H-7903, H-7904
STEP LADDERS

TOOLS NEEDED

1/2" Wrench or Socket
Step Ladder x 1
WARNING: Assembly of these types of ladders can be inherently dangerous. Please take all precautions
necessary during the assembly process. Always use a separate ladder to finish assembly in high places.
Never climb a ladder that is not completely assembled. Do not assemble or use a ladder with missing or
damaged parts. Use proper lifting mechanics when assembling a ladder. Watch for overhead electrical
hazards and obstructions.

CROSS-BRACE FOR HANDRAILS

1.
Remove product from carton and unwrap all parts.
2. Align the holes of crossbar with handrails and start
the Phillips head screw from the outside.
(See Figure 1)
3. Repeat this procedure for the opposite side.
4. Tighten screws.
PAGE 1 OF 6
1-800-295-5510
Rubber Mallet
Phillips Screwdriver
Handrail x 2
uline.com
Safety Glasses

PARTS

Crossbar x 1

ASSEMBLY

Figure 1
Para Español, vea páginas 3-4.
Pour le français, consulter les pages 5-6.
Hardware Kit
Hex Nut x 2
Hex Head Cap
Screw x 2
Flat Washer
Phillips Head
x 2
Screw x 4
U Shaped
Bracket x 2
0521 IH-7903
