8. Reader Feedback

Scenario
CR1100 successfully powers up
CR1100 successfully enumerates with host (via cable)
Attempting to decode
Successful decode and data transfer
Configuration code successfully decoded and processed
Configuration code successfully decoded but wasn't successfully processed
Downloading file/firmware
Installing file/firmware
*Depending on comm port configuration
9. Symbologies Turned On
by Default
The following are symbologies that are turned
on by default. To turn symbologies on or off,
scan the symbology barcodes in the CR1100
Configuration Guide—located on the CR1100
product page:
codecorp.com/products/code-reader-1100
•
Aztec
•
Codabar
•
Code 39
•
Code 93
•
Code 128
•
Data Matrix
•
Data Matrix
Rectangle
D032078_03_CR1100_User_Manual
•
All GS1 DataBar
•
Interleaved 2 of 5
•
PDF417
•
QR Code
•
UPC/EAN/JAN
Top LED Light
Green LED flashes
Once enumerated, the green LED turns off
Green LED light is off
Green LED flashes
Green LED flashes
Green LED flashes
Amber LED flashes
Red LED is on
10. Symbologies Turned Off
by Default
Code barcode readers can read a number of
barcode symbologies that are not enabled
by default. To turn symbologies on or off,
scan the symbology barcodes in the CR1100
Configuration Guide—located on the CR1100
product page:
codecorp.com/products/code-reader-1100
•
Codablock F
•
Code 11
•
Code 32
•
Code 49
•
Composite
•
Grid Matrix
•
Han Xin Code
•
Hong Kong 2 of 5
•
IATA 2 of 5
•
Matrix 2 of 5
Sound
1 beep
1 beep
None
1 beep
2 beeps
4 beeps
None
3-4 beeps*
•
Maxicode
•
Micro PDF417
•
MSI Plessey
•
NEC 2 of 5
•
Pharmacode
•
Plessey
•
Postal Codes
•
Standard 2 of 5
•
Telepen
•
Trioptic
