H-840U-10
H-1082U-10
3-4 STEP ROLLING
SAFETY LADDERS
10" DEEP TOP STEP
TOOlS NEEDED
" Wrench (2)
9
16
" Wrench or Socket
7
16
Rubber mallet
Safety Glasses
A. Side Handrail (1)
B. Side Handrail (1) Opposite
Handrail Brackets
(shipped attached to side of Stile)
WARNING! Assembly of these types of ladders
can be inherently dangerous. Please take all
precautions necessary during the assembly
process. Always use a separate ladder to
finish assembly in high places. Never climb a
ladder that is not completely assembled. Do
not assemble or use a ladder with missing or
damaged parts. Use proper lifting mechanics
when assembling a ladder. Watch for overhead
electrical hazards and obstructions.
PAGE 1 OF 2
PARTS
C. Rear Handrail Bar (1)
(shipped under a step
attached with orange ties)
F. Back Panel (1)
ASSEMBLY
1.
D. Stile (1)
Notched Bushings (4)
STEP 1: BACK PANEl ASSEmBly
NOTE: DO NOT tighten bolts until instructed to.
Place the ladder stile (D) on the floor. Be sure to
assemble on a protective surface so the finish does
not get damaged.
2.
Bolt back panel (F) to the insides of lugs 1 with (2)
-16 x 1¼" hex head cap screw and self-locking
3
8
nuts. (See Figure 1)
E. Bottom Bars (2)
Hardware Kit (1)
(misc. hardware included)
1011 IH-840U-10
