- Page 1 VIVOTEK Fixed Dome & Fisheye Series Mounting Cap Installation Guide Using AM-51C mounting cap and compatible accessories Rev. 1.0 Ordering part no.:100140100G Part no.: 625032200G IP Sur veillance...
- Page 2 FD9381 / FD9371 / FD836B / FD8382 Fisheye FE8191 / FE8181 You may also refer to VIVOTEK's website for the list of supported models. Support for other models can be available through time. Package Contents: AM-51C, Installation Guide, 3x panhead M4x7, double-sided tape, plastic stopper...
-
Page 3: Installation
Installation Mounting Hole Definitions User a hammer and screwdriver to open the knock out holes you prefer to use. Above are the locations of different groups of mounting holes for matching different junction boxes: Hole Applicable Box Drawings Screw No. of Type screws 4"... - Page 4 Hole Applicable Cameras Screw No. of screws Type FD9171, FD816B, #8-32, L15 (User-supplied) FD8182 FE8191, FE8181 #8-32, L15 (User-supplied) NOTE: 1. Route cables before you secure the accessories to a wall. 2. For details on the cable connections with network cameras, please refer to their Quick Installation Guide.
- Page 5 2. Install the mount cap to the junction box. Use screw holes specified on page 3 depending on the type of junction box.
- Page 6 431. FE8181 and FE8191. 3-1-1. Install the camera to the mount cap by fastening two screws to the threaded holes on the copper spacers. 3-1-2. Connect the cables and install the top cover.
- Page 7 3-2. FD836B/FD8382/FD9381/FD9371. 3-2-1. Fasten screws to the mounting cap. Do not completely tighten the screws. Leave part of the screws out. Attach the plastic stopper to the opening at the bottom of the camera.
- Page 8 3-2-2. Install the camera to the mounting cap by turning it counter-clockwise so that the screw heads fit in the keyhole slots. Fasten the screws, and then connect the cables. Refer to the camera's Quick Installation Guide for how to make the waterproof connections. 3-2-3.
