BTH-600

Dual Link Wireless Speaker

Microphone

User Manual

1. Function keys of BTH-600

PTT

Power /Pairing button

Volume Up/Down

Blue/Red LED

Talk/End Button

Mini USB

charging jack

Press and hold the

Power/Pairing button

Turn off BTH-600.

Press and hold the power/

pairing button for 6 seconds.

The Red/Blue LED will flash

alternately, indicates BTH-600 is

now in pairing mode.

Release the button.

Power/Pairing

3.5mm ear phone jack

with cap

Table of Contents

Do you have a question about the BTH-600 and is the answer not in the manual?

Page 1 Dual Link Wireless Speaker Microphone User Manual Mini USB 3.5mm ear phone jack charging jack with cap 2. Get BTH-600 into pairing mode 1. Function keys of BTH-600 Press and hold the Power/Pairing button Power /Pairing button Volume Up/Down Turn off BTH-600.
Page 2 Make sure BTH-600 is in Pairing mode 5. Dual link functions: 6. Listen the music of the phone BTH-600 can link both radio and In Phone-only link mode, BTH- mobile phone at the same time 600 can listen the music in the when both devices are paired and phone(iPhone only).
Page 3 6 seconds Unpaired or lost link Blue LED flashes once every 2 seconds No link, no pair BTH-600 link with audio dongle on Radio only Stand-By mode Blue LED flashes once every 6 seconds Single link with dongle Press PTT button...
Page 4 5 steps in volume adjust, when reach the Volume Down minimum volume, a short beep is heard and the earphone is muted External Earphone BTH-600 comes with a 3.5mm female audio jack for extern listen only earphone MobilitySound Technology LTD. www.mobilitysound.com info@mobilitysound.com Replaceable battery...
Page 5 BTH-600 Specification Type: Bluetooth Speaker Microphone Operating Temp: -20℃±2℃ ~ 50℃±2℃ Approx. Weight: 130g • Fully Qualified Bluetooth v4.0. • Echo cancellation, noise reduction, Stereo audio (A2DP audio), also extended features • High Quality DAC • 80MHz RISC MCU and 80MIPS Kalimba DSP •...
