INSTALLATION

Connecting your PYKO-in device

It is recommended to establish all connections before powering the device up.

Power supply

Before plugging the power cord, make sure it is not damaged:
Just like for any other audio system, power the individual devices up following the audio path and power
down in the opposite direction.
Do not allow anything to rest on the power cable. Keep the power cable away from where people could trip
over it.

Set-up

•
Use an Ethernet cable to connect your PYKO-in to the network through its RJ45 port (labeled 'ETH.'
on the back panel). To connect your PYKO-in directly to your computer, use a crossover cable.
•
Plug your headphones (front panel)
•
Prepare pen and paper in order to write the IP address down, which will be announced over the headphones
output.
•
Connect the electric cable to the plug labeled 'PWR' on the back panel and to the power outlet

Audio

The pinout used on the XLRs is standard: pin 1 carries the signal ground, pin 2 carries the positive signal
("hot", +) and pin 3 carries the negative signal ("cold", -).

Configuration

You can use PYKO-in along with Audio Manager, in stand-alone or in EtherSound mode.

Firmware update

Digigram provides a firmware (compound.bin) compatible PYKO-in that is installed by default (factory
configuration).
Digigram may decide to publish updates of the embedded firmware. It may then become necessary to upgrade
your devices. In this case, please connect to the corresponding page on
and download the most recent version. Then, go to the <Tools>, <Update> section of the PYKO-in html
page, click 'Browse' to indicate the location of the downloaded file, then the 'Upload' button. When the
message 'compound.bin successfully loaded' is displayed, click onto the link 'Click on update before
updating the next component or unplug the power supply to reboot the device' in the message, then
onto the 'Reboot' button to finish the update, or, alternatively, disconnect then re-plug the power cord.
