- Page 1 VIVOTEK Bullet Series AM-523 Adapter Plate for Junction Box Installation Guide Rev. 1.1 IP Sur veillance...
- Page 2 Compatible VIVOTEK Cameras Bullet series Large bullets: IP8371E, IP8355EH, IP8365EH, IP8372, IP8361 Medium bullets: IP8362, IP8335H, IB8369, IB8373-EH, IB8381(-E) You may also refer to VIVOTEK's website for the list of supported models. Support for other models can be available through time.
- Page 3 Installation 1. Install the adapter plate to different types of 4" junction boxes using the included screws as shown below. Countersunk head Flat head 8# x1/2 (drill point) 6# x12 NI...
- Page 4 2. Secure the camera mounting plate to the adapter plate as shown below. IP8372, IP8371E, IP8355EH, IP8365EH, Pan head M6 x6 NI IP8361, IB8373-EH, IB8381(-E) IP8362, IP8335H IB8369 3. Refer to the camera's Quick Installation Guide for the rest of the installation instructions.
