5. Using a CR1100 Outside of a
Universal Stand

7. Typical Reading Ranges

Test Barcode
3 mil Code 39
7.5 mil Code 39
10.5 mil GS1 DataBar
13 mil UPC
5 mil DM
6.3 mil DM
10 mil DM
20.8 mil DM
Note: Working ranges are a combination of both the wide and high density fields. All samples were high
quality codes and were read along a physical center line at a 10° angle. Measured from the front of the reader
with default settings. Testing conditions may impact reading ranges.
D032078_03_CR1100_User_Manual
10 cm
Min Inches (mm)
3.3" (84 mm)
1.9" (47 mm)
0.6" (16 mm)
0.6" (16 mm)
1.9" (48 mm)
1.4" (35 mm)
0.6" (14 mm)
1.0" (25 mm)
6. Using a CR1100 in a
Universal Stand
Max Inches (mm)
4.3" (109 mm)
7.0" (177 mm)
7.7" (196 mm)
11.3" (286 mm)
4.8" (121 mm)
5.6" (142 mm)
7.2" (182 mm)
12.6" (319 mm)
10 cm
