Mobility Sound BTH-600 Instructions Manual

BTH-600
<Product Descriptions>
•Heavy duty speaker microphone for Cellphone.
•Volume control buttons, and PTT button are
built in
•Features cell phone key to answer incoming
phone call when BTH-600 links to cell phone.
•Embedded 3.5mm jack for external earphone.
Built-in Mini USB for charging.
<Specification>
Type: Bluetooth Speaker Microphone
Operating Temp: -20℃±2℃ ~ 50℃±2℃
Approx. Weight: 140g
• Fully Qualified Bluetooth v4.0.
• Echo cancellation, noise reduction, also
extended features
• High Quality DAC, CSR CVC built-in
• 80MHz RISC MCU and 80MIPS Kalimba DSP
• Fast Current (200mA) battery charge
• SBC, MP3, AAC, Fast stream, APTX codec
support
• RoHS compliant
• HSP / HFP / AVRCP/ SPP profile support
• Speaker Output: 2W
• PTT function: built-in
• Talking Range: Bluetooth class 2, 10 meters
• Display LED: Blue and Red
• DC Input: 5 Vdc (std.)
• DC Current: 25 mA (Average)
• Battery: 1000mAH, replaceable BL-5C
• Talk Time: 40+ Hours
