PB_P216_08 2014
P216
Condenser Fan Speed Controller
Product Bulletin
These controllers are designed for speed variation of single
phase motors, especially for fan speed control on air cooled
condensers. Head pressure control of a refrigeration system,
through speed variation of the fan on an air-cooled condenser,
results in optimum performance throughout the year.
Using a pressure transducer as the input device to the fan
speed controller, gives the most direct and fastest response
to pressure variations in the refrigerant system. The controller
varies the supply voltage to the motor from 45% to at least 95%
over the proportional band using the phase cutting principle.
If the pressure drops below the adjusted setpoint minus the
proportional band, the output to the motor is zero volt or the
adjusted min. speed setting. This provides speed variation of
permanent split capacitor or shaded pole motors which do not
draw more than 12 A (rms) full load current.
The controller used for dual pressure input varies the fan speed
by directly sensing the pressure changes of two separate
refrigerant circuits. The setpoint of each pressure transducer
can be separately adjusted. The controller selects the input with
the greatest cooling demand to control the fan speed.
The transducers can be used in non-corrosive refrigerant
systems.
The motor manufacturer should have approved his product for
this speed control principle. It is recommended to confirm with
the electric motor manufacturer, that the motor can be used
with a controller, using the phase cutting principle for speed
variation.
You can also provide a copy of this P216 product data sheet to
the motor manufacturer/supplier for review.
Features
• The new benchmark in standard FSC
• Easy to Install and Easy to operate
• Output Range: 0,5 to 12 Amp (1 phase)
• Input 0-10 Vdc
• Including 0-50 bar pressure transducer P499VCS-405C
• Heatpump mode
• Reverse operation mode
• Master / Slave mode
• Fixed pressure ranges for direct replacement (P215)
• Setpoint and Min speed potmeters

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Penn P216 and is the answer not in the manual?

Questions and answers

Related Manuals for Johnson Controls Penn P216

Summary of Contents for Johnson Controls Penn P216

  • Page 1 PB_P216_08 2014 P216 Condenser Fan Speed Controller Product Bulletin These controllers are designed for speed variation of single phase motors, especially for fan speed control on air cooled condensers. Head pressure control of a refrigeration system, through speed variation of the fan on an air-cooled condenser, results in optimum performance throughout the year.

  • Page 2: Dimensions (Mm)

    PB_P216_08 2014 Dimensions (mm)

  • Page 3: Installation

    PB_P216_08 2014 Installation The P216 can be used for single or dual pressure input. For proper aircirculation there should be a clearance In the case of dual input the controller selects the input around the controller of at least 10 mm. When mounted with the greater cooling demand to control the fan speed.

  • Page 4: Input Connections

    PB_P216_08 2014 Wiring Heatpump Electric Shock. WARNING: Risk of and Reverse action Disconnect or isolate all power supplies before Terminal making electrical connections. More than one disconnect or isolation may be required to completely de-energize equipment. Contact with components carrying hazardous voltage can cause electric shock and may DIP Switch Block result in severe personal injury or death.
  • Page 5 PB_P216_08 2014 P216 Output Voltage vs Input In reverse operation, the minimum speed occurs when the pressure is equal to the setpoint and the maximum speed occurs when the pressure is less than or equal to the setpoint minus the prop. band. DIP Switch Block Min speed ON OFF OFF ON...
  • Page 6 PB_P216_08 2014 Switches Positions Dip Switch Block Min Speed Switch Motor never stops, always runs at Min Speed or greater, depending on conditions. Motor does not run unless conditions dictate that it does so. Setpoint Voltage Command Modes Range CCW - CW Sensor Sensor Proportional...
  • Page 7 P499 Electronic Pressure Transducers P216 Series controllers are designed to reference either Only P499 models that have a 0-10 Vdc output signal can one or two Johnson Controls P499 Electronic Pressure be used with the P216 control. Transducers to monitor condenser pressure.

  • Page 8: Technical Specification

    The performance specifications are nominal and conform to acceptable industry standards. For application at conditions beyond these specifications, consult the local Johnson Controls office. Johnson Controls, Inc. shall not be liable for damages resulting from misapplication or misuse of its products.
