Vivotek AF101 Quick Start Manual

AF101 140cm Stand
(AM812+AM813+AM814)
(for Social Distancing Control)
Quick Installation Guide
Package Contents
1. AM812, AM813, AM814
2. Screws, 1x T10 torx star L wrench, 1x hex
wrench
AF101
AM813
* The AB101 edge computer and AF101 Thermal
reader come in other packages. The wall-
mount bracket and middle bracket come with
the AF101. The middle bracket is not used.
AM812
AM814
3
When cables are in place, assemble the top section, and drive the flathead
screws on the sides.
6
Lay the reader on a clean surface. Remove the bottom mounting plate using the
T10 torx wrench. Keep the anti-tamper screw for later use.
NOTE:
The AF101 configuration can not be exposed to direct sunlight.
Hardware Installation
1
Assembly the AM814 base plate and AM812 using 2 hex sunkhead screws.
4
Secure another 2 screws from the other side.
7
Install the bracket to the wall-mount bracket by driving 4 cross-head sunkhead
screws.
AF101
Securing tab
T10 torx
wrench
AM812
AM814
Hex wrench
Bracket from reader
Screw tab, this side up
2
Assemble the top section (AM813) with the stand. Pull the cables (RJ45 Ethernet,
USB, and 12V power jack) through the bottom of the AM813 and through the opening
in the center. You can put the AM813 on top of the stand and place a piece of clothe
underneath to avoid damaging the aluminum surface.
AM813
Cushion
AM812
5
Remove the protective sheet from the wall-mount bracket.
8
Install the bracket assembly to the stand by driving 4 small cross-head hex
screws. Please also pull the cable through the center opening.
