Section 2, Engineering Guidelines

Front Panel LEDs

With the NetVanta 2000 series powered-up, the front panel LEDs provide visual information about the
status of the system. Table 1 provides a brief description of the front panel features, and Table 2 provides
detailed information about the LEDs.
Feature
PWR
VPN (2050/2100 only)
VPN TD
VPN RD
VPN ACT (2300/2400 only)
LAN TD
LAN RD
LAN LNK (2300/2400 Only)
WAN TD
WAN RD
WAN LNK (2300/2400 Only)
For these LEDs...
PWR
VPN
(2050/2100 only)
VPN ACT
(2300/2400 Only)
18

Table 1. NetVanta 2000 series Front Panel Description

Indicates whether the unit has power.
Indicates status of VPN negotiations.
Indicates VPN traffic transmitted by the NetVanta.
Indicates VPN traffic received by the NetVanta.
Indicates status of VPN Negotiations.
Indicates LAN traffic transmitted by the NetVanta.
Indicates LAN traffic received by the NetVanta.
Indicates active physical link on the LAN port.
Indicates WAN traffic transmitted by the NetVanta.
Indicates WAN traffic received by the NetVanta.
Indicates active physical link on the WAN port.

Table 2. NetVanta 2000 series LEDs

This color light...
Red (solid)
Green (solid)
Amber (slow blink)
Green (slow blink)
Red (slow blink)
Amber (fast blink)
Green (solid)
Red (fast blink)
Amber and Green
(alternating slow blink)
© 2002 ADTRAN, Inc.
NetVanta 2000 Series System Manual
Description
Indicates that...
The unit has power and is in the boot process.
Unit has power and has successfully completed the
boot process.
Initial Phase 1 IKE negotiation in progress.
Initial Phase 1 IKE negotiation completed successfully.
Phase 1 IKE negotiation failed.
Phase 2 IKE negotiation in progress.
Phase 2 IKE negotiation completed successfully.
Phase 2 IKE negotiation failed.
There is an active tunnel and an additional IKE Phase
1 negotiation in progress.
