6.0 - Reader Feedback

Scenario
CR1000
Successfully
Powers Up
CR1000
Successfully
Enumerates with
Host (via cable)
Attempting to
Decode
Successful
Decode and Data
Transfer via Cable
Configuration
Code Successfully
Decoded and
Processed
Configuration
Code Successfully
Decoded
but wasn't
Successfully
Processed
Top LED Button
Green LED lights Up
Once enumerated, the
Green LED turns off
Press the top button
Green LED light is off
Green LED lights Up
Press the top button
the LED does not flash
Press the top button
the LED does not flash
Sound
1 Beep
1 Beep
None
1 Beep
2 Beeps
4 Beeps
