H-5592, H-5593
π
H-5594
CROSSOVER LADDERS
TOOLS NEEDED
3/4" Wrench
3
1
WARNING! Please read and save these
instructions. Read carefully before attempting
to assemble, install, operate or maintain the
product described. Protect yourself and others
by observing all safety information. Failure
to comply with instructions could result in
personal injury and/or property damage!
Retain instructions for future reference.
PAGE 1 OF 6
1-800-295-5510
uline.com
3/4" Socket Wrench
4
2
PARTS
5, 6
ASSEMBLY
The crossover ladder is used to provide a safe walkway
over obstacles.
The crossover ladder is comprised of two stiles (1), one
platform (2), two left handrails (3), two right handrails (4),
1⁄2-13 x 1⁄" bolts (5) and 1⁄2" nylon insert hex nuts (6).
Para Español, vea páginas 3-4.
Pour le français, consulter les pages 5-6.
#
QTY.
DESCRIPTION
1
2
Stile
2
1
Platform
3
2
Left Handrail
4
2
Right Handrail
5
36
1/2-13 x 1⁄" Bolt
6
36
1/2" Nylon Hex Nut
0521 IH-5592
