Be careful not to get your fingers caught between
the two halves of the adapter!
After clipping the adapter onto the valve body, fix it using
the provided screw and nut.
5.2.3

Support ring

The valves from different manufacturers may have toler-
ance fluctuations that make the DHC Radiator Thermostat
more loosely seated on the valve. In this case, the provided
support ring should be placed into the flange before mount-
ing the accessory (see figure 8).
5.3

Adaption run

Once the batteries have been inserted, the motor
reserves. Meanwhile, InS and the activity symbol
are displayed (see figure 9).
After the DHC Radiator Thermostat has been mounted
successfully, an adaption run (AdA) has to be performed
in order to adapt the accessory to the valve. To do this,
proceed as follows:
1. As soon as AdA is displayed, press the menu/
boost button (G) to start the adaption run (see fi-
gure 10).
» AdA and the activity symbol
ring the adaption run (see figure 10). During this
Start-up
are displayed du-
