Federal Communication Commission Interference Statement
This equipment has been tested and found to comply with the
limits for a Class B digital device, pursuant to Part 15 of the FCC
Rules. These limits are designed to provide reasonable protection
against harmful interference in a residential installation. This
equipment generates uses and can radiate radio frequency energy
and, if not installed and used in accordance with the instructions,
may cause harmful interference to radio communications.
However, there is no guarantee that interference will not occur in
a particular installation. If this equipment does cause harmful
interference to radio or television reception, which can be
determined by turning the equipment o and on, the user is
encouraged to try to correct the interference by one of the
following measures:
-Reorient or relocate the receiving antenna.
-Increase the separation between the equipment and receiver.
-Connect the equipment into an outlet on a circuit different from
that to which the receiver is connected.
-Consult the dealer or an experienced radio/TV technician for
help.
FCC Caution: Any changes or modifications not expressly
approved by the party responsible for compliance could void the
user's authority to operate this equipment.
This device complies with Part 15 of the FCC Rules. Operation is
subject to the following two conditions: (1) This device may not
cause harmful interference, and (2) this device must accept any
interference received, including interference that may cause
undesired operation.
This equipment complies with FCC RF radiation exposure limits set
forth for an uncontrolled environment. To maintain compliance
with FCC RF exposure compliance requirements, please avoid
direct contact to the transmitting antenna during transmitting.
RF Exposure Warning!
This device contains transmitters and receivers which emit Radio
Frequency (RF) energy. The device is designed to comply with the
limits for exposure to RF energy set dby the Federal
Communications Commission (FCC) of the United States, Industry
Canada (IC) of Canada, and the regulating entities of other
countries.
If you are still concerned about exposure to RF energy,
you can further limit your exposure by limiting the
amount of time you use the equipment or by placing
more distance between your body and the device,
since exposure level drops o dramatically with distance.
PTT-100-VZ
Wireless Speaker Microphone
For use with Zello and other Push-To-Talk
apps on Android Smart Phone.
Model No.: PTT-100-VZ
Made in Taiwan
Mobility Sound is trademark owned by Mobility Sound Products,
Taiwan. All other product or service names are the property of
their respective owners.
© 2014 Mobility Sound Products, Taiwan. All Rights Reserved
Advertisement
Table of Contents
Related Manuals for Mobility Sound PTT-100-VZ
Summary of Contents for Mobility Sound PTT-100-VZ
- Page 1 Canada (IC) of Canada, and the regulating entities of other countries. Mobility Sound is trademark owned by Mobility Sound Products, If you are still concerned about exposure to RF energy, Taiwan. All other product or service names are the property of you can further limit your exposure by limiting the their respective owners.
-
Page 2: Controls And Connection
Controls and Connection Microphone: Front Firing Speaker This microphone picks up Received calls are heard over this the user’s voice audio speaker. The volume level is controlled using the volume controls on the phone. Clothing Clip The alligator-type clip secures the speaker, microphone to the user’s clothing during use. - Page 3 Charging the Speaker Microphone The PTT-100-VZ speaker microphone has an internal Lithium Ion rechargeable battery pack which must be charged prior to operation, and must be recharged regularly. A fully charged battery will provide approximately 5 hours (or more) of continuous operation before needing to be recharged.
-
Page 4: Pairing With A Smartphone
Pairing with a Smartphone The PTT-100-VZ speaker microphone is designed to work with smart phones running the Android operating system. Prior to normal operation, the phone and speaker microphone must be paired together using the following process: 1. Activate the pairing mode on the speaker microphone by holding down the multifunction button until the status LED ashes BLUE-RED-BLUE-RED continuously in sequence. - Page 5 Setting Up the Zello App To get the Zello app on your phone and set it up to work with the PTT-100-VZ speaker microphone, do the following: 1. Install Zello from your Zello@Work network, or download the app from the Google Play store.
-
Page 6: Making And Receiving Phone Calls
To activate Zello’s push-to-talk feature, press and hold the PTT button on the speaker microphone. When Zello is transmitting a call, audio will be picked up by the PTT-100-VZ’s built-in microphone. Incoming calls received by Zello will be heard over the PTT-100-VZ’s built-in speaker or through the optional earphone if you are using one. -
Page 7: Specifications
OPTIONAL EAPRHONES Although the PTT-100-VZ has a built-in speaker for listening to received calls, some users may prefer to use a listen only earphone for enhanced privacy. The accessory jack on the speaker microphone will accept any mono earphone with a 3.5 mm audio plug. -
Page 8: Support And Warranty
Mobility Sound Products warrants this product against defects in materials or workmanship for a period of one year from the date of retail purchase. Mobility Sound will repair or replace a defective unit, at our option, without charge for parts or labor. The limited warranty does not cover damage or failure caused...
