSM antenna connector, SMA type ❼ Status signaling LEDs SC-GSM M2 4 EN manual v2.0... -
Page 5: Suggested Wiring Diagram
Connecting to network / SIM or network failure after 1 minute Flashing GREEN Idle state ( Device is ready, waiting for report from alarm panel) Continuous GREEN Communication with alarm panel in progress Flashing RED & GREEN Low signal strength, below 30% SC-GSM M2 5 EN manual v2.0... -
Page 6: Settings
Settings To set up the device install the SECURECOM CONFIGURATOR software. The installation file (securecomconfiguratorsetup.exe) is available on securecom.eu web site. Run the installer, it will make the software available from the start menu. After running the program, connect the USB port of the device to the PC, and select the appropriate serial port, then push the “Connect”... -
Page 7: Standalone Mode
GSM network. The device does not handle the incoming call, so it cannot ring the connected telephone line. SC-GSM M2 7 EN manual v2.0... -
Page 8: Contact Inputs Events Setting
(as mentioned above) Test SMS period: frequency of periodic test report that the unit works properly Test SMS text: message of periodic test report that the unit works properly SC-GSM M2 8 EN manual v2.0... -
Page 9: Module Status Window
Administrative tools Language selection The function of the administration icons is as follows: Open and load saved settings to the screen Save settings to file Save the configurator screen settings into the device memory SC-GSM M2 9 EN manual v2.0... -
Page 10: Technical Data
Rated current 100 mA Maximum current 300 mA Operating temperature -20°C - +70 °C Dimensions 40x80x15 mm Device package content • SC-GPRS M2 communicator • Antenna • USB cable • Plastic pegs • Warranty SC-GSM M2 10 EN manual v2.0...
