- Page 1 LED PAR 36 4x15W 4in1 ZOOM F7000200 USER MANUAL / INSTRUKCJA OBSŁUGI...
-
Page 2: Table Of Contents
LED PAR 36 4x15W 4in1 ZOOM F7000200 Table of contents Introduction ..............................2 Safety information ............................2 Product information ............................2 Specification ..............................2 Installation ................................ 3 Connections ..............................3 Connecting DMX signal..........................3 Voltage specification ..........................3 Connecting power supply ........................4 Operation manual ............................ -
Page 3: Introduction
Operating modes: DMX, Automatic, Sound controlled Features: Zoom AC IN: IEC - C14 AC OUT: IEC - C13 DMX IN: XLR - 3 pin DMX OUT: XLR - 3 pin IP Rating: IP20 Housing made: Aluminium www.flash-butrym.pl... -
Page 4: Installation
LED PAR 36 4x15W 4in1 ZOOM F7000200 Cooling: Passive Height [cm]: 23 Width [cm]: 23 Depth [cm]: 34 Weight [kg]: 4,5 Weight with packaging [kg]: 6 INSTALLATION After removing the packaging, check if the device was not damaged during transport. Before connecting to the mains, make sure that the device is securely mounted. -
Page 5: Connecting Power Supply
→ 000-255 Small to large Strobe FF** → 00-99 Slow to fast Color change CC** → 00-99 Slow to fast Color change - smooth DE** → 00-99 Slow to fast Sound control SU** → 00-99 Auto run DEno → / www.flash-butrym.pl... -
Page 6: Dmx Channel List
LED PAR 36 4x15W 4in1 ZOOM F7000200 DMX channel list 5CH mode Channel Function Effect CH 1 0-255: 0-100% CH 2 Green 0-255: 0-100% CH 3 Blue 0-255: 0-100% CH 4 White 0-255: 0-100% CH 5 Zoom 0-255: Small to large... -
Page 7: Wprowadzenie
Ściemnianie: Płynne: 0 - 100% Ilość kanałów DMX: 5 / 8 Standard DMX: DMX 512 Sterowanie: 4 przyciski Tryby pracy: DMX, Automatyczny, Sterowanie dźwiękiem Funkcje: Zoom AC IN: IEC - C14 AC OUT: IEC - C13 www.flash-butrym.pl... -
Page 8: Instalacja
LED PAR 36 4x15W 4in1 ZOOM F7000200 DMX IN: XLR - 3 pin DMX OUT: XLR - 3 pin Stopień ochrony IP: IP20 Rodzaj obudowy: Aluminium Chłodzenie: Pasywne Wysokość [cm]: 23 Szerokość [cm]: 23 ... -
Page 9: Specyfikacja Zasilania
Wąsko – szeroko Strobo FF** → 00-99 Wolno - szybko Zmiana kolorów CC** → 00-99 Wolno – szybko Płynna zmiana kolrów DE** → 00-99 Wolno – szybko Sterowanie dźwiękiem SU** → 00-99 Włączone Tryb Auto DEno → / Włączony www.flash-butrym.pl... -
Page 10: Lista Kanałów Dmx
LED PAR 36 4x15W 4in1 ZOOM F7000200 Lista kanałów DMX Tryb 8CH Kanał Funkcja Efekt CH 1 Ściemnianie 0-255: 0-100% CH 2 Czerwony 0-255: 0-100% CH 3 Zielony 0-255: 0-100% CH 4 Niebieski 0-255: 0-100% CH 5 Biały 0-255: 0-100%...
