5.3

Connecting power supply

The connection is performed using power cable with IEC C13 connector (included).
The device must be operated by qualified personnel. Make sure that the power grid supply parameters are
consistent with device parameters and limitations are not exceeded.
CAUTION! In the case of cable damage do not attempt to repair. Replacement or repair can be made only
on the manufacturer or by a person with appropriate permissions.
6

OPERATION MANUAL

6.1

Control panel

The control panel is equipped with display and 4 control buttons:
1. MENU – access to menu
2. DOWN – change value, go to next option
3. UP – change value, go to previous option
4. ENTER – confirm changes
6.2

Menu

Menu diagram:
DMX channel
Red dimmer
Green dimmer
Blue dimmer
White dimmer
Zoom
Strobe
Color change
Color change - smooth
Sound control
Auto run
www.flash-butrym.pl
d*** → 001 - 512
r** → 000-255
G** → 000-255
b*** → 000-255
u*** → 000-255
F*** → 000-255
FF** → 00-99
CC** → 00-99
DE** → 00-99
SU** → 00-99
DEno → /
Set channel
Dark to bright
Dark to bright
Dark to bright
Dark to bright
Small to large
Slow to fast
Slow to fast
Slow to fast
ON
ON
