VIVOTEK Fixed Dome Series
Mounting kit
Using
AM-528 Mounting Adapter,
AM-118 Pendant Head (indoor),
AM-116 and AM-117 Pendant Pipes,
AM-522 NPT adaptor
AM-221 Gooseneck,
AM-212 Wall Mount,
AM-311 Pole Mount,
AM-411 Corner Mount
Corresponding part number:
AM-528: 100147800G
AM-116: 900014301G
AM-117: 900014401G
AM-118: 900014600G
AM-221: 900014800G
AM-212: 900004202G
AM-311: 900002902G (v03)
AM-411: 900003003G (v04)
AM-522: 900020201G (V02)
Document part no.: 625035700G
Installation Guide
900004203G (v03)
900002903G (v04)
900002904G (v05)
900003004G (v05)
IP Sur veillance
Rev. 1.0
Advertisement
Subscribe to Our Youtube Channel
Related Manuals for Vivotek Fixed Dome AM-528
Summary of Contents for Vivotek Fixed Dome AM-528
- Page 1 VIVOTEK Fixed Dome Series Mounting kit Using AM-528 Mounting Adapter, AM-118 Pendant Head (indoor), AM-116 and AM-117 Pendant Pipes, AM-522 NPT adaptor AM-221 Gooseneck, AM-212 Wall Mount, AM-311 Pole Mount, AM-411 Corner Mount Installation Guide Corresponding part number: AM-528: 100147800G...
- Page 2 Revison History: Rev. 1.0: Initial release. AM-528 Mounting Adapter Package Contents Applications AM-118 AM-118 AM-522 NPT adaptor AM-116 AM-117 NPT pipe AM-528 For other applications, please refer to page AM-528...
- Page 3 Compatible VIVOTEK Cameras Direct installation: FD8369A, FD8367A, FD8169A, FD8167A, FD8379-HV, FD8377- HV, FD8179-H, FD8177-H AM-118+AM-117/116 +AM-528 WARNING: 1. Select a suitable location where the camera is free from accidental damage, tampering, or harsh environmental conditions. 2. Locate a place for the installation where the camera can not be intentionally or unintentionally interfered.
-
Page 4: Compatible Accessories
Compatible Accessories Compatible Accessories (1): AM-311 Pole Mount Bracket Compatible Accessories (2): AM-411 Corner Mount Bracket Compatible Accessories (4-1): AM-221 Gooseneck Bracket Compatible Accessories (4-2): AM-212 Wall-mount Bracket Compatible Accessories (5-1): AM-118 Pendant Head Compatible Accessories: AM-522 Pendant NPT Adaptor... - Page 5 Compatible Accessories (5-2): AM-116 and AM-117 Pendant Pipe Shown below are the mounting dimensions using a 40cm pendant pipe (AM-117). AM-118 AM-118 140 mm 140 mm AM-117 AM-117 438.2 mm 556 mm 438.2 mm 557.5 mm 307 mm FD8369A FD8169A 24.5 mm 24.5 mm 94.8 mm...
- Page 6 Direct Installation 3-1. Using the Pendant Pipe 1. Determine a hard surface ceiling location, and use the included alignment sticker for marking three mounting holes as where holes will be drilled to secure the pendant head. 2. Hammer in the plastic anchors. AM-118 3.
- Page 7 8. Pull the cables through the pendant pipe, and the camera base. Install the camera. Use a crimping tool to connect the Ethernet wires to an RJ45 connector. Some outdoor cameras come with a side-routing cutout. Use the included tape and side plug to seal the cutout.
- Page 8 3-2. Using the 3/4" NPT Pipe AM-118 AM-522 3/4" Female adapter 3/4" pendent pipe AM-528 130 mm 1. Determine a hard surface ceiling location, and use the included alignment sticker for marking three mounting holes as where holes will be drilled to secure the pendant head. 2.
- Page 9 3. Secure the pandant head using the included screws. 4. Install the AM-522 adaptor and the NPT female-female coupler (user-supplied) 5. Tighten the retention screw using the hex wrench. 6. Install the 3/4" NPT pipe of a preferred length. 7. Install the AM-528. AM-118 AM-522 NPT female-...
- Page 10 8. Pull the cables through the NPT pipe and the camera base. Install the camera. Use a crimping tool to connect the Ethernet wires to an RJ45 connector. Some cameras come with a side-routing cutout. Use the included tape and side plug to seal the cutout.
- Page 11 Using Other Accessories 4-1. Gooseneck Installation - AM-221 Below is a general, sample procedure using a gooseneck bracket: 1. Route power lines and other cables through the wall and the bracket. 2. Locate the position where you want to install the gooseneck bracket and camera. Drill holes on the wall for securing the bracket and for routing the cables.
- Page 12 The same installation method applies to the AM-212 wall-mount bracket.
- Page 13 4-2. Corner Mount Installation Below is a general, sample procedure using a Corner mount bracket: 1. Combine the two brackets together using the included nuts and washers. 2. Align the assembled brackets with the desired position. Align screw holes on the brackets against the wall.
-
Page 14: Pole Mount Installation
4-3. Pole Mount Installation Below is a general, sample procedure using a Pole mount bracket: 1. Route power lines and other cables through the included cable gland, pass them through conduits (separately purchased), and install the cable gland to the pole mount bracket. - Page 15 This page is intentionally left blank.
- Page 16 This page is intentionally left blank.
