Rocstor Y10A237-B1 User Manual

USB-C to DisplayPort Adapter
4K 60Hz - M/F - Black
Congratulations
Thank you for purchasing this premium Rocstor product. For optimum performance and
safety, please read these instructions carefully before connecting, operating or using this
product. Please keep this manual for future reference.
Introduction
This Premium Rocstor Type-C to DisplayPort Adapter. It allows to connect Type-C
source or Thunderbolt™ 3 source to DisplayPort display at max 3840x2160 @60Hz
resolution. It can work on all DP Alt mode supported Type-C host.
Package Contents
Before attempting to use this unit, please check the packaging and make sure
the following items are contained in the Packaging:
• Main unit x1
• User Manual x1
Operation
1- Connect USB-C port of this product to host PC
2- Connect DisplayPort output of this product to HDTV with one DisplayPort M/M
cable.
System Requirement
Host computer with an available USB-C Port
- USB 3.0/3.1/3.2
Operating systems
- Windows 7 / 8 / 10 / 11
- Android OS
- Chrome OS
- Linux OS
- Mac OS v10.5 or above
User Manual
Y10A237-B1
®
Features
Upstream:
USB Type-C - Male
(Connect to host computer)
• Type-C Male (Connect to host)
• Supports DP1.2 Alt mode
Downstream:
DispalyPort - Female
• Supports per lane data rates of 5.4Gbps (HBR2),
2.7Gbps (HBR) and 1.62Gbps (RBR)
• HDR bypasss
• HDCP bypass
• Supports DisplayPort resolution up to
3840x2160@60Hz
• USB bus power (no external power supply)
Speci cation
Input / Output Connector
Input
Output
Warranty
Limited Warranty
Environmental
Operating Temperature
Operating Humidity
Storage Temperature
Storage Humidity
Regulatory Approvals
Certi cations
Power Requirement
Power Source
Size (LxHxW)
Weight
Accessory
User Manual
Type-C Male x1
DisplayPort Female x1
2 Year
0°C to + 45°C - (32°F to + 113°F)
10% to 90 % RH (no condensation)
-10°C to + 70°C - (14°F to + 158°F)
10% to 90 % RH (no condensation)
FCC, CE
USB bus power
8.5"x0.59"x1.46" - 216x14.9x37 mm
1.2 oz - 34 gr
English Version
